  1. Our Profile Corporate Milestone

  2. Our Profile 63% 67% 100% 100% 50% - Hull engineering and project management Malaysia Marine and Heavy Engineering Sdn Bhd (MMHE) - Oil & gas engineering and construction works, marine conversion and repair Malaysia Marine and Heavy Engineering (Turkmenistan) Sdn Bhd (MTSB) - Dormant 100% 60% 40% 70% Techno Indah Sdn Bhd - Sludge disposal management MMHE-SHI LNG Sdn Bhd (MSLNG) - Provision of repair services and dry docking of LNG carrier MMHE-ATB Sdn Bhd (MMHE-ATB) - Manufacturing of pressure vessels and tube heat exchangers MMHE-TPGM Sdn Bhd (MMHE-TPGM) - Provision of engineering, procurement, construction, installation and commissioning

  3. The Yard Facilities (West) • Dry dock 1 • Size: 385m x 80m x 14m (one of the largest • in region) • Dry dock 2 • Size: 270m x 46m x 12.5m • Capacity : 140,000 dwt Dry dock • 5 fabrication areas totalling 321,400 m2 • 3 skid tracks and 2 bulkheads, one up to • 40,000 mt and the other up to 12,000 mt • Skidding facilities up to 55,000 mt Open Fabrication Yard Area • 35 workshops covering an area of • 99,000m2 fully equipped service and • production workshop • Integrated cutting, sub-assembly and block • shop under one roof. Workshops • 1 LNG Carrier Repair Facility • 3 Global Test Control Rooms • 1 Cryogenic Workshop (557.8 m2) • 1 Invar Welding Training Centre • (84.24 m2) Other Facilities

  4. The Yard Facilities (West) • Size : 188.4m x 33.8m x 8m • Lift Capacity : 50,000 dwt Shiplift 2 land berths (each 345 metres in length) 7 quays (lengths of up to 368 metres) • Pier • Size : 300m x 25m • Capacity: 39,000 dwt West Finger Pier • Material Handling Quay • Size : 100m x 20m • Capacity: 5,000 dwt Comprehensive and integrated facilities in our strategically located 150.6 hectare complex with a 1.8km seafront in Pasir Gudang, Johor. Land berth Quay

  5. The Yard Layout (West) cutting & assembly workshop FA2 FA3 FA4 FA1 drydock 450k dwt drydock 140k dwt landberth FA5 shiplift bulkhead 40k mt skid-track 40k mt skid-track 55k mt

  6. The Yard Facilities (East) Location Total Area

  7. The Yard Facilities (East) TOTAL OPEN AREA (Exclude New Dev Area) As At March 2012

  8. The Yard Layout (East) 111 Acres, Capacity 60,000 MT/p.a.

  9. The Core Businesses • Engineering & Construction • Full range of oil and gas construction and engineering services from detailed engineering • design and procurement to construction, installation, hook-up and commissioning. • Only yard in Malaysia that has constructed complex deepwater structures for the oil & gas • industry. • Marine Conversion • Offers one-stop centre for converting vessels such as VLCCs, Aframax tankers and offshore • oil rigs into floating structures for the offshore oil and gas industry such as FPSOs, FSOs, • MOPUs and MODUs. • Only yard in Malaysia that has completed FPSO/FSO conversions. • Marine Repair • Offers repairs, refit and refurbishment services to a wide range of vessels with focus on energy-related vessels such as ULCCs, VLCCs, petroleum tankers, chemical tankers, offshore oil rigs, gas carriers and other offshore support vessels. • Provides maintenance, technical solutions and refurbishment services for LNG carriers, in joint venture with Samsung Heavy Industries. • One of three in Malaysia / Singapore region to repair or refurbish LNG carriers in 2009.

  10. Current project in the yard

  11. The Customers

  12. The Core Businesses Marine Conversion MMHE is a one-stop centre for FPSO and FSO conversions, providing a comprehensive range of services from initial design to fabrication, installation and commissioning.

  13. Conversion of FPSO Kikeh (Track record) Client: MDFT (Labuan) Ltd. Charterer: Murphy Sabah Oil Co., Ltd. Completion date: February 2007

  14. Conversion of FSO Okid (Track record) Client: MISC Completion date: Nov. 2008

  15. Conversion of FPSO Ruby (Track record) Client: MISC Weight: 100,047dwt Completion date: Mar 2009

  16. Conversion of T12 Tender Drill Barge (Track record) Client : Seadrill Delivery : 1 Dec 2009 4thOrder from Seadrill

  17. Conversion Works of FSU Lekas (Track record)

  18. Conversion Work of FPSO Cendor (Current)

  19. The Customers

  20. The Core Businesses Marine Repair

  21. The Track Record Over 3,500 Ships Repaired Since 1976 VLCC & OTHER PETROLEUM TANKERS GAS CARRIERS (LPG & LNG) CHEMICAL TANKERS OTHER VESSEL TYPES RIGS
