  1. Asuro bootloader Shareware Created by Peter Wilbert Version V1.3 Next

  2. Download: Bootloader: • AsuroSerialBootLoaderV1.3 (2006-06-01).hex OCConsole.rar: shareware terminal program V3.0 von U. Altenburg: • OC-Console.exe • Console.ini (Saved settings for OC-Console) Prev Next

  3. First: program file AsuroSerialBootLoaderV1.3 (2006-06-01).hex into your Atmega8L using some Atmega programming equipment. Prev Next

  4. startOC-Console.exe Next: Prev Next

  5. Prev Next

  6. Select your COM Prev Next

  7. Set the bitrate to 2400baud Prev Next

  8. No parity Prev Next

  9. 8 databits Prev Next

  10. 1 stopbit Prev Next

  11. Prev Next

  12. Select ASCII Prev Next

  13. Disable all options Prev Next

  14. Prev Next

  15. Select NO synchronization Prev Next

  16. Prev Next

  17. Prev Next

  18. Prev Next

  19. Find any Asuro .hex Prev Next

  20. Do nothing, next slide please... Prev Next

  21. Switch Asuro On Prev Next

  22. OC-Console shows ‘Wait’... Prev Next

  23. Start uploading Prev Next

  24. Uploading... Prev Next

  25. If any failure occurs during uploading, Asuro system led will blink fast. Switch Asuro off. Repeat the upload sequence. Prev Next

  26. Upload finished, now upload another program or...(next) Prev Next

  27. Press any switch to start the program Prev Next

  28. Suggestions, idea’s, bugs... please mail to henk@arexx.com The End Prev
