  1. NetGlide Product Family Overview

  2. 3rd Generation 4th Generation 2nd Generation The Evolution to Fourth Generation WiFi 1st Generation Functionality • Consumer WiFi • Consumer-Grade WiFi Routers • Minimal Security • Enterprise WiFi • Limited Security • “Fat” Stand-Alone APs • AP's not networked • Security not robust • Centrally-Managed, Enterprise WiFi • Improved Security • Thin APs, Controller Managed • Cell Planning Required • Interference Prone • Poor VoFi Operation • Deployment of 802.11n requires significant changes to network • Portability, Not Mobility • Multi-Application, Ubiquitous WiFi • Coordinated AP transmissions Paradigm Major Shortcomings

  3. Technical background

  4. Bandwidth Limitation Of Cell Based System Co-Channel Interference Roaming Edge Users

  5. Bandwidth Limitation Of Cell Based System • Radio channels are a scarce resource – use them wisely • Make each channel’s bandwidth available everywhere

  6. Interference-Free™ Architecture • The channel blanket is formed from the aggregate coverage of all the APs • APs operate on the same channel(s) to create the channel blanket • The Switch completely controls the APs, preventing co-channel interference • The AP is only a radio/antenna; no software, no configuration; no IP address, no processing • The Client associates with the switch, not the AP; the APs are simply conduits between the client and the switch

  7. Uplink in the Channel Blanket (1) (2) • Uplink path diversity • Multiple APs “hear” the client • Switch receives multiple copies of the same transmission, and selects the best one – making the uplink resilient to disruption on any one individual link • Seamless zero-latency mobility • As the client moves, different APs receive the uplink transmission - this is transparent to the client and no handoff event ever occurs • Elimination of client balancing problem that exists in cell-based WLAN

  8. Netronics Wireless LAN • Total Mobility • Robust In Any Environment • Multi-Service Convergence • True Dual-Band 802.11n • Slashes the Complexity of Wireless and Networking

  9. A Different Picture for Radically Different Results NetGlide • Channel Blanket • No Cell Planning Complexity • Robust Connection • Zero-Latency Mobility • Client Consistency 1 6 11 • Layer Any Mix of Channels, Modes and Band, from the Same Set of APs • Stacked Capacity • Built-In QoS • Dedicated Security “Simply a Better Way to Wireless” Cell / Virtual Cell Based 1 11 6 11 6 • Dramatic reduction in networking complexity 6 1 1

  10. The NetGlide Experience Guaranteed Performance Move from “Best-Efforts” WLAN to Guaranteed Performance metrics Surprising Simplicity Take away the complexity of RF Total Mobility Voice demands true mobility – without it, convergence cannot succeed Voice, Data, & Video Without Trade-Offs One infrastructure investment, many uses, serving different users with predictable quality of service

  11. 802.11n 2.4 GHz Scenario Today’s 3 non-overlapping channels collapse down to 1 x 40MHz and 1 x 20MHz channel “Full-performance” ‘n’ (i.e. the 300Mbps promise) requires a 40MHz-wide channel, with only ‘n’ clients Mixing ‘g’ clients with ‘n’ on the same channel reduces throughput by 4X! 20MHz wide channels provide half the data rate as 40MHz channels 2402 2407 2412 2417 2422 2427 2432 2437 2442 2447 2452 2457 2462 2467 2472 MHz Today Ch 1 Ch 6 Ch 11 802.11n/g 40MHz width 20MHz width

  12. Advantage Netronics in 2.4 GHz Band • Netronics is the only technology capable of supporting full-performance 802.11n clients and permanent co-existence with full-performance 802.11b/g clients, all in the same AP deployment. Blanket 1: 40MHz “pure n” blanket Business as Usual: Enterprise-wide 802.11n + g/b WLAN n Blanket 2: 20MHz legacy b/g blanket b/g ? ? Mission Impossible: Not enough channels for cell planning • Cell-planning is not viable – insufficient channels for channel planning. Cell 1: 40MHz n/g cell ? ? n/g ? Cell 2: 20MHz n/g cell n/g ?

  13. Netronics 802.11n The Channel Blanket™ Comes of Age Any combination of channels, bands, modes, & security Data 2.4GHz ‘n’ Voice 2.4GHz ‘b/g’ Multimedia 5GHz ’n’ Locationing 5GHz ‘a’ or Rogue Monitor Multiple WLANs in One means the onlydisruption-free, gradual introductionof full-performance‘N’ in the enterprise

  14. Throughput Again and again, customers report how migration to NetGlide’s channel blanket solved their WLAN throughput problems.

  15. NetGlide Products WLAN Switches Access Points Management & Planning Accessories

  16. Continuing Our Technology Leadership: NetGlide –UTAP3nWorld’s First 3-stream Enterprise Access Point • 802.11a/b/g/n • 3 x 3 MIMO technology • 450 Mbps maximum air rate per channel blanket • 3 internal radios

  17. Edge GbE Port Capacity • Switch cascade • Ability to form ports switches of any number in the range of 16-32 • Single blanket, no handoff between switches • Requires switches direct connectivity • Cascading can be added to existing deployments • All traffic is uplinked to the networked from a single switch • Built in redundancy option 32 24 16 8 Standalone mode Cascade mode

  18. Switch Cascade High Availability LAN LAN Interconnect AP’s Distributed in mesh. Smaller coverage area.

  19. NetGlide Network Management System Centrally manage and monitor up to 48,000 APs / 2,000 switches Display floor plans with APs, geographical maps with sites Present faults, performance stats, inventory management, reports, graphs Interface to higher level organizational management systems

  20. 3 Case Studies • Essa School(UK) • Kiva Systems (USA) • Mignot Hospital (France)

  21. Essa-School, UK Private, K-12 school

  22. “Our vision was basically to form a wireless backbone for anytime, any place learning, that doesn’t necessarily have to take place in the classroom.” Abdul Chohan, Essa IT Manager

  23. The Challenge • Tablet PCs, iPhones, 50 wireless projectors, and an iPod Touch for every student to leverage podcasts and vodcasts as part of their day-to-day instruction. • Throughput, mobility, reliability must-haves

  24. Checked Out The Competition First • “I was beginning to think that wireless LANs might not be a feasible solution, because co-channel interference can severely reduce basic network performance during high usage periods…

  25. Then Discovered Netronics …Netronics seemed almost too good to be true. I hadn’t heard of Channel Blanket technology, and couldn’t imagine wireless without dead spots or limitations caused by interference. But we piloted the Netronics solution onsite, saw that the performance claims were real, and went forward immediately with it.” Abdul Chohan, Essa IT Manager

  26. The Result…. Networked Wireless Laptops in-use

  27. True Mobility, High Throughput Networked IPAD in-use

  28. Essa WLAN Platform • 802.11a/b/g/n • Netronics NetGlide APC-8 Controllers • switches • NetGlide UTAP3N Access Points

  29. KIVA Systems, USA Logistics and warehousing automation

  30. The Challenge • How do you control a floor of • fast-moving robots? • High RF Noise due to • metal building walls! • RF ‘canyons’ (the aisles) • Any WLAN outage will shut-down the system !!!

  31. Kiva Feedback “Especially in the fault conditions we looked into, Netronics performed effortlessly compared to other technologies. “Seamless mobility is very important to us, and Netronics technology is what makes that possible.” • Matt Verminski, Kiva Engineering

  32. Kiva WLAN Platform • 802.11a • NetGlide APC8 • switches • NetGlide UTAP3N Access Points

  33. Mignot Hospital, Versailles HS, France800-bed hospital, part of Versailles Hospital System

  34. The Challenge • Bandwidth-intensive PACS application ( 90MB files!) • Need fast downloads, while walking from room to room in patient areas • Seamless mobility • Absolute dependability!

  35. The Choice: Netronics “We needed real mobility without dropped connections while downloading Large, highly time-sensitive files……and Netronics was the only product that offered us that.” Herve Paris, Director of Information Technology Versailles Hospital System

  36. Mignot Hospital WLAN Platform • 802.11a • NetGlide APC8 • switches • NetGlide UTAP3N AccessPoints

  37. Thank you www.netronics-networks.com
