Presentation Transcript

  1. CATCERA www.nanoxides.com NCI Ceramic Filter-Catalyst Composite Related Process and Technology ( CATCERA Series ) June, 2008 Nano Chemical Inc. CEO : KIM Joo-Pyung ( CP : 82-10-2024-7176 ) TEL : 82-42-935-7176 , FAX : 82-42-935-7175 jpkim@nanoxides.com www.nanoxides.com

  2. Characteristics of CATCERA -. CATCERA : Ceramic Filter-Catalyst Composite -. Maximized Filtering Area with Variable Shapes -. High Reacting/Filtering Efficiency by 3-dimensional Tunnel Structure -. Excellent Porous Shape with Low Pressure Drop -. Excellent Chemical/Wear Resistance -. Controllable Porosity -. More Than 50% of Porosity to be Light Weight -. High Strength for High Temperature/Pressure -. Multi-Function in DeNOx SCR and Filter -. Ease of Backflushing -. Excellent Cost-Benefit -. Up to 2m Length [ Cross Section ] [ Side View ] [ Rectangular Shape ] [ Hollow Cylinder Shape ]

  3. Various Shape of CATCERA and Working Principle Punched Plate CATCERA Exhaust gas(N2 + NOx + Fly ash + SOx) Ammonia gas(NH3) Fly ash Purified exhaust gas(N2 + SOx) Air pulse Note : Composition of exhaust gas differs from the fuel. Normally N2 + O2 + H2O + NOx + (Fly ash) + (SOx) Normally the moral ratio of NOx and NH3 is 1 to 1.(NOx : NH3 = 1 : 1)

  4. N2 N2 N2 N2 H2O H2O H2O H2O H2O H2O SCR DeNOx Principle SCR SCR 4NO + 4NH3 + O2 4N2 + 6H2O NO + NO2 + 2NH3 2N2 + 3H2O NH3 Temperature ~350oC ~350oC NH3 NOx NOx CATCERA NH3 NOx Purified Gas Exhaust Gas NOx NH3 NOx NOx NH3 NOx NOx Honeycomb Catalyst Corrugate Catalyst

  5. CATCERA SCR Selective Catalytic Reduction (SCR) • Mechanism : Using same mole concentration with NH3 Specialty of NCI’s Product • High Temperature Stability : up to 1,000oF • Rutile phase synthesis on low temp. less then 200oF CATCERA(Ceramic Filter-SCR Catalyst Composite) • Pore Size : ~ PM10(up to 10 microns) • High Porosity : ~90% • Relatively Low Cost : Comparable teflon bag filter • Variable Shape • Substitutable Honeycomb with using SCR Catalyst • Pressure Drop : Up to 10cmH2O @ 10cm3/sec/cm2 air DPF/DOC • Soot Removal by Direct Catalytic Oxidation • Relatively Low Cost • Variable Shape • Simultaneous Removal of Soot and NOx

  6. Applicable Area of CATCERA • CATCERA is useful(or effective) on nearly all high temperature processes where the hot gas may contain smoke, fume or dust. It covers a broad range of application including; • Pre-Purification of CO2 removal system • Waste incineration • Thermal power plant, Coal-fired power plant • IGCC(Integrated Gasification Combined Cycle) • Pyrolysis • Chemical processing • Metals smelting • Glass melting • Industrial boiler • Cement plant • Diesel exhaust emission control facility • Dust collector, Soot collector CATCERA

  7. Comparison between CATCERA and Honeycomb/Corrugate – Operating Principle • Notes: • Composition of exhaust gas differs from fuel types. • Ammonia concentration is higher than regulation, and NOx conversion ratio will be up to 85%. Because of fly ash, surface of honeycomb/corrugate is covered by alkaline oxides such as CaO, MgO, etc in one year to degrade SCR catalytic function for coal fire boilers. • Ammonia is oxidized to NOx. • Lower ammonia concentration increases NOx Concentration. • Ammonia concentration is lower than regulation, fly ash is captured by CATCERA and NOx conversion ratio will be up to 98%.

  8. Comparison between CATCERA and Honeycomb/Corrugate – Iron Mill Honeycomb/Corrugate Catalyst CATCERA

  9. Comparison between CATCERA and Honeycomb/Corrugate – Incinerator Honeycomb/Corrugate Catalyst CATCERA

  10. Comparison between CATCERA and Honeycomb/Corrugate – Power Plant – DeSOx - Wet AIR FUEL HEAT EXCH. 110℃ 80℃ 350℃ EP FGD Duct Burner SCR BOILER 155℃ 450℃ Honeycomb/Corrugate Catalyst AIR HEAT EXCH. FGD BOILER CATCERA 110℃ 250℃ -450℃ CATCERA

  11. Comparison between CATCERA and Honeycomb/Corrugate – Power Plant – DeSOx – Dry/SemiDry AIR HEAT EXCH. BAG FILTER BOILER FGD CYCLONE SCR 370℃ 350℃ (SEMI) DRY Honeycomb/Corrugate Catalyst AIR HEAT EXCH. BOILER FGD CATCERA 270℃ -400℃ 250℃ -380℃ (SEMI) DRY CATCERA

  12. Benefit of CATCERA Technology Inorganic Binder : High Temperature SCR Coating Binder Technology Coating Technology : On Ceramic Filter High Temperature SCR Catalyst : Rutile Phase TiO2 Manufacturing Technology Applicable to gas turbine complex power plant DPF/DOC/Ceramic Filter : Manufacturing Technology for Soot/DeNOx from Diesel Flu Gas

  13. CATCERA Manufacturing Procedure A B C D V2O5-WO3/TiO2 Coated Ceramic Filter A: Ceramic Filter B:Coated 1 Time C: Coated 2 Times D: Coated 3 Times

  14. CATCERA Testing Part

  15. CATCERA Testing Facility Schematics NO2 SO2 H2O

  16. SCR Testing Facility and Powder Powder Changes with Calcination Temperature

  17. Test Result Depending on SV NO : 500ppm, NOx:NH3=1:1, O2:3.0%

  18. Test Result Depending on SCR Catalyst Test Condition SV=40,000h-1

  19. Comparison between Ceramic Filters
