Presentation Transcript

  1. Hacking the Phantom by Team Reaper Jacob, Kyle, and Scott

  2. Agenda • Drone Overview • Security Overview • Hacking Plans • Hardening Options

  3. Drone Overview • Base Drone $479.00 • Dronefly.com • GoPro Hero 3 Black $399.99 • 64GB High Speed Micro SD $129.99 • Spare 2200 mAH Battery $27.00 • Complete Starter Package $1035.98

  4. Drone Features • Receiver Range • 1000m (.6 miles) • GPS • Accurate Within .8 m Vertical 2.5m Horizontal • Wind Compensation • Max Speed 10m/sec (22mph) • Payload • 1000grams (2.2 pounds)

  5. Drone Modifications • 2 axis Gimble • Zenmuse H3-2D $699 • More control and less Jelloing • Fatshark First Person Video • Can Transmit from GoPro • Live Flight View • Can record video from goggles • $299.99 • Motors • Blades • Batteries

  6. Drone Reactions • People oblivious • Turkey Police • Neighborhood Spying • Youtube

  7. Current Hacks • Unable to find documentation on attacking the drone’s wireless communication, only modifications

  8. Communications – High Level

  9. Communications – Protocol • 2.4 GHz Direct Sequence Spread Spectrum • Unlicensed ISM band (2.400 GHz to 2.483 GHz)

  10. Communications – Microcontroller • Atmel ATMEGA Microcontroller • Gives interface to wireless module for drone’s Master Controller

  11. Communications - Chip • Cypress CYRF6936 – WirelessUSB LP 2.4 GHz Radio SoC • Transmit power: up to +4 dBm • Receive sensitivity: up to -97 dBm • DSSS data rates up to 250 kbps, GFSK data rate of 1 Mbps • 98 different channels available

  12. Interface to Chip • 4 MHz Serial Peripheral Interface (SPI) • 4 pin serial communications protocol • SCK, MISO, MOSI, SS • Easily implemented (i.e. Raspberry Pi) • Used to configure and send data to CYRF6936 Cypress Semiconductor Corporation - Document #: 38-16015 Rev. *J – page 1

  13. Data Transmission Modes • GFSK (Gaussian frequency-shift keying) Mode • 1 Mbps, no DSSS • 8DR Mode • 8 bits per symbol transmitted • DDR Mode • 2 bits per symbol transmitted • SDR • 1 bit per symbol transmitted • Lower data rates reduce error rate

  14. Typical Packet Structure • GFSK and 8DR have a max payload of 40 bytes • DDR and SDR have a max payload of 16 bytes • Optional packet framing • SOP required in GFSK and 8DR, optional in DDR, not supported in SDR • If SOP enabled, length field required • Length field required in GFSK and 8DR modes • CRC 16 has a configurable seed Cypress Semiconductor Corporation - Document #: 38-16015 Rev. *J – page 5

  15. Potential Hacking Options • Targeted • Take over control • Interference • Area of Effect • Jamming the 2.4 GHz ISM frequency band

  16. Targeted Attack Plan: Prototyping • Items needed: • Two transceiver chips • Two breakout boards • Two sets of supporting circuitry • Prototype both with Raspberry Pi

  17. Prototyping Block Diagram

  18. Targeted Attack Plan: System Investigation • Use an oscilloscope to see SPI signals from microcontroller to receiver chip on the DJI Phantom • Determine how the CYRF6936 is configured for receiving data from the remote control • Mimic the receiver chip configuration on the prototype system • Stimulate remote control and see what actions on the remote control correspond to data payload content

  19. System Investigation Block Diagram

  20. Targeted Attack: Custom Control • Once we have an understanding of the packet payload and operating modes, we can simulate the remote control and send commands to the DJI Phantom • We should receive some sort of acknowledge at least, hopefully some data feedback.

  21. Targeted Attack: Field Trials • Use Raspberry Pi and CYRF6936 in transmit mode to interfere with existing communication between the remote control and DJI Phantom • Change operating modes • Send the DJI Phantom away, attempt to turn it off • Send malformed packet payloads and see how it behaves.

  22. Targeted Attack: Field Trial Block Diagram

  23. Potential Challenges • Payload data may be encrypted • Unlikely because of small microcontroller connected to CYRF6936 • Scoping out SPI configuration may take a while • Interference between Raspberry Pi and remote control may result in erratic and non-deterministic behavior. • Range of Raspberry Pi will be shorter than remote control due to decreased signal integrity. • If we were to build a custom PCB, we can overcome this and drastically increase the strength of the transmit signal with a power amplifier.

  24. Cost of Development • BOM: • 2x 12 MHz Crystal (~$10) • 2x CYRF6936 (~$10) • 2x Breakout Board (~$25) • 2x Antenna (~$5) • 2x Passives (~10$) • Total Cost ~$60 • Time to develop estimated at 40 hours

  25. Area of Effect: Jamming • Need a lot of power for a small radius of jamming (need to be close to operator) • Possible to jam 2.4 GHz frequency band • FCC violations, jamming 2.4 GHz band is illegal • When the GoPro transmits the video via 2.4GHz band, the DJI Phantom has erratic behavior and flies off • Would expect similar effect with jamming the transmitter

  26. Hardening • Encrypt packet payload • Requires more hardware, but possible • Get a transceiver that has a wider bandwidth (1 GHz – 10 GHz) and implements dynamic frequency hopping • May not exist, but if it does it probably violates FCC regulations

  27. References • http://www.dronefly.com • http://www.dji.com • http://www.cdc.gov/niosh/ershdb/EmergencyResponseCard_29750002.html • https://sites.google.com/site/mrdunk/interfacing-cypress-cyrf6936-to-avr-microcontrollers • http://www.cypress.com/?docID=30520 • https://sites.google.com/site/mrdunk/interfacing-cypress-cyrf6936-to-avr-microcontrollers • http://www.cypress.com/?docID=28606
