  1. Knowledge Engineering for Bayesian Networks Ann Nicholson School of Computer Science and Software Engineering Monash University

  2. Overview • Representing uncertainty • Introduction to Bayesian Networks • Syntax, semantics, examples • The knowledge engineering process • Case Studies • Seabreeze prediction • Intelligent Tutoring • Open research questions

  3. Sources of Uncertainty • Ignorance • Inexact observations • Non-determinism • AI representations • Probability theory • Dempster-Shafer • Fuzzy logic

  4. Probability theory for representing uncertainty • Assigns a numerical degree of belief between 0 and 1 to facts • e.g. “it will rain today” is T/F. • P(“it will rain today”) = 0.2 prior probability (unconditional) • Posterior probability (conditional) • P(“it wil rain today” | “rain is forecast”) = 0.8 • Bayes’ Rule: P(H|E) = P(E|H) x P(H) P(E)

  5. Bayesian networks • Directed acyclic graphs • Nodes: random variables, • R: “it is raining”, discrete values T/F • T: temperature, cts or discrete variable • C: colour, discrete values {red,blue,green} • Arcs indicate dependencies (can have causal interpretation)

  6. X Flu Y Te Q Th Bayesian networks • Conditional Probability Distribution (CPD) • Associated with each variable • probability of each state given parent states “Jane has the flu” P(Flu=T) = 0.05 Models causal relationship “Jane has a high temp” P(Te=High|Flu=T) = 0.4 P(Te=High|Flu=F) = 0.01 Models possible sensor error “Thermometer temp reading” P(Th=High|Te=H) = 0.95 P(Th=High|Te=L) = 0.1

  7. Flu Flu TB Flu Flu Y Te Te Te Y Te Th Th Th Diagnostic inference Causal inference Mixed inference Intercausal inference BN inference • Evidence: observation of specific state • Task: compute the posterior probabilities for query node(s) given evidence. Flu

  8. BN software • Commerical packages: Netica, Hugin, Analytica (all with demo versions) • Free software: Smile, Genie, JavaBayes, … http://HTTP.CS.Berkeley.EDU/~murphyk/Bayes/bnsoft.html • Examples

  9. Decision networks • Extension to basic BN for decision making • Decision nodes • Utility nodes • EU(Action) =  p(o|Action,E) U(o) o • choose action with highest expect utility • Example

  10. Elicitation from experts • Variables • important variables? values/states? • Structure • causal relationships? • dependencies/independencies? • Parameters (probabilities) • quantify relationships and interactions? • Preferences (utilities)

  11. BN EXPERT Domain EXPERT BN TOOLS Expert Elicitation Process • These stages are done iteratively • Stops when further expert input is no longer cost effective • Process is difficult and time consuming. • Current BN tools • inference engine • GUI • Next generation of BN tools?

  12. Knowledge discovery • There is much interest in automated methods for learning BNS from data • parameters, structure (causal discovery) • Computationally complex problem, so current methods have practical limitations • e.g. limit number of states, require variable ordering constraints, do not specify all arc directions • Evaluation methods

  13. The knowledge engineering process 1. Building the BN • variables, structure, parameters, preferences • combination of expert elicitation and knowledge discovery 2. Validation/Evaluation • case-based, sensitivity analysis, accuracy testing 3. Field Testing • alpha/beta testing, acceptance testing 4. Industrial Use • collection of statistics 5. Refinement • Updating procedures, regression testing

  14. Case Study: Intelligent tutoring • Tutoring domain: primary and secondary school students’ misconceptions about decimals • Based on Decimal Comparison Test (DCT) • student asked to choose the larger of pairs of decimals • different types of pairs reveal different misconceptions • ITS System involves computer games involving decimals • This research also looks at a combination of expert elicitation and automated methods

  15. Expert classification of Decimal Comparison Test (DCT) results

  16. The ITS architecture Adaptive Bayesian Network Inputs Student Generic BN model of student Decimal comparison test (optional) Item Answers Answer • Diagnose misconception • Predict outcomes • Identify most useful information Information about student e.g. age (optional) Computer Games Hidden number Answer Classroom diagnostic test results (optional) Feedback Answer Flying photographer • Select next item type • Decide to present help • Decide change to new game • Identify when expertise gained System Controller Module Item type Item Decimaliens New game Sequencing tactics Number between Help Help …. Report on student Classroom Teaching Activities Teacher

  17. Expert Elicitation • Variables • two classification nodes: fine and coarse (mut. ex.) • item types: (i) H/M/L (ii) 0-N • Structure • arcs from classification to item type • item types independent given classification • Parameters • careless mistake (3 different values) • expert ignorance: - in table (uniform distribution)

  18. Expert Elicited BN

  19. Evaluation process • Case-based evaluation • experts checked individual cases • sometimes, if prior was low, ‘true’ classification did not have highest posterior (but usually had biggest change in ratio) • Adaptiveness evaluation • priors changes after each set of evidence • Comparison evaluation • Differences in classification between BN and expert rule • Differences in predictions between different BNs

  20. Comparison evaluation • Development of measure: same classification, desirable and undesirable re-classification • Use item type predictions • Investigation of effect of item type granularity and probability of careless mistake

  21. Investigation by Automated methods • Classification (using SNOB program, based on MML) • Parameters • Structure (using CaMML)

  22. Results

  23. Case Study: Seabreeze prediction • 2000 Honours project, joint with Bureau of Meteorology (PAKDD’2001 paper, TR) • BN network built based on existing simple expert rule • Several years data available for Sydney seabreezes • CaMML and Tetrad-II programs used to learn BNs from data • Comparative analysis showed automated methods gave improved predictions.

  24. Open Research Questions • Tools needed to support expert elicitation • Combining expert elicitation and automated methods • Evaluation measures and methods • Industry adoption of BN technology
