Best Practices for Building Web Services with Visual Studio ® .NET

1. Best Practices for Building Web Services withVisual Studio® .NET Sanguan Thammarojsakul Microsoft MVP - .NET Department of Computer Science, Faculty of Science and Technology Assumption University of Thailand

2. What we will cover • ASP .NET Web Services • ACT • SOAP Security • Global XML Web Services Architecture (GXA) • scalability, interoperability, reliability, and security

3. Session Prerequisites • Familiarity with .NET Programming • Know Visual Basic® .NET • Familiar with ASP .NET Level 300

4. Agenda • Architecture of Web Services • Testing Web Services • Securing SOAP • Web Services in the Enterprise

5. Architecture of Web ServicesOpen Middle Tier Implementation • What is a Web Service? • A website without the user interface • A method for defining interfaces above the transport protocol • XML Interoperability • Web Services support 4 protocols • Http Get - Interoperable • Http Post - Interoperable • Http SOAP - Interoperable • Import as a DLL for an object interface - .NET

6. Architecture of Web Services Implementing XML Services • <WebService(Namespace := "http://msdn.microsoft.com/DevT1-46")> • Declares the interface, indicates that the class defined is a web service • Inherits System.Web.Services.WebService • Parent class for all web services in .NET • <WebMethod()> • Each method which is exposed as part of the service. • Return values can be supported in any request format but Output parameters are only supported in SOAP

7. Architecture of Web ServicesService Discovery • UDDI: Universal Description, Discovery and Integration • Design time specification for the discovery of services and communication of their interface • Does not define the service implementation and protocol details. • Complemented by WSDL • Managed by an industry-wide consortium; for details visit http://uddi.org

8. Agenda • Architectureof Web Services • Testing Web Services • Securing SOAP • Web Services in the Enterprise

9. Testing Web ServicesDefault ASMX Pages • Visual Studio creates a default test frame for each web service • Accessible from the <service>.asmx page • The automated page only supports and test the http Get protocol • Can act as the starting point for both functional and performance testing

10. Testing Web Services Performance Testing • Application Center Test • Allows for the automated execution of web based resources using VB Scripts • Two versions • Full version in Application Center Server • Developer Version in Visual Studio .NET Enterprise Architect edition • Produces XML based results • Supports Side by Side Comparison • Integrated with Performance Counters for collection of Transaction Cost Analysis data

11. Testing Web Services Transaction Cost Analysis Transaction Cost Analysis Equation Cycles = N * S * avg (Pt) / avg(Rps) Where: • N = Number of Processors • S = Speed of Processors • Pt = System: % Total Processor Time • Rps = ACT ASP Requests per second • Cycles = Average CPU cycles

12. Demonstration 1Transaction Calculator ServiceRun the T_Calc ServiceCreate a Simple ACT TestRun a Custom ACT Test

13. Agenda • Architecture of Web Services • Testing Web Services • Securing SOAP • Web Services in the Enterprise

14. Securing SOAPAuthentication & SSL • Authentication is supported • Selected from Internet Services Manager • NTLM and Basic authentication are available • Use: New Net.NetworkCredential() • Authentication does not protect data • To protect data can use SSL • From Browser preface call with https:// • From Code modify <service>.url property to include https:// • Https is transport specific

15. Securing SOAPEncoding & Encryption • UTF-8 Encoding • Can be used for the contents of a SOAP Message • Allows for the inclusion of binary data • Encryption • .NET supports several forms of encryption • Can be used to protect data without relying on transport protocol • Requires key synchronization

16. Demonstration 2Authentication/SecurityCreate a service requiring AuthenticationCreate a Windows Form ClientCall a Service that Encodes response Data

17. Agenda • Architecture of Web Services • Testing Web Services • Securing SOAP • Web Services in the Enterprise

18. Web Services in the EnterpriseMessaging Infrastructure • Global XML Services Architecture (GXA) • GXA has four key specifications to date • WS-Security • Credential exchange, message integrity, and message confidentiality • WS-License • Encoding for common license formats

19. Web Services in the EnterpriseMessaging Infrastructure • WS-Referral • Partition URL namespaces between nodes • WS-Routing • Route messages across intermediate SOAP nodes • GXA is still under development as an industry wide standard. • Other specifications may be added as the standard develops.

20. Web Services in the EnterpriseSOAP Extensions • SOAP Extensions • Added to the SOAP envelope • Provide a generic means of implementing additional capabilities. • .NET SoapExtension • System.Web.Services.Protocols.SoapExtension • Will be the core of implementing GXA

21. Session Summary • Use Web Services as Middleware • Use ACT for lifecycle testing support • Use .NET’s built in mechanisms for securing web services • SOAP Extensions
