  1. Edif. 01 Dep. 01 Edif. 04 Dep. 01 Edif. 04 Dep. 32 Edif. 04 Dep. 02 Edif. 03 Dep. 02 Edif. 03 Dep. 32 Edif. 01 Dep. 32 Edif. 01 Dep. 02 Edif. 01 Dep. 01 Edif. 02 Dep. 02 Edif. 02 Dep. 32 Edif. 02 Dep. 01 Edif. 03 Dep. 01 RS232 (15m max.) 12Vdc (150m max.) D-Net (RS485 1,200m max.) Usuario Final NC100 + - + - + - + - PS 12VDC 4A PS 12VDC 4A PS 12VDC 4A PS 12VDC 4A OPTOMUX-015ch OPTOMUX-02 Estación Central de Monitoreo Digital Dialer (SIA Format)KE-SDACT Receptor Digital (SurGuard / Ademco etc.) Formato SIA • 2499 teclados máx.. por sistema • 4 Zonas + 2 TTL + 1 Lector / Teclado120mA, 12Vdc • 8 usuarios por teclado Linea TelCo NC100 • 254 Teclados máx. por NC100 RS485 (1200m max.) Hasta 5 Canales, hasta 32 Teclados / canal120mA, 12Vdc OPTOMUX-015ch
