  1. SIWAREX

  2. Stand alone Weighing and Proportioning High Speed Dosing Fill level monitoring load measurement SIWAREX P SIWAREX M SIWAREX A SIWAREX U EX- Interface SIWAREX R Load cells and Mounting Copmponents SIWAREX leveringsprogramma 40 years weighing technology

  3. WSG WSG F    R U S + WSG + U F + R _ Um + F _ U F - U S - Um SIWAREX het weegprincipe

  4. SIWAREX Rloadcellen

  5. SIWAREX RRN serie • Bending ring load cell • Nominal loads 60, 130, 280, 500 kg, 1, 2, 3.5, 5, 10, 13, 28, 60 t • Certification acc. to OIML R60 up to 6000d • Certification for use in Ex area (EEx ib IIC T6) • Stainless steel version • High degree of protection IP 66/68 • Integrated overload protection • Low height • Specially suitable for use in container and platform scales

  6. SIWAREX R montage elementenRN serie – combinatie unit

  7. SIWAREX Uhighlights The SIMATIC + PCS7 weighing system Level supervision: Min + Max Modular Accuracy 0,05% Resolution 65.000 parts easy installing with SIWATOOL

  8. One or two channels version IM153-1 S5 / S7 PS307 CPU312 S I W A R E X U Central in SIMATIC S7- 300 S I W A R E X U SIMATICS7-300 SIMATICS7-300 Decentralized in SIMATIC S7- 300 / 400 / S5 MPI BUS SIWAREX Uintegratie in de Simatic omgeving

  9. SIEMENS SIMATIC ET 200M X 2 1 3 6ES7153-1AA02-0XB0 SIWAREX U bij een rioolwaterzuivering in twee-kanaaluitvoering Container 1 Sewage mud Container 1 S5 S7-300 S7-400 SIWAREX U (2 channel) SV ET200M 4 x load cells SB 4 x 5t PS 307 2A TTY JB SIMATIC TTY S7-300 Sewage mud Container 2 X 1 6ES7307-1BA00-0AA0 Container 2 4 x load cells SB 4 x 5t Profibus DP JB Junction box

  10. SIWAREX Utoepassingen Fill level scales (min/max) • Container and Silos Overload Protection • for cranes • for industrial lifts • for rolling lines All types of load and force • measuring belt tension • measuring combustible consumption

  11. SIWAREX weeg- en doseersystemen Hartelijk dank voor uw aandacht!
