  1. Dynamics

  2. Things to Remember from Last Year Newton's Three Laws of Motion Inertial Reference Frames Mass vs. Weight Forces we studied:  weight / gravity  normal force  tension  friction (kinetic and static) Drawing Free Body Diagrams Problem Solving

  3. Newton's Laws of Motion 1. An object maintains its velocity (both speed and direction) unless acted upon by a nonzero net force. 2. Newton’s second law is the relation between acceleration and force. 3. Whenever one object exerts a force on a second object, the second object exerts an equal force in the opposite direction on the first object. ΣF = ma

  4. 1 Which of Newton's laws best explains why
motorists should buckle-up? A First Law B Second Law C Third Law D Law of Gravitation

  5. 2 You are standing in a moving bus, facing forward,
and you suddenly fall forward. You can infer from
this that the bus's A velocity decreased. B velocity increased. C speed remained the same, but it is turning
to the right. D speed remained the same, but it is turning
to the left.

  6. 3 You are standing in a moving bus, facing forward,
and you suddenly fall forward as the bus comes to
an immediate stop. What force caused you to fall
forward? A gravity B normal force due to your contact with the floor
of the bus C force due to friction between you and the floor
of the bus D There is not a force leading to your fall.

  7. 4 When the rocket engines on the spacecraft are
suddenly turned off, while traveling in empty
space, the starship will A stop immediately. B slowly slow down, then stop. C go faster. D move with constant speed

  8. 5 A net force F accelerates a mass m with an
acceleration a. If the same net force is applied to
mass 2m, then the acceleration will be A 4a B 2a C a/2 D a/4

  9. 6 A net force F acts on a mass m and produces an
acceleration a. What acceleration results if a net
force 2F acts on mass 4m? A a/2 B 8a C 4a D 2a

  10. 7 An object of mass m sits on a flat table. The Earth
pulls on this object with force mg, which we will
call the action force. What is the reaction force? A The table pushing up on the object with force
mg B The object pushing down on the table with
force mg C The table pushing down on the floor with force
mg D The object pulling upward on the Earth with
force mg

  11. 8 A 20-ton truck collides with a 1500-lb car and
causes a lot of damage to the car. Since a lot of
damage is done on the car A the force on the truck is greater then the
force on the car B the force on the truck is equal to the force
on the car C the force on the truck is smaller than the
force on the car D the truck did not slow down during the
collision

  12. Inertial Reference Frames Newton's laws are only valid in inertial reference
frames: An inertial reference frame is one in which Newton’s
first law is valid. This excludes rotating and
accelerating frames.

  13. Mass and Weight MASS is the measure of the inertia of an object, the
resistance of an object to accelerate. WEIGHT is the force exerted on that object by
gravity. Close to the surface of the Earth, where the
gravitational force is nearly constant, the weight is: Mass is measured in kilograms, weight Newtons. FG = mg

  14. Normal Force and Weight FN The Normal Force,
FN, is ALWAYS perpendicular to
the surface. Weight, mg, is
ALWAYS directed
downward. mg

  15. 9 The acceleration due to gravity is lower on the
Moon than on Earth. Which of the following is
true about the mass and weight of an astronaut on
the Moon's surface, compared to Earth? A Mass is less, weight is same B Mass is same, weight is less C Both mass and weight are less D Both mass and weight are the same

  16. 10 A 14 N brick is sitting on a table. What is the
normal force supplied by the table? A 14 N upwards B 28 N upwards C 14 N downwards D 28 N downwards

  17. Kinetic Friction Friction forces are
ALWAYS parallel to
the surface exerting
them. Kinetic friction is
always directed
opposite to
direction the object
is sliding and has
magnitude: fK = μkFN v fK

  18. 11 A 4.0kg brick is sliding on a surface. The
coefficient of kinetic friction between the surfaces
is 0.25. What it the size of the force of friction? A 8.0 B 8.8 C 9.0 D 9.8

  19. 12 A brick is sliding to the right on a horizontal
surface. What are the directions of the two surface forces:
the friction force and the normal force? A right, down B right, up C left, down D left, up

  20. Static Friction Static friction is
always equal and
opposite the Net
Applied Force
acting on the object
(not including
friction). Its magnitude is: fS ≤ μSFN fS FAPP

  21. 13 A 4.0 kg brick is sitting on a table. The coefficient
of static friction between the surfaces is 0.45.
What is the largest force that can be applied
horizontally to the brick before it begins to slide? A 16.33 B 17.64 C 17.98 D 18.12

  22. 14 A 4.0kg brick is sitting on a table. The coefficient
of static friction between the surfaces is 0.45. If a
10 N horizontal force is applied to the brick, what
will be the force of friction and will the brick
move? A 16.12, no B 17.64, no C 16.12, yes D 17.64, yes

  23. Tension Force When a cord or rope pulls on an
object, it is said to be under
tension, and the force it exerts is
called a tension force, FT. FT a mg

  24. 15 A crane is lifting a 60 kg load at a constant
velocity. Determine the tension force in the cable. A 568 N B 578 N C 504 N D 600 N

  25. 16 A system of two blocks is accelerated by an
applied force of magnitude F on the frictionless
horizontal surface. The tension in the string
between the blocks is: A 6F F 6 kg 4 kg B 4F C 3/5 F D 1/6 F E 1/4 F

  26. Two Dimensions

  27. Adding Orthogonal Forces Since forces are vectors, they add as vectors. The simplest case is if the forces are perpendicular
(orthogonal) with another. Let's add a 50 N force at 0o with a 40 N force at 90o.

  28. Adding Orthogonal Forces 1. Draw the first force
vector, 50 N at 0o,
beginning at the origin. 90o 180o 0o 270o

  29. Adding Orthogonal Forces 1. Draw the first force
vector, 50 N at 0o, beginning at the origin. 2. Draw the second force
vector, 40 N at 90o, with its tail at the tip of the first
vector. 90o 180o 0o 270o

  30. Adding Orthogonal Forces 1. Draw the first force
vector, 50 N at 0o, beginning at the origin. 2. Draw the second force
vector, 40 N at 90o, with its tail at the tip of the first
vector. 3. Draw Fnet from the tail of the first force to the tip of
the last force. 90o 180o 0o 270o

  31. Adding Orthogonal Forces We get the magnitude of the resultant from the
Pythagorean Theorem. c2 = a2 + b2 Fnet2 = (50N)2 + (40N)2 = 2500N2 + 1600N2 = 4100N2 Fnet = (4100N2)1/2 = 64 N 90o 180o 0o 270o

  32. Adding Orthogonal Forces We get the direction of the net Force from the inverse tangent. tan(θ) = opp / adj tan(θ) = (40N) / (50N) tan(θ) = 4/5 tan(θ) = 0.8 θ = tan-1(0.80) = 39o Fnet = 64 N at 39o 90o 180o 0o 270o

  33. Decomposing Forces into Orthogonal
Components 90o Let's decompose a 120 N
force at 34o into its x and y
components. F θ 180o 0o 270o

  34. Decomposing Forces into Orthogonal
Components 90o We have Fnet, which is the hypotenuse, so let's first
find the adjacent side by
using cosθ = adj / hyp cosθ = Fx / Fnet Fx = Fnet cosθ = 120N cos34o = 100 N F θ 180o 0o Fx 270o

  35. Decomposing Forces into Orthogonal
Components 90o Now let's find the opposite
side by using sinθ = adj / hyp sinθ = Fy / Fnet Fy = Fnet sinθ = 120N sin34o = 67 N Fy F θ 180o 0o Fx 270o

  36. Adding non-Orthogonal Forces Now that we know how to add orthogonal forces. And we know now to break forces into orthogonal
components, so we can make any force into two
orthogonal forces. We combine those two steps to add any number of
forces together at any different angles.

  37. Adding non-Orthogonal Forces Let's add together these three forces: F1 = 8.0 N at 50o F2 = 6.5 N at 75o F3 = 8.4 N at 30o First, we will do it graphically, to show the
principle for how we will do it analytically. Then, we will do it analytically, which is easy once
you see why it works that way.

  38. Adding non-Orthogonal Forces 90o First, here are the
vectors all drawn
from the origin. F1 = 4.0 N at 50o F2 = 6.5 N at 75o F3 = 8.4 N at 30o 180o 0o 270o

  39. Adding non-Orthogonal Forces 90o Now we arrange
them tail to tip. F3 F2 F1 180o 0o F1 = 4.0 N at 50o F2 = 6.5 N at 75o F3 = 8.4 N at 30o 270o

  40. Adding non-Orthogonal Forces 90o Then we draw in the
Resultant, the sum of the vectors. F3 F2 F F F1 F2 F3 F1 180o 0o F1 = 4.0 N at 50o F2 = 6.5 N at 75o F3 = 8.4 N at 30o 270o

  41. Adding non-Orthogonal Forces 90o F3 Now, we graphically
break each vector
into its orthogonal
components. F3y F3x F F2 F2y F2x F1 F1y F1 = 4.0 N at 50o F2 = 6.5 N at 75o F3 = 8.4 N at 30o 180o 0o F1x 270o

  42. Adding non-Orthogonal Forces 90o Then, we remove
the original vectors
and note that the
sum of the
components is the
same as the sum of
the vectors. F3y F3x F F2y F2x F1y 180o 0o F1 = 4.0 N at 50o F2 = 6.5 N at 75o F3 = 8.4 N at 30o F1x 270o

  43. Adding non-Orthogonal Forces 90o This is the key result: The sum of the x-
components of the
vectors equals the x-
component of the
Resultant. As it is for the y-
components. F3y F F2y Fy F1y F3x F1x F2x F1 = 4.0 N at 50o F2 = 6.5 N at 75o F3 = 8.4 N at 30o 180o 0o Fx 270o

  44. Adding non-Orthogonal Forces This explains how we will add vectors analytically. 1. Write the magnitude and direction (from 0 to 360 degrees)
of each vector. 2. Compute the values of the x and y components. 3. Add the x components to find the x component of the
Resultant. 4. Repeat for the y-components. 5. Use Pythagorean Theorem to find the magnitude of the
Resultant. 6. Use Inverse Tangent to find the Resultant's direction.

  45. Adding non-Orthogonal Forces First make a table and enter what you know. F1 = 8.0 N at 50o F2 = 6.5 N at 75o F3 = 8.4 N at 30o

  46. Adding non-Orthogonal Forces Then calculate the x and y components. F1 = 8.0 N at 50o F2 = 6.5 N at 75o F3 = 8.4 N at 30o

  47. Adding non-Orthogonal Forces Then add up the x and y components. F1 = 8.0 N at 50o F2 = 6.5 N at 75o F3 = 8.4 N at 30o

  48. Adding non-Orthogonal Forces Then use Pythagorean Theorem and tan-1 to determine Fnet. F1 = 8.0 N at 50o F2 = 6.5 N at 75o F3 = 8.4 N at 30o

  49. Adding non-Orthogonal Forces Let's add together these three forces: F1 = 8.0 N at 50o F2 = 6.5 N at 75o F3 = 8.4 N at 30o

  50. Adding non-Orthogonal Forces Now use the same procedure to add these forces. DO NOT IGNORE NEGATIVE SIGNS F1 = 21 N at 60o F2 = 65 N at 150o F3 = 8.4 N at 330o
