Presentation Transcript

  1. Applied Electronic Circuit 생체의료공학과 2009103859 안흥기

  2. Stress & Gain F Axial load L L F Cantilever

  3. - Curve ( Brittle Material(glass)) Brittle material (glass) Rapture (일정 힘 이상이 되면깨져버린다.) X Nonlinear : ultimate stress

  4. - Curve (Ductile material(AI, Steel)) X X Rupture Elastic region Plastic region : yield stress Elastic region Al Steel

  5. For Elastic Region Young’s Modulus (크면 잘 안 늘어나고, 작으면 잘 늘어난다.)

  6. Strain Gage L s

  7. s1 s2 s4 s3 Cantilever

  8. Bridge Circuit

  9. Lecture Note 8 -OVER- Thank you for your attention!
