  1. Tof cal using 2000v mcp….

  2. 30116, 343nm, CEH old

  3. 30117, 707nm, Manuel new

  4. 802nm, 30118, CEH old

  5. 510nm, 30119, manuel

  6. 400nm, 30120, manuel

  7. 299nm, 30121, manuel

  8. 210nm, 30122, manuel

  9. 152nm, 30123, CEH old

  10. 99nm, 30124, manuel

  11. 60nm, 30125, ceh old

  12. 920nm, 30126, manuel

  13. 690nm, 30127, manuel

  14. Tuned heater bias to 36.5V, 0-1v aq scale

  15. 1.6ma emiss, 3.26 filcurrent, mcp=2050

  16. T=3bits…ignore this

  17. Choose threshold=2bits

  18. Loooks good

  19. Airbeam ok

  20. Flowrate = 0 standard closed =0.02Von baratron Flowrate=1.32 standard open =1.3V on baratron No change since ireland so no change to cal… NOTE: number reporting in standard = 278K 1013mB

  21. 300nm nh4no3, approx 2100h

  22. Filter runs….

  23. Ambient sampling, approx 2150
