Presentation Transcript

  1. Computer Security Software

  2. Issues • Virus (anti virus scanners) • Intrusion-Detection Software • Firewalls • Configuration of firewalls

  3. Virus • Virus • Malware - need a host program/file to propagate • Trojan horse – concept • Well known • 1999: Melissa (email) • 2001: Klez (email) • Worm • Malware – make a copy and propagate by it self • Well known • 2000: ILOVEYOU (also email) • 2004 Sasser (also email) • http://computer.howstuffworks.com/worst-computer-viruses.htm#page=0

  4. More Virus • How scanners work • Recognize signature (file size, code, file name …)simple but work for known viruses • Detect suspicious behavior(write to boot sector, change system files, TSR)complex work for ‘unknown’ viruses • Problems to face • False positive (find virus – which is not a virus) • False negative (do not find a real virus)

  5. Intrusion-Detection Software • Different categories • Misuse (like recognize) • Anormal (behavior) • Passive (just detect - log) • Reactive (detect – log and block) • Network Based (look at network traffic) • Host based (look at one computer) • One Tool – SNORT (snort.org) • Honey pots

  6. Firewalls • Purpose of a Firewall • To allow ‘proper’ traffic and discard all other traffic • Characteristic of a firewall • All traffic must go through the firewall • Allow and blocking traffic (Only Authorized traffic) • The Firewall itself must be immune of attacked

  7. Firewalls what to configure • 5 areas to control: • Services (web, ftp, mail …) i.e. Port# • Network (hosts) i.e. IP addresses • Direction i.e. control inside-out or reverse • User i.e. only authorized users allow • Behaviour (e.g. attachment to mail) • (Denial of Service Inspection)

  8. Firewalls types • Screening Firewall • The normal built in packet filter firewall in routers • Application Gateway (OR application proxy) • Establish connection to gateway then a new connect out • Have user authentication BUT performance is bad • Circuit level gateway • Like application (two connections + authentication) • Better performance

  9. Firewall – ScreeningPacket-filtering • Level 3 – network (IP-packets) • Filtering on (the access control list): • Source/Destination IP-addresses • Source/Destination Port-numbers • IP-protocol field (e.g. icmp, tcp, egp) • TCP-direction (SYN-bit) • InBound / Outbound on each interface (sometimes also forwarding)

  10. Firewall – ScreeningPacket-filtering • Configurations • Policies: 1:optimistic: default set to allow / forward2:pessimistic: default set to discard / deny • Setting up rules

  11. Example IN OUT IN OUT

  12. Firewall – ScreeningPacket-filtering • Out 10.10.10.1 • In 10.10.10.1

  13. Firewall - Architecture • Best Practice solutionFor small and middle companies: • Screened subnet firewall MOST secure DMZ –demilitarized zone(2 packet-filter + bastion host on the net (DMZ) in between) • Home Firewalllike ZoneAlarm/ windows-firewall
