  1. Matt Klein Decorator Patternflyweight Pattern

  2. Decorator Pattern • Intent • Attach Additional responsibilities to an object by dynamically. Decorators provide a flexible alternative to subclassing for extending functionality. • AKA • Wrapper

  3. Decorator: Motivation • Desire to add responsibilities to individual objects • Two Approaches • Inheritance • Choices are made statically • Inflexible • Decorator • Dynamic • Unlimited in number of added responsibilities

  4. Decorator: Applicability • Use the Decorator Pattern… • To add responsibilities to individual objects dynamically and transparently • For responsibilities that can be withdrawn • When extension by subclassing is impractical

  5. Decorator: Participants • Component • Defines the interface for objects that can have responsibilities added to them dynamically • ConcreteComponent • Defines an object to which additional responsibilities can be attached

  6. Decorator: Participants • Decorator • Maintains a reference to a Component object and defines an interface that conforms to Component’s interface • ConcreteDecorator • Adds responsibilities to the component

  7. Decorator: Structure

  8. Decorator: Consequences • Good • More Flexibility than static inheritance • Much easier to use than multiple inheritance • Can be used to mix and match features • Can add the same property twice • Avoids feature laden classes high up in hierarchy • Allows to easily add new features incrementally

  9. Decorator: Consequences • Bad • A decorator and its component aren’t identical • From an object identity point of view, a decorated component is not identical to the component itself • Don’t rely on object identity when using decorators • Lots of little objects • Often end up with systems composed of lots of little objects • Can be hard to learn and debug

  10. Decorator: Implementation • Interface conformance • Decorator object’s interface must conform to the interface of the component it decorates • Omitting the abstract Decorator class • If you’re adding just one responsibility, there’s no need to have the abstract Decorator class

  11. Decorator: Implementation • Keeping Component classes lightweight • Component should stick to defining an interface • Changing the skin of an object vs. changing the guts • Strategy vs. Decorator

  12. Decorator: Related Patterns • Adapter • Provides new interface vs. changing responsibilities • Composite • Can be viewed as a degenerate composite with only one component • Strategy • Skin vs. Guts

  13. Flyweight Pattern • Intent • Use sharing to support large numbers of fine-grained objects efficiently

  14. Flyweight: Motivation • Can be used when an application could benefit from using objects throughout their design, but a naïve implementation would be prohibitively expensive • Objects for each character in a document editor • Cost is too great! • Can use flyweight to share characters

  15. Intrinsic vs. Extrinsic • Intrinsic • state is stored in the flyweight • Information that’s independent of the flyweight’s context • Shared • Extrinsic • State depends on and varies with the flyweight’s context • Cannot be shared

  16. Flyweight: Applicability • Use the Flyweight pattern when ALL of the following are true • An application uses a large number of objects • Storage costs are high because of the sheer quantity of objects • Most object state can be made extrinsic • Many Groups of objects may be replaced by relatively few shared objects once extrinsic state is removed • The application doesn’t depend on object identity

  17. Flyweight: Participants • Flyweight • Declares an interface through which flyweights can receive and act on extrinsic state • ConcreteFlyweight • Implements the Flyweight interface and adds storage for intrinsic state, if any • Must be shareable

  18. Flyweight: Participants • FlyweightFactory • Creates and manages flyweight objects • Ensures that flyweights are shared properly • Client • Maintains reference to flyweights • Computes or stores the extrinsic state of flyweights

  19. Flyweight: Structure

  20. Flyweight: Consequences • May introduce run-time costs associated with transferring, finding, and/or computing extrinsic state • Costs are offset by space savings

  21. Flyweight: Consequences • Storage savings are a function of the following factors: • The reduction in the total number of instances that comes from sharing • The amount of intrinsic state per object • Whether extrinsic state is computed or stored

  22. Flyweight: Consequences • Ideal situation • High number of shared flyweights • Objects use substantial quantities of both intrinsic and extrinsic state • Extrinsic state is computed

  23. Decorator: Implementation • Removing extrinsic state • Success of pattern depends on ability to remove extrinsic state from shared objects • No help if there are many different kinds of extrinsic state • Ideally, state is computed separately

  24. Flyweight: Implementation • Managing shared objects • Objects are shared so clients should not instantiate • FlyweightFactory is used to create and share objects • Garbage collection may not be necessary

  25. Flyweight: Related Patterns • Composite • Often combined with flyweight • Provides a logically hierarchical structure in terms of a directed-acyclic graph with shared leaf nodes • State and Strategy • Best implemented as flyweights
