  1. BNL Database Services Update Database Readiness Workshop CERN, Geneva, Switzerland Yingzi(Iris) Wu, Yuri Smirnov February 6, 2006

  2. Outline • BNL Database Services • Readiness of LCG production service Yingzi(Iris) Wu, Yuri Smirnov (BNL)

  3. BNL Database Services • Oracle Database Service • FTS • 3D Project • MySQL database Service • PandaDB • PostgreSQL • dCache Yingzi(Iris) Wu, Yuri Smirnov (BNL)

  4. Oracle service in production • Backend database for FTS • Hardware • Xeon 2 CPU 3GHz, 2GB RAM, 200GB disk • Operating system • RHEL3 • Oracle server/DB • Oracle 10g (10.1.0.4) • Backup tool • Recovery Manager (RMAN) Yingzi(Iris) Wu, Yuri Smirnov (BNL)

  5. 3D Oracle streams test bed • Test bed for Oracle streams replication • Since Oct, 2005 • Hardware • Xeon 2 CPU 3GHz, 2GB RAM, 200GB disk • Operating system • RHEL3 • Orace server/DB • Oracle 10g (10.1.0.4) Yingzi(Iris) Wu, Yuri Smirnov (BNL)

  6. Readiness of LCG production Service • Hardware readiness– middle Dec, 2005 • 300 GB hard disk ( after mirrored) • Fiber channel • Operating System • RHEL3 • Oracle server/DB – early Jan, 2006 • Oracle 10g release 2 • 2 nodes Cluster • ASMlib 2.0 as the storage management system Yingzi(Iris) Wu, Yuri Smirnov (BNL)

  7. Plan • Application installation • Data replication from Tie0 to BNL via Oracle streams • Schedule ? Yingzi(Iris) Wu, Yuri Smirnov (BNL)

  8. ATLAS MySQL clusters at BNL Tier1 • MySQL clusters • Production dbpro • 2 nodes Xeon 2CPU 3GHz, 2GB RAM, 250GB disk, RHEL-4 • MySQL 4.1.14 • supports USATLAS PandaDB (production and distributed analysis) • uses NDB-technology (“in-memory” MySQL DataBase tables implementation) • special cluster-based daily backup (using management server ndb_mgm) Yingzi(Iris) Wu, Yuri Smirnov (BNL)

  9. Sample -Panda job error summary page Yingzi(Iris) Wu, Yuri Smirnov (BNL)

  10. ATLAS MySQL clusters at BNL Tier1 • MySQL clusters • Development adbpro • 4 nodes PIII 0.7GHz, 0.5GB RAM, 25GB disk, RHEL-4 • MySQL 4.1.14 (plans to test 5.X) • supports development version PandaDevDB • uses NDB-engine • daily backup for cluster (ndb_mgm based) Yingzi(Iris) Wu, Yuri Smirnov (BNL)

  11. ATLAS MySQL DataBase servers at BNL Tier1 • db1 supports production • ConditionsDB (IOV and payload), Geometry NOVA, DBs for subdetectors, VDC, DialDB, Terapaths DB • dbdevel1 • ATLASDD, MagdaFC • dbdevel2 • TAG DB (Oracle CERN replica), PandaArchiveDB • dms01 • RLS, DQ1 • dms02 • DQ2 DataBases and catalogs, LFC • gums • GUMS DB for OSG and LCG • vo • VOMS DB for OSG and LCG Yingzi(Iris) Wu, Yuri Smirnov (BNL)

  12. Q & A Yingzi(Iris) Wu, Yuri Smirnov (BNL)

  13. Thank you ! Yingzi(Iris) Wu, Yuri Smirnov (BNL)
