ModuleHub ::A quick overview Carlo del Mundo 8-16-2011
Architecture • Director • Finite state machine • Controls autonomous decisions • Controlled by Lua scripts • States triggered by timeout or variables • Controls • Simulink Module • Movement algorithms • Reads sensor input • Outputs thruster data • Actuators • Reads thruster data and mechanism states • Sends serial commands to output devices • Vision • Simulink Module • Relays algorithm information to state data • Software Abstraction Layer (SAL) • Initializes and monitors hardware • Sends data to State Data SAL, Director, Vision, Controls, and Actuators are modules Cameras State Data Director SAL Maestro Micro-Strain OS-5000 Actuators Vision Controls Thrusters Mechanisms
Definitions • ModuleHub • A centralized location where modules are aggregated; the “controller” • Module • The smallest unit that performs some task Module Hub Director Controllers Vision
Current Responsibilities • “Pseudo” Publish-Subscribe Pattern (Observer Pattern) Module Hub (Controller) New Data (ex: isFire = 1) Vision Director State Data (Model)
Correct Responsibility • “Pseudo” Publish-Subscribe Pattern (Observer Pattern) Module Hub (Controller) New Data (ex: isFire = 1) Vision State Data (Model) Director
Summary of Previous Slide • Modules (Director, Vision, etc) should be listening to changes in the model (AUVT State Data) • Our current paradigm is flawed; modules are listening for changes in ModuleHub (the Controller) • Problems: • Race Conditions • At startup when modules are initialized, there is no centralized model/database. Some variables are not being set at initialization • Controller Responsibilities • Controller is performing model responsibilities; when requesting for data, controller is attempting to regenerate data through Model
Actual/Revised Roles • Controller of “MVC” or “MVD” pattern • Intercept user commands • Observer objects should NOT listen to controller, but instead the model • Modules should listen to State Data (Model)
