  1. DBI409 SQL Server Columnstore Performance Tuning Eric N Hanson Principal Program Manager Microsoft Corporation

  2. Session Objectives and Takeaways • Session Objective(s): • Learn to make query performance go from good to outstanding • Batch mode is crucial to speedups • Good application design can work around limits

  3. Why pay attention? Your customer with well-tuned xVelocitycolumnstoreapplication Your customer with poorly-tuned xVelocitycolumnstoreapplication

  4. demo Outer Join Performance Limit

  5. Fundamentals of xVelocityColumnstore Performance • Each column stored separately, compressed • Batch mode query execution • Segment elimination

  6. Columnstore physical structure segment 1 • Segment (a.k.a. row group) = 1 million rows • Table partition has 1 or more segments • Each column segment is a BLOB • Dictionaries are BLOBs • Catalog has one row per column segment with min/max values catalog … dictionaries segment N

  7. Batch vs. Row Mode

  8. Batch mode processing • Process ~1000 rows at a time • Batch stored in vector form • Vector operators implemented • Filter, hash join, hash aggregation • Greatly reduced CPU time (7 to 40X) Batch object Column vectors bitmap of qualifying rows

  9. #1 Takeaway! Make sure most of the work of the query happens in batch mode.

  10. Segment Elimination • Segment(rowgroup)= 1 million row chunk • Min, Max kept for each column in a segment • Scans can skip segments based on this select Date, count(*) from dbo.Purchasewhere Date >= 20120201 group by Date skipped

  11. DOs • Use star schema • Put columnstores on large tables only • Include every column of table in columnstore index • Use integer surrogate keys for joins • Structure your queries as star joins with grouping and aggregation as much as possible

  12. DON’T • Join on string columns • Filter on string columns of columnstore table • Join pairs of very large tables if you don’t have to • Use NOT IN <subquery> on columnstore table • Use UNION ALL to combine columnstore tables with other tables

  13. Outer Join Workaround • Outer join prevents batch processing • Rewrite query to do most work in batch mode  DEMO

  14. IN and EXISTs Issue & Workaround • Using IN and EXISTS with subqueries can prevent batch mode execution • IN ( <list of constants> ) typically works fine •  DEMO

  15. Union All Issue & Workaround • UNION ALL often prevents batch mode • Workaround • Push GROUP BY and aggregation over UNION ALL • Do final GROUP BY and aggregation of results • Called “local-global aggregation” •  DEMO

  16. Scalar Aggregates Issue & Workaround • Aggregate without group by doesn’t get batch processing • select count(*) from dbo.Purchase1.2 seconds • Workaround • with CountByDate (Date, c) 0.093 secondsas ( select Date, count(*) from dbo.Purchasegroup by Date ) select sum(c) from CountByDate;

  17. Multiple DISTINCT aggregates issue & workaround • Table Spool if query has 2 or more DISTINCT aggregates • Spool takes time to write • Spool write is single threaded • Reads of spool in plan are single threaded, in row mode • Workaround: • form each DISTINCT agg in separate subquery • Join results on grouping keys •  DEMO SQL Server 2012 runs queries with 1 DISTINCT agg and 1 or more non-distinct aggs in batch mode without any spool!

  18. Physical DB Design, Loading, and Index Management

  19. Adding Data Using Partition Switching • Columnstores must be partition-aligned • Partition switching fully supported • To add data daily • Partition by day • Every day • Split last partition • Create staging table and columnstore index it • Switch it in • Avoids costly drop/rebuild

  20. Trickle Loading with Columnstore Indexes • Master table (columnstore) • Delta table (rowstore) • Query using UNION ALL local-global aggregation workaround • Add Delta to Master nightly •  DEMO

  21. Avoid Nonclustered B-trees • Covering B-trees no longer needed • Extra B-trees can cause optimizer to choose poor plan • Save space • Reduce ETL time

  22. Eliminating Unsupported Data Types • Omit column, or • Modify column type to supported type • Reduce precision of numerics to 18 digits or less • Convert guid’s to ints • Reduce precision of datetimeoffset to 2 or less • Convert hierarchyid to int or string

  23. Achieving Fast Columnstore Index Builds • One thread per segment • Low memory throttles parallelism • Consider • high min server memory setting • Set REQUEST_MAX_MEMORY_GRANT_PERCENT to 50 or more • Add memory • Omit columns • Normalize fact columns to dimensions • Vertically partition • sys.dm_exec_query_memory_grants shows DOP

  24. Not enough memory to build a columnstore index? • Same ideas apply as for achieving fast builds • Run out of memory during execution, not startup? • Errors 701 or 802 indicate this • Workaround: reduce DOP explicitly, e.g. • create columnstore index <name> on <table>(<columns>) with(maxdop= 1);

  25. Maximizing the Benefits of Segment Elimination

  26. Verifying Segment Elimination • You may want to check if segments are eliminated • Ways to get segment elimination confirmation: • Xevent sqlserver.column_store_segment_eliminate • Text output messages • Trace flag 646 outputs segment elimination messages • Trace flag 3605 directs messages to error log file •  DEMO

  27. Ensuring segment elimination by date • Use clustered B-tree on date • Columnstore inherits order • Or, partition by date • Ordering by load date, ship date, order date etc. can all work • Dates are naturally correlated

  28. Partitioning and Segment Elimination -- Example Select … From Fact Where Date = 20120301

  29. Multi-dimensional segment elimination • Pre-sort or partition on a keydrawn from >1 dimension • E.g. YYYYMMRR • Can be persisted computed columnnot used in columnstore select f.region_id, avg(f.duration)from fact_CDR f where f.region_id = 1 and f.date_id between 20120101 and 20120131 group by f.region_id

  30. Additional Tuning Considerations

  31. String performance issues • String filters don’t get pushed to storage engine • more batches to process • defeats segment elimination • Joining on string columns is slow • Factor strings out to dimensions

  32. Forcing use or non-use of Columnstores • Query hint • OPTION(IGNORE_NONCLUSTERED_COLUMNSTORE_INDEX) • Index hint • … FROM F WITH(index=MyColumnStore) … • … FROM F WITH(index=MyClusteredBtree) …

  33. Summary • Key’s to fast processing • Batch mode • Segment elimination • Make sure most work is done in batch mode! • Can work around read-only property by • Partitioning • Using Delta-file for trickle load • Future work will reduce need for tuning

  34. Related Content • Columnstore Tuning Guide (your reading homework ) • http://social.technet.microsoft.com/wiki/contents/articles/sql-server-columnstore-performance-tuning.aspx • Columnstore FAQ • http://social.technet.microsoft.com/wiki/contents/articles/sql-server-columnstore-index-faq.aspx • Introductory Columnstores Talk Video • TechEd 2011 session DBI312 • Customer Case Studies • See list in FAQ
