  1. AEROSOLS: types • LIQUIID • SOLID • Dust • Smoke • Fly ash • pollen • Cloud • Mist • Fog • smog

  2. Mount manitoba, June 1991

  3. Asian brown cloud over China

  4. AEROSOLS: sources DUST SEA • Dust • Smoke • Fly ash • pollen • plant fragments • cement • brake lining • tires • soil chemical concentration factor (surface effects) CCF = [aerosol]/[sea]

  5. AEROSOLS: sizes • > 400 nm scatter light • < 0.01 micron coagulate • > 10 micron settle out • Typical size: 0.1-1 micron

  6. AEROSOLS: how to measure them • Alphabet soup: • COH • TSP • IP • TDF • PM10 • light scattering • collecting on filters

  7. AEROSOLS: how to measure them • Alphabet soup: • COH • TSP • IP • TDF • PM10 Coefficient of Haze Draw 300 meters through a filter measure absorbance x 100 >6 bad for asthma typical samples 5-10 micron

  8. AEROSOLS: how to measure them • Alphabet soup: • COH • TSP • IP • TDF • PM10 Total Suspended Particulate Weighing after filtering Units: μg/m3 “normal” ~ 10 μg/m3 sometimes 500 μg/m3 in cities

  9. AEROSOLS: how to measure them • Alphabet soup: • COH • TSP • IP • TDF • PM10 Inhalable Particulates Generally IP ~ 0.45 TSP

  10. AEROSOLS: how to measure them • Alphabet soup: • COH • TSP • IP • TDF • PM10 Total Dust Fall units: g m-2 month-1 should be < 7 g m-2 month-1 often exceeded in industrial areas

  11. AEROSOLS: how to measure them • Alphabet soup: • COH • TSP • IP • TDF • PM10 Particulate matter < 10 micron PM10 = TSP < 10 μ

  12. Combustion Products. Fly-ash vs. bottom-ash 150 PAHs With 2 – 7 rings

  13. • Nuclei mode • Accumulation mode • Coarse particle mode

  14. Particulate air quality in major world cities. Values are annual PM10 means. Horizontal line is WHO air quality guideline
