Graph a Function Using Intercepts

Learn how to graph a function using x and y intercepts. Find the intercepts, plot the points, and connect them to graph the function.

davidethompson
Télécharger la présentation

Graph a Function Using Intercepts

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Lesson Menu Main Idea and New Vocabulary Example 1: Graph a Function Using Intercepts Example 2: Graph a Function Using Intercepts Example 3: Using Intercepts Example 4: Using Intercepts

  2. Graph a function using the x- and y-intercepts. • standard form • x-intercept Main Idea/Vocabulary

  3. Graph a Function Using Intercepts State the x- and y-intercepts of the function 2x − 3y = 6. Graph the function. Step 1Find the x-intercept. To find the x-intercept, let y = 0. 2x – 3y= 6 Write the equation. 2x – 3(0)= 6 Replace y with 0. 2x = 6 Simplify. x = 3 Divide each side by 2. The x-intercept is 3. Example 1

  4. Graph a Function Using Intercepts Step 2Find the y-intercept. To find the y-intercept, let x = 0. 2x– 3y = 6 Write the equation. 2(0)– 3y = 6 Replace x with 0. –3y = 6 Simplify. y = –2 Divide each side by –3. The y-intercept is –2. Example 1

  5. Graph a Function Using Intercepts Step 3Graph the points (3, 0) and (0, –2) on a coordinate plane. Then connect the points. Answer: Example 1

  6. A.x-intercept: 1; y-intercept: 4 B.x-intercept: –1; y-intercept: 4 C.x-intercept: 1; y-intercept: –4 D.x-intercept: –1; y-intercept: –4 State the x- and y-intercepts of the function –4x + y = 4. Graph the function. Example 1 CYP

  7. State the x- and y-intercepts of the function x + y = –3. Graph the function. Graph a Function Using Intercepts Step 1 Find the x- and y-intercepts. x-intercept y-intercept Example 2

  8. Graph a Function Using Intercepts The x-intercept is –6. The y-intercept is –3. Step 2Graph the points (–6, 0) and (0, –3) on a coordinate plane. Then connect the points. Answer: Example 2

  9. A.x-intercept: –4; y-intercept: 3 B.x-intercept: 4; y-intercept: 3 C.x-intercept: –3; y-intercept: 4 D.x-intercept: –3; y-intercept: –4 State the x- and y-intercepts of the function 3x – 4y = –12. Graph the function. Example 2 CYP

  10. Using Intercepts SCHOOL PLAY The drama department sold $1,260 worth of tickets to a play. Student tickets x cost $5 and adult tickets y cost $9. This can be represented by the function 5x + 9y = 1,260. Use the x- and y-intercepts to graph the function. x-intercept 5x + 9y= 1,260 5x + 9(0)= 1,260 5x = 1,260 x = 252 y-intercept 5x + 9y= 1,260 5(0)+ 9y= 1,260 9y = 1,260 y = 140 Example 3

  11. Using Intercepts Answer: The x-intercept is 252. The y-intercept is 140. Example 3

  12. A. C. B. D. MUSIC The Taylor family bought tickets to an outdoor concert by the school band. The cost of a student ticket is $3 and the cost of an adult ticket is $4. They spent a total of $36. This can be represented by the function 3x + 4y = 36. Use the x- and y-intercepts to graph the function. Example 3 CYP

  13. Using Intercepts SCHOOL PLAY The drama department sold $1,260 worth of tickets to a play. Student tickets x cost $5 and adult tickets y cost $9. This can be represented by the function 5x + 9y = 1,260. Interpret the x- and y-intercepts. Example 4

  14. Using Intercepts Answer: The x-intercept is the point (252, 0). This means that 252 student tickets and 0 adult tickets could be sold for the drama department to sell $1,260 worth of tickets. The y-intercept is the point (0, 140). This means that 0 student tickets and 140 adult tickets could be sold for them to sell $1,260 worth of tickets. Example 4

  15. MUSIC The Taylor family bought tickets to an outdoor concert. The cost of a student ticket is $3 and the cost of an adult ticket is $4. They spent a total of $36. This can be represented by the function 3x + 4y = 36. Which statement is true? A.The y-intercept is the point (12, 0). This means that 12 adult tickets and 0 student tickets could be sold for $36. B.The y-intercept is the point (9, 0). This means that 9 student tickets and 0 adult tickets could be sold for $36. C.The x-intercept is the point (9, 0). This means that 9 student tickets and 0 adult tickets could be sold for $36. D.The x-intercept is the point (12, 0). This means that 12 student tickets and 0 adult tickets could be sold for $36. Example 4 CYP
