  1. Experience Predicting Application Server Memory Usage Thomas Reidemeister Mohammad A. Munawar Paul A.S.Ward University of Waterloo April 2005

  2. Outline • Introduction • Difficulty of predicting in dynamic systems • Case Study: Java-based Application server • A simple approach to predicting memory-usage • Some experiments • Work in progress

  3. Introduction • Need for monitoring system health • Performance • Security • Availability • Correctness, etc • Sources of information • Events (logs, notifications, etc) • System status (resources, parameters, etc) • Purpose • Anomaly detection and diagnosis • Dynamic reconfiguration • Planning

  4. Building a Model WorkloadGenerator ResponseMonitor System Under Observation Model Builder Model

  5. Using the Model Workload ResponseMonitor System Under Operation System Model Problem Determination Tool

  6. Dynamic Environments • Changing nature • System configurations can change • System components (software/hardware) can be updated/added/removed • Examples • Operating systems, Applications using Virtual Machines • Java-based applications • Java Virtual Machine (JVM) • Automatic memory management • Dynamic class-loading • Just-in-time compilation • Online byte-code instrumentation, etc

  7. Uncertainty • Why is prediction is difficult? • Beside lack of knowledge of the future, we have to deal with: • Availability of information • Quality of available information • Performance impact • Dynamic environments (adaptive behaviour) • Complexity of the underlying process and dependencies

  8. Case Study • Predicting memory-usage of a Java-based application server • Memory leaks and resource exhaustion is a severe problem • Automatic memory management makes it interesting • Prediction can help with • Load-balancing • Capacity planning • Possibly leak-detection • What can we achieve with the simplest approach and information that is readily available?

  9. Approach

  10. Setup • Software: • IBM WebSphere Application Server 5.1 running Trade3 • IBM DB2 UDB 8.1 • ‘httperf’ and httpunit-based custom workload generators • Hardware • P4 2.0 GHz, 1024MB machine with Windows Server 2003 running WebSphere • P4 2.0 GHz, 512MB machine with Redhat Linux running DB2 • Dual-processor Xeon 2.8GHz with Redhat Linux for load generation • Connected with a Gbit-network

  11. Profiling • Obtain low-level memory allocation information from the JVM • Use timing of request execution to match associated memory allocation • Execute requests sequentially and at reasonably distant time-points to better isolate their effects • Repeat requests a sufficient number of times and with different parameter values to obtain good representative statistics • Build histograms for each request-type and select mode as the representative value

  12. Profiling (cont.) • Examples Memory bytes allocated by an idle server Histogram of a request-type

  13. Profiling (cont.) • Issues • Typically, only millisecond time-resolution is available. How much memory does a sub-millisecond request use? When requests overlap in a millisecond-interval, we apportion equally • Should we isolate unusual, irregular memory-allocation due to internal house-keeping? • Profiles can change. A search request may require more memory depending how many add/updates have taken place since the last profiling time • Profiling requires a dedicated and isolated server

  14. Monitoring • Precise memory-usage information is not readily available • For example, Websphere interface to query memory-usage has a KB resolution. • Reported memory-usage usually includes objects no more referenced and waiting to be freed • Relatively precise information can be obtained from the JVM, if we profile GC events. However, the profiling interface does not provide a complete picture • Let us monitor at regular interval, but at some reasonable granularity. We thus have an approximate actual usage.

  15. Monitoring (cont.)

  16. Prediction • Predict number of requests of each type that we expect to see • Use the above together with the profiles created earlier to estimate memory-usage • Any technique to project future requests can be used. e.g. simple Exponential Smoothing • What prediction period to use? • Fixed-duration: memory usage information is approximate • Variable-duration (e.g. time to next GC event): need for estimating interval length

  17. Prediction (cont.) • Experiments • How close do we get to actual memory usage, if we knew exactly the number of each request-type received during an interval? • Let us use variable-duration intervals, which correspond to GC events observed to estimate actual memory-usage • The prediction model is instantiated with request counts and request-type profile (mode-values) • No model fine-tuning

  18. Prediction (cont.)

  19. Results • We slightly under-estimate in general, but closely follow the trend when a sufficient number of requests are received during the prediction interval • With some calibration, we should be able to achieve better results • Caching is an important factor that needs to be incorporated in our prediction model

  20. Improving Prediction • Build better profiles • Isolate object allocation due to server house-keeping • Deal with intervals with small number of requests • Use a different model? • Take caching into account • Model effect of present memory allocations on future requests

  21. Fine-grained Monitoring • Our approach can be used for coarse-grained monitoring • What if we wanted closer monitoring of the absolute memory used at any time? • Can we develop a general technique that can, for example, help detect memory-leaks? • Again, we would need to model the behaviour of the JVM in details • E.g. take into account the effect of requests, occurrence of GC events, caching, etc • Exploring Dynamic Bayesian Networks

  22. Summary • Described a simple approach to predicting memory-usage of an application server • Mentioned difficulties and issues • Showed that this approach is able to closely follow memory-usage trend • Depending on purpose, such simple prediction models can be very effective • Prediction in dynamic systems is tricky and require that we resort to approximations • But, we need to be intelligent about how to approximate

  23. Our Research • Resource monitoring for anomaly-detection in dynamic environments • Associating status information (e.g. resource usage) with discrete system events for problem detection and diagnosis • Adaptive monitoring

  24. End Thank you. Questions are welcome.
