  1. Characterizing the Structure of Bacteriogenic Uranium Oxides • Jonathan Stahlman, Carnegie Mellon University • John Bargar, Stanford Linear Accelerator Center • Eleanor Schofield, Stanford Linear Accelerator Center

  2. Outline • Motivation • Overall project • This summer’s work • Final results

  3. A BIG Problem • Our Cold War Legacy: • 1.7 trillion gallons of contaminated groundwater • 40 million m3 of contaminated soils • 3 million m3 of buried waste • Contaminants: radionuclides, metals, hydrocarbons How do we manage these threats?

  4. O2 2 e- One Possible Solution U(VI) Shewanella oneidensis MR-1 2 e- Nanoparticulate UO2 Uranium - green ; Oxygen - red

  5. Hypothesis • Incorporation of other cations present in groundwater into the UO2 structure will result in a more stable crystalline structure We will look at: Ca Mg Mn

  6. A Structured Approach • Ecole Polytechnique Fédérale de Lausanne (EPFL) • Sample preparation • Washington University in St. Louis • Dissolution studies • Stanford Synchrotron Radiation Laboratory • Structural studies (EXAFS, WAXS)

  7. This Summer’s Work • Wide angle x-ray scattering (WAXS) to examine lattice contraction • Experimental Setup • Compton Subtraction • Background Subtraction • Le Bail Fitting • Results a

  8. Wide Angle X-ray Scattering • Challenges: • Wet Samples • Radioactive Concerns • Anaerobic Conditions

  9. Raw Data

  10. 2Θ = 10° 2Θ = 120° Compton Subtraction • Compton - inelastically scattered x-rays • Can be easily separated at high angle due to difference in energy • Not true at lower angles

  11. Compton Fits 2Θ = 10° 2Θ = 120°

  12. Background Subtraction • XRD-BS: • Subtract the capillary reflections • Correct for absorption in the sample

  13. Le Bail Fitting • A derivative of the Rietveld Refinement • Used to extract the lattice constant • Parameters: Space Group, Particle Size, Background, Lattice Constant

  14. Magnesium Results Undoped Sample: 5.4307 ± .0016 Å 10 mM Mg Doped Sample: 5.4405 ± .0045 Å Sample pH: 8.0 Cleaning Method: NaOH

  15. Calcium Results Undoped Sample: 5.4437 ± .0029 Å 10 mM Ca Doped Sample: 5.4353 ± .0022 Å Sample pH: 6.0 Cleaning Method: NaOH

  16. Manganese Results Undoped Sample: 5.4331 ± .0016 Å Mn Doped Samples: .1 mM : 5.3956 ± .0061 Å 1 mM : 5.4387 ± .0016 Å 5 mM : 5.4018 ± .0022 Å Sample pH: 6.3 Cleaning Method: NaOH

  17. Cleaning Method Results No Dopants Added

  18. Conclusions • Possible lattice contraction in Mn samples • NaOH cleaning process is affecting the structure of bacteriogenic UO2 • Future Work: • Rietveld Refinement for more structural information • Possibly design new cleaning method

  19. Acknowledgments • Funding: • Department of Energy, SULI • Software: • Sam Webb: XRD-BS • A.C. Larson and R.B. Von Dreele: GSAS • B. H. Toby: EXPGUI • Nita Dragoe: Powder 4 • Other: • Apurva Mehta • John Bargar and Eleanor Schofield

  20. Summary • Long term sequestration of bacteriogenic UO2 depends on incorporation of cations • WAXS provides structural information about bacteriogenic UO2 samples • Le Bail fitting reveals: • Possible lattice contraction for Mn doped sample • NaOH cleaning method causing lattice contraction
