Presentation Transcript

  1. Sqoop Installation Guide Lecturer : Prof. KyungbaekKim Presenter : ZubairAmjad

  2. Requirements • Hadoop • Sqoop • MySQL Server • JDBC driver

  3. Environment • Ubuntu 12.04 • Hadoop 1.0.3 • Sqoop1.4.4

  4. Hadoop Fully Distributed Mode

  5. Sqoop Installation • Download the sqoop-1.4.4.bin_hadoop-1.0.0.tar.gz file • ww.apache.org/dyn/closer.cgl/sqoop/1.4.4 • Unzip the tar file • sudotar -zxvfsqoop-1.4.4.bin_hadoop-1.0.0.tar.gz • Move sqoop-1.4.4.bin_hadoop-1.0.0 to sqoop • sudo mv sqoop1.4.4.bin_hadoop-1.0.0 sqoop • Create a directory sqoop in usr/lib • sudomkdir /usr/lib/sqoop • Go to the folder sqoopand copy files to /usr/lib/sqoop • sudo mv ./* /usr/lib/sqoop • Go to root directory and open bashrcfile • sudogedit ~/.bashrc • Add SQOOP_HOME variable • export SQOOP_HOME=/usr/lib/sqoop • export PATH=$PATH:$SQOOP_HOME/bin • Check sqoop installation • sqoop version

  6. MySQL Server • Install mysql server • sudo apt-get install mysql-server • Give appropriate username and password • Download mysql-connector-java-5.1.28-bin.jar and copy to /usr/lib/sqoop/lib • cp mysql-connnectpr-java-5.1.28-bin.jar /usr/lib/sqoop/lib/ • Login to mysql server • mysql -u root –p

  7. Create Database • Create a database • create database temp_db; • show databases; • Add a table in the database • use temp_db; • CREATE TABLE employee (id INT, name VARCHAR(20), email VARCHAR(20)); • Insert some rows using INSERT INTO • Grant privileges to root user • grant all privileges on *.* to root@IP IDENTIFIED BY ‘root’ WITH GRANT OPTION;

  8. Create Database

  9. Create Table

  10. Insert rows in table

  11. Grant Permissions

  12. Sqoop Import • Import the table from temp_db to HDFS • sqoop import -connect jdbc:mysql://localhost:3306/temp_db -username root -P -table employee –target-dir /sqoopOut –m 1

  13. Table Import

  14. HDFS

  15. Sqoop Export • Export data from HDFS to database table • Create a table in data base • CREATE TABLE stud1 (id INT, name VARCHAR(20)); • Export data in file stud to database • sqoopexport --connect jdbc:mysql://192.168.34.130/temp_db --username root -P --table stud1 -m 1 --export-dir /sqoopexport/stud

  16. Export

  17. Exported Table

  18. Thank you
