  1. More SIMPLESEM Examples CSCI 169 - Oleg Aulov A. Bellaachia

  2. Review • Semantics • SIMPLESEM • C1 - simple statements only

  3. C2 and C2’ - simple routines • Global data • Routine declarations and definitions • Main() routine • C2’ - separate compilation

  4. C2 - program example int i=1,j=2,k=3; alpha() { int i=4,l=5; … i+=k+l; … }; beta() { int k=6; … i=j+k; alpha(); … }; main() { … beta(); … }

  5. C3 - recursive functions • Direct recursion • Indirect recursion

  6. C3 - implimentation needs • Base address (known at exec time only) • LIFO stack • Return pointer • Dynamic link / dynamic chain

  7. C3 - program example int n; int fact() { int loc; if(n>1){ loc=n--; return loc * fact(); } else return 1; } main() { get(n); if(n>=0) print(fact()); else print(“input error”); }

  8. Show Examples Show Examples on a SIMPLESEM

  9. Example of C2 0 set 0,read 1 set 1,read 2 set 2,read 3 set 6,5 4 jump 10 5 halt 6 set 4,4 7 set 5,5 8 set 4, D[4]+D[2]+D[5] 9 jump D[3] 10 set 7,6 11 set 0, D[1]+D[7] 12 set 3, 14 13 jump 6 14 jump D[6]

  10. Example of C3 14 set D[0] + 2, D[2] 15 set 2, D[2] - 1 16 set 1, D[1] + 1 17 set D[1], ip + 4 18 set D[1] + 1, D[0] 19 set 0, D[1] 20 set 1, D[1] + 3 21 jump 13 22 set D[0] - 1, D[D[0] + 2] * D[D[1] - 1] 23 jump 25 24 set D[0] - 1, 1 25 set 1, D[0] 26 set 0, D[D[0] + 1] 27 jump D[D[1]] 0 set 1,3 1 set 2, read 2 jumpt 11, D[2] < 0 3 set 1, D[1] + 1 4 set D[1], ip + 4 5 set D[1] + 1, D[0] 6 set 0, D[1] 7 set 1, D[1] + 3 8 jump 13 9 set write, D[D[1] - 1] 10 jump 12 11 set write, "input error" 12 halt 13 jumpt 24, D[2] <= 1
