  1. BoggleAssignment Intro James Wei Professor Peck March 26, 2014 Slides by James Wei

  2. Outline • A look at Boggle • Classes of Boggle • Understanding the design • Implementing a word finder • Implementing a lexicon • Implementing an autoplayer • Analysis • Grading • Summary

  3. A look at Boggle • We are creating AI to play the game Boggle • The AI will make use of three main tools to find words on a boggle board: • A lexicon for knowing which words are valid • A word finder for searching for a specific word on the board • An autoplayer for searching the board for words • We will also analyze different implementations of these tools to see which ones are better • Sample playthrough

  4. Classes of Boggle • The (more important) classes of Boggle: • BoggleMain – runs Boggle • IWordOnBoardFinder– interface for finding the position of a single word on a Boggle board • ILexicon– interface for a list of all valid words and the ability to query for them • IAutoPlayer– interface for an AI Boggle player • LexiconBenchmark– performs stress and correctness tests on Lexicon implementations • BoggleStats– compares performance for different lexicon/autoplayer combinations • TestLexicon/TestWordFinder– test your code

  5. Understanding the Design • Boggle is a great example of the uses of inheritance! You will write multiple implementations for various interfaces. • As mentioned before, these interfaces include: • ILexicon • IWordOnBoardFinder • IAutoPlayer

  6. Understanding the Design • Steps to Boggle: • Player enters a guess • Computer looks for word and highlights if found • When time runs out, computer looks for all valid words on board • Computer lists out all valid words

  7. Understanding the Design • Break it down—what tasks must we be able to handle (and what’s handled for us)? • Given a String, determine if it is a word • Given a word, determine its exists on the board • Given a board, find all valid words in it • Framework for playing the game is given

  8. Understanding the Design • Break it down—what tools will handle each individual task? • We determine if a String is a valid word using a lexicon, as defined by ILexicon • We search boards for individual words and obtain the positions of those words with a word finder, as defined by IWordOnBoardFinder • We determine the entire list of words on a board by using an autoplayer, as defined by IAutoPlayer

  9. Understanding the Design • What are we given? What will we write? • Lexicons: we start with SimpleLexicon, which holds a dictionary as a list of Strings, and TrieLexicon, which uses tries (a variant of a tree) to organize words • We will write BinarySearchLexicon, which uses binary search to make querying the lexicon faster • For extra credit, you may also write CompressedTrieLexicon, which is a more optimized implementation of TrieLexicon

  10. Understanding the Design

  11. Understanding the Design • What are we given? What will we write? • Word Finders: we start with our so-called BadWordOnBoardFinder, which employs the beautiful strategy of always returning nothing • We will write GoodWordOnBoardFinder, which uses recursive backtracking to find the cells at which a word can be found on the board

  12. Understanding the Design • What are we given? What will we write? • AutoPlayers: we have LexiconFirstAutoPlayer, which relies on a working implementation of IWordOnBoardFinder to search the board for every possible word in the lexicon • We will write BoardFirstAutoPlayer, which uses recursive backtracking to search the board for all of valid words, instead of searching the board for each word in the lexicon specifically

  13. Understanding the Design

  14. Implementation – Lexicon • Look at BinarySearchLexicon. Most methods are already implemented for you, but you must complete one: LexStatuswordStatus(String) • wordStatus must: • Use binary search to see if the string exists in the lexicon (use Collections.binarySearch, check online for documentation on its usage) • Determine if a string that is not found is a PREFIX by finding the word in the lexicon which would succeed it if inserted and seeing if the string is a prefix to that word

  15. Implementation – Lexicon • What’s a LexStatus? • It’s an enum, aka a special data type which must take one of several predefined constants • Our enum has three values: • LexStatus.WORD • LexStatus.PREFIX • LexStatus.NOT_WORD • More on enums: http://docs.oracle.com/javase/tutorial/java/javaOO/enum.html

  16. Implementation – Word Finder • Look at IWordOnBoardFinder—there is one method to implement in this interface List<BoardCell> cellsForWord(BoggleBoard, String) • cellsForWord must: • Use recursive backtracking to find the cells in which a word on the board is found • Return a List of BoardCell objects which represent the position of each letter on the board in order • Hints to get started: what is the base case? What about the recursive step?

  17. Implementation – Word Finder • Two other classes to consider here, BoggleBoard and BoardCell, which are java objects representing the board and cell • BoggleBoard is implemented as a String array showing the faces of the board • So this board to the right is represented by the String array:[“LORE”, “LTSR”, “AOSP”, “MOTG”] • BoardCell represents the positionof one cell on the board—does notstore the cell’s value!

  18. Implementation – AutoPlayer • Look at BoardFirstAutoPlayer. Most methods are already implemented for you, but you must complete one: void findAllValidWords(BoggleBoard, ILexicon, int) • findAllValidWords must: • Iterate over all cells on a board for use as a “start” • For each starting cell, use recursive backtracking to find every word starting at that cell • Use an ILexiconto determine hits and base cases • Use the IPlayeradd method to mark found words

  19. Analysis • When you finish coding the assignment, you will have three (four with extra credit) lexicon implementations and two autoplayers • Now the question is—which ones are better? • You will analyze your different implementations using the BoggleStats class we have provided for you

  20. Analysis • How to use BoggleStats? Pretty easy… • main method calls runTests, which calls doTests • doTests will create two autoplayers, a LexiconFirst and a BoardFirst, then it will use each autoplayer to find all valid words on a series of randomly generated boards • The Lexicon used by BoggleStats is passed in to doTests as an argument • You may change the instance variable NUM_TRIALS as appropriate • You will need to modify doTests to return the highest scoring board for part of the analysis

  21. Analysis • Your analysis has a few parts: • Compare running different autoplayers with different lexicons (with at least 500 trials per combination). Include both empirical data AND code analysis! • Play lots of auto-games—start with 100, then 1,000, 10,000, 50,000. Use your findings to predict how long it’d take for 100,000 and 1,000,000 games • In your 10,000 auto-games, print out the Boggle board you find with the highest score (and the score) • Run these tests for both 4x4 and 5x5 boards

  22. Grading • Your grade is based on: • Code (16 pts + 1 E.C.): • Word finder code passes tests • Lexicon code passes tests • Functional autoplayer • CompressedTrieLexicon implementation (extra credit) • Analysis (4 pts): • All combinations of autoplayers and lexicons • Sufficient number of trials per combination (500 bare minimum, likely need more for other parts of analysis) • High scores for 4x4 and 5x5 board sizes, and the boards corresponding to those scores

  23. Wrap-Up • Recommended plan of attack? • Start by looking over everything, understanding the classes and the program design • Implement BinarySearchLexicon; test with TestLexicon which is provided • Implement GoodWordOnBoardFinder (you need to make this class yourself); test with TestWordFinder • Modify BoggleMain to use your new word finder and try playing Boggle • Implement BoardFirstAutoPlayer; try playing Boggle with this autoplayer

  24. Wrap-Up • Recommended plan of attack? • Check your BoardFirstAutoPlayer by running BoggleStats with 100+ trials; your autoplayer should find the same number of words in every board as LexiconFirstAutoPlayer • Using BoggleStats, try running large numbers of autoplayer games using all combinations of lexicons and autoplayers • In your analysis, compare performance of different lexicon/autoplayer combinations; make sure to include both empirical data and code analysis • For extra credit, implement CompressedTrieLexicon and include it in your analysis

  25. One Last Thing… • Start early! Seriously. Or you’ll be sadder than this woman:

  26. Good luck! Start early!
