  1. Escuadra de combinación Julian Sucerquia Mijalis Papadopulos

  2. Escuadra combinada • Básicamente la escuadra combinadaconsiste en una lámina o regla que lleva montados una serie de accesorios útiles intercambiables, denominados cabezales, que pueden desplazarse libremente a lo largo de la regla por medio de una ranura ubicada en el centro de la regla. Existen tres tipos de cabezales diferentes,

  3. Usos de la escuadra para medir eldiámetro de un cilindro

  4. Uso de la escuadra paradetErminar Profundidad

  5. Uso de la escuadra paradeterminar un ángulo
