  1. Having Fun with Netduino Chris Gilmore Joe Havelick

  2. What is a Netduino? * Not actual size

  3. Use Cases • Prototyping • Robotics • Automation • Automotive • Sequencing • Learning aid • Making something cool

  4. The Netduino processor and memory • Atmel 32-bit microcontroller • Speed: 48MHz, ARM7 • Code Storage: 128 KB power and i/o • input: 7.5 - 12.0 VDC or USB powered • output: 5 VDC and 3.3 VDC regulated • digital i/o are 3.3 V--but 5 V tolerant

  5. Power

  6. Inputs

  7. Outputs

  8. Shields

  9. The Netduino Plus differences from the Netduino • Code Storage: 64 KB • ethernet • micro sd

  10. The Netduino Mini Differences from the Netduino • Smaller package • Code Storage: 152 KB • output: 5 VDC only • 16 digital/analog GPIO pins

  11. Developing for Netdiuno • Environment • Visual Studio 2010 • C#/VB.Net • .NET Micro Framework

  12. Developing for Netdiuno • Features • Intellisense • Debugging • Breakpoints • Console • Emulation • Multithreading • Unit Testing

  13. Sample – FartyBreathalizer • Dev Environment • Basic I/O

  14. Sample - NetDoorNo • Events • Netduino Plus as a Web Server

  15. Sample - GPS Flight Logger • Classes and Libraries • SD Card Write

  16. Samples - Floppy Instrument • Multithreading • Interfaces

  17. Resources • Netduino.com • Forums/Chat • Book: The Internet of Things • SparkFun.com • DIYDrones.com

  18. Questions • Chris Gilmore • Joe Havelick • JoeHavelick.com
