  1. MPI Program Structure

  2. Topics • This chapter introduces the basic structure of an MPI program. After sketching this structure using a generic pseudo-code, specific program elements are described in detail for C. These include • Header files • MPI naming conventions • MPI routines and return values • MPI handles • MPI data types • Initializing and terminating MPI • Communicators • Getting communicator information: rank and size

  3. Generic MPI Program

  4. A Generic MPI Program • All MPI programs have the following general structure: include MPI header file variable declarations initialize the MPI environment ...do computation and MPI communication calls... close MPI communications

  5. MPI include file #include <mpi.h> void main (int argc, char *argv[]) { int np, rank, ierr; ierr = MPI_Init(&argc, &argv); MPI_Comm_rank(MPI_COMM_WORLD,&rank); MPI_Comm_size(MPI_COMM_WORLD,&np); /* Do Some Works */ ierr = MPI_Finalize(); } #include <mpi.h> void main (int argc, char *argv[]) { int np, rank, ierr; ierr = MPI_Init(&argc, &argv); MPI_Comm_rank(MPI_COMM_WORLD,&rank); MPI_Comm_size(MPI_COMM_WORLD,&np); /* Do Some Works */ ierr = MPI_Finalize(); } #include <mpi.h> void main (int argc, char *argv[]) { int np, rank, ierr; ierr = MPI_Init(&argc, &argv); MPI_Comm_rank(MPI_COMM_WORLD,&rank); MPI_Comm_size(MPI_COMM_WORLD,&np); /* Do Some Works */ ierr = MPI_Finalize(); } variable declarations #include <mpi.h> void main (int argc, char *argv[]) { int np, rank, ierr; ierr = MPI_Init(&argc, &argv); MPI_Comm_rank(MPI_COMM_WORLD,&rank); MPI_Comm_size(MPI_COMM_WORLD,&np); /* Do Some Works */ ierr = MPI_Finalize(); } #include <mpi.h> void main (int argc, char *argv[]) { int np, rank, ierr; ierr = MPI_Init(&argc, &argv); MPI_Comm_rank(MPI_COMM_WORLD,&rank); MPI_Comm_size(MPI_COMM_WORLD,&np); /* Do Some Works */ ierr = MPI_Finalize(); } Initialize MPI environment Do work and make message passing calls Terminate MPI Environment General MPI Program Structure

  6. A Generic MPI Program • The MPI header file contains MPI-specific definitions and function prototypes. • Then, following the variable declarations, each process calls an MPI routine that initializes the message passing environment. All calls to MPI communication routines must come after this initialization. • Finally, before the program ends, each process must call a routine that terminates MPI. No MPI routines may be called after the termination routine is called. Note that if any process does not reach this point during execution, the program will appear to hang.

  7. MPI Header Files

  8. MPI Header Files • MPI header files contain the prototypes for MPI functions/subroutines, as well as definitions of macros, special constants, and data types used by MPI. An appropriate "include" statement must appear in any source file that contains MPI function calls or constants. #include <mpi.h>

  9. MPI Naming Conventions

  10. MPI Naming Conventions • The names of all MPI entities (routines, constants, types, etc.) begin with MPI_ to avoid conflicts. • C function names have a mixed case: MPI_Xxxxx(parameter, ... ) Example: MPI_Init(&argc, &argv). • The names of MPI constants are all upper case in both C and Fortran, for example, MPI_COMM_WORLD, MPI_REAL, ... • In C, specially defined types correspond to many MPI entities. (In Fortran these are all integers.) Type names follow the C function naming convention above; for example, MPI_Comm • is the type corresponding to an MPI "communicator".

  11. MPI Routines and Return Values

  12. MPI Routines and Return Values • MPI routines are implemented as functions in C. In either case generally an error code is returned, enabling you to test for the successful operation of the routine. • In C, MPI functions return an int, which indicates the exit status of the call. int ierr; ... ierr = MPI_Init(&argc, &argv); ...

  13. MPI Routines and Return Values • The error code returned is MPI_SUCCESS if the routine ran successfully (that is, the integer returned is equal to the pre-defined integer constant MPI_SUCCESS). Thus, you can test for successful operation with if (ierr == MPI_SUCCESS) { ...routine ran correctly... } • If an error occurred, then the integer returned has an implementation-dependent value indicating the specific error.

  14. MPI Handles

  15. MPI Handles • MPI defines and maintains its own internal data structures related to communication, etc. You reference these data structures through handles. Handles are returned by various MPI calls and may be used as arguments in other MPI calls. • In C, handles are pointers to specially defined datatypes (created via the C typedef mechanism). Arrays are indexed starting at 0. • Examples: • MPI_SUCCESS - An integer. Used to test error codes. • MPI_COMM_WORLD - In C, an object of type MPI_Comm (a "communicator"); it represents a pre-defined communicator consisting of all processors. • Handles may be copied using the standard assignment operation.

  16. MPI Datatypes

  17. MPI Datatypes • MPI provides its own reference data types corresponding to the various elementary data types in C. • MPI allows automatic translation between representations in a heterogeneous environment. • As a general rule, the MPI datatype given in a receive must match the MPI datatype specified in the send. • In addition, MPI allows you to define arbitrary data types built from the basic types.

  18. Basic MPI Datatypes - C

  19. Basic MPI Data Types

  20. Basic MPI Data Types

  21. Special MPI Datatypes (C)

  22. Special MPI Datatypes (C) • In C, MPI provides several special datatypes (structures). Examples include • MPI_Comm - a communicator • MPI_Status - a structure containing several pieces of status information for MPI calls • MPI_Datatype • These are used in variable declarations, for example, MPI_Comm some_comm; • declares a variable called some_comm, which is of type MPI_Comm (i.e. a communicator).

  23. Initializing MPI

  24. Initializing MPI • The first MPI routine called in any MPI program must be the initialization routine MPI_INIT. This routine establishes the MPI environment, returning an error code if there is a problem. int ierr; ... ierr = MPI_Init(&argc, &argv); • Note that the arguments to MPI_Init are the addresses of argc and argv, the variables that contain the command-line arguments for the program.

  25. Communicators

  26. 1 3 dest 4 0 2 source 5 Communicator Communicators • A communicator is a handle representing a group of processors that can communicate with one another. • The communicator name is required as an argument to all point-to-point and collective operations. • The communicator specified in the send and receive calls must agree for communication to take place. • Processors can communicate only if they share a communicator.

  27. Communicators • There can be many communicators, and a given processor can be a member of a number of different communicators. Within each communicator, processors are numbered consecutively (starting at 0). This identifying number is known as the rank of the processor in that communicator. • The rank is also used to specify the source and destination in send and receive calls. • If a processor belongs to more than one communicator, its rank in each can (and usually will) be different!

  28. 4 1 2 Comm1 0 5 0 Comm2 1 1 3 6 2 3 0 2 MPI_COMM_WORLD Communicators • MPI automatically provides a basic communicator called MPI_COMM_WORLD. It is the communicator consisting of all processors. Using MPI_COMM_WORLD, every processor can communicate with every other processor. You can define additional communicators consisting of subsets of the available processors. • Communicator: • MPI_COMM_WORLD • Comm1 • Comm2

  29. Getting Communicator Information: Rank • A processor can determine its rank in a communicator with a call to MPI_COMM_RANK. • Remember: ranks are consecutive and start with 0. • A given processor may have different ranks in the various communicators to which it belongs. int MPI_Comm_rank(MPI_Comm comm, int *rank); • The argument comm is a variable of type MPI_Comm, a communicator. For example, you could use MPI_COMM_WORLD here. Alternatively, you could pass the name of another communicator you have defined elsewhere. Such a variable would be declared as MPI_Comm some_comm; • Note that the second argument is the address of the integer variable rank.

  30. Getting Communicator Information: Size • A processor can also determine the size, or number of processors, of any communicator to which it belongs with a call to MPI_COMM_SIZE. int MPI_Comm_size(MPI_Comm comm, int *size); • The argument comm is of type MPI_Comm, a communicator. • Note that the second argument is the address of the integer variable size. • MPI_Comm_size(MPI_COMM_WORLD, &size);  size =7 • MPI_Comm_size(Comm1, &size1);  size1=4 • MPI_Comm_size(Comm2, &size2);  size2=3

  31. Terminating MPI

  32. Terminating MPI • The last MPI routine called should be MPI_FINALIZE which • cleans up all MPI data structures, cancels operations that never completed, etc. • must be called by all processes; if any one process does not reach this statement, the program will appear to hang. • Once MPI_FINALIZE has been called, no other MPI routines (including MPI_INIT) may be called. int err; ... err = MPI_Finalize();

  33. Hello World!

  34. Sample Program: Hello World! • In this modified version of the "Hello World" program, each processor prints its rank as well as the total number of processors in the communicator MPI_COMM_WORLD. • Notes: • Makes use of the pre-defined communicator MPI_COMM_WORLD. • Not testing for error status of routines!

  35. Sample Program: Hello World! #include <stdio.h> #include <mpi.h> void main (int argc, char *argv[]) { int myrank, size; /* Initialize MPI */ MPI_Init(&argc, &argv); /* Get my rank */ MPI_Comm_rank(MPI_COMM_WORLD, &myrank); /* Get the total number of processors */ MPI_Comm_size(MPI_COMM_WORLD, &size); printf("Processor %d of %d: Hello World!\n", myrank, size); MPI_Finalize(); /* Terminate MPI */ }

  36. Sample Program Output

  37. Sample Program: Output • Running this code on four processors will produce a result like: Processor 2 of 4: Hello World! Processor 1 of 4: Hello World! Processor 3 of 4: Hello World! Processor 0 of 4: Hello World! • Each processor executes the same code, including probing for its rank and size and printing the string. • The order of the printed lines is essentially random! • There is no intrinsic synchronization of operations on different processors. • Each time the code is run, the order of the output lines may change.

  38. END
