SharePoint Framework and Modern Sites

SharePoint Framework and Modern Sites. Eric J Oszakiewski Development Manager – General Motors. twitter.com/ eoszak. eric@oszak.com. youtube.com/ sharepointeric. Agenda. Intro (< 5 min) Overview of Classic vs. Modern site differences (5-10 min)

favian
Télécharger la présentation

SharePoint Framework and Modern Sites

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. SharePoint Framework and Modern Sites Eric J Oszakiewski Development Manager – General Motors twitter.com/eoszak eric@oszak.com youtube.com/sharepointeric

  2. Agenda Intro (< 5 min) Overview of Classic vs. Modern site differences (5-10 min) SharePoint Framework review and installation/configuration (5-10 min w/ demo) Creating a simple app (5 min w/ demo) Deploying to SP2019 and activating on modern site (5 min w/ demo) Q&A (~5 min)

  3. Intro Programming since 1982 (TSO, Phoenix, BASIC, DASD) 12 years developing with SharePoint (started with WSS 2.0) Current project: migrate 12k site collections to SP2019 on prem Side projects: Xamarin mobile apps, .Net Web API, Azure CI/CD

  4. Classic vs. Modern sites, lists, libraries

  5. So, what are some branding options? • Custom theme • Office UI Fabric design toolkit (React or AngularJS) • On-Prem limited to colors and fonts only • Opt out of the modern list/library experience • No content rendered with modern look • Deprives users from improved experience • SharePoint Framework application extension (replaces Custom Actions and web parts!)

  6. SharePoint Framework • Originally we built managed & full trust code to highly customize SharePoint • Not suitable for multi-tenant, SPO environment • SharePoint Framework (SPFx) released in Feb 2017 • Provides a standardized framework for custom extensions and applications on SPO in a supported, future-prepared way • Modern web stack technologies • Streamlined experience

  7. Pros/Cons Pros SPFx does not run in an iFrame like traditional add-ins (SHA, PHA) Better control over arbitrary HTML and JS Tenant-wide deployment in SPO (not available on prem at this time) Cons Possible learning curve Limited to client-side code

  8. Improvements with Modern Column formatting

  9. Improvements with Modern { "$schema": "https://developer.microsoft.com/json-schemas/sp/column-formatting.schema.json", "elmType": "div", "attributes": { "class": "=if(@currentField <= 70,'sp-field-severity--warning', '')" }, "children": [ { "elmType": "span", "style": { "display": "inline-block", "padding": "0 4px" }, "attributes": { "iconName": "=if(@currentField <= 70,'Error', '')" } }, { "elmType": "span", "txtContent": "@currentField" } ] }

  10. Improvements with Modern Formatting list views

  11. Installing Pre-reqs Visual Studio Code (or similar IDE) Node.js (8.15.1 LTS) npm install -g yo gulp npm install -g @microsoft/generator-sharepoint@1.7.1 gulp trust-dev-cert (only need to do this once per machine) yo @microsoft/sharepoint (follow prompts)

  12. Building/Testing gulp serve (to test locally) • Uses workbench.html to experiment on your local machine like a 2019 modern page

  13. gulp serve on application customizer

  14. gulp serve on webpart

  15. Workbench

  16. Workbench

  17. Building/Testing • gulp bundle --ship (to pre-package everything) • Must run before package-solution --ship! • No manifests were found in '*.json'. Ensure a build has completed successfully and that paths.manifestsMatch is correct • gulp package-solution --ship • Solution will be a .sppkg file in the /sharepoint/solution folder in the project

  18. Deploying constspsync = require('gulp-spsync-creds').sync; build.task('upload-app-pkg', { execute: (config) => { return new Promise((resolve, reject) => { constpkgFile = require('./config/package-solution.json'); constfolderLocation = `./sharepoint/${pkgFile.paths.zippedPackage}`; return gulp.src(folderLocation) .pipe(spsync({ "username": "<username>", "password": "<password>", "site": "https://<server>/sites/<app-catalog-url-frag>", "libraryPath": "AppCatalog", "publish": true })) .on('finish', resolve); }); } }); Requires deployment to App Catalog • Manual deployment • Auto-publish using gulp • npm install gulp-spsync-creds • Add code to gulpfile.js • gulp build-solution --ship • gulp upload-app-pkg --ship

  19. Deploying PowerShell to SPO Connect-PnPOnline -Urlhttps://tenantname.sharepoint.com Add-PnPApp -Path <path to file.sppkg> -Scope Site –Publish (for tenant-wide deployment) Add-PnPApp -Path <path to file.sppkg> –Publish

  20. Deploying cls $CSOMPath = "C:\program files\common files\microsoft shared\web server extensions\16\isapi\“ $OfficeDevPnPPath=“<path to those files>” Import-Module "$CSOMPath\Microsoft.SharePoint.Client.dll" Import-Module "$CSOMPath\Microsoft.SharePoint.Client.Runtime.dll" Import-Module " $OfficeDevPnPPath\Microsoft.IdentityModel.Clients.ActiveDirectory.dll" Import-Module " $OfficeDevPnPPath \SharePointPnP.IdentityModel.Extensions.dll" Import-Module " $OfficeDevPnPPath\Microsoft.Graph.Core.dll" Import-Module " $OfficeDevPnPPath\Microsoft.Graph.dll" Import-Module " $OfficeDevPnPPath\OfficeDevPnP.Core.dll" Import-Module " $OfficeDevPnPPath\Newtonsoft.Json.dll" Write-Host "Connecting to app catalog..." -ForegroundColor Yellow -NoNewline $context = New-Object Microsoft.SharePoint.Client.ClientContext(“<url to target site collection>") $appmgr = New-Object OfficeDevPnP.Core.ALM.AppManager($context) Write-Host "Done" -ForegroundColor Yellow Write-Host "Locating branding app..." -ForegroundColor Yellow -NoNewline $apps = $appmgr.GetAvailable(); Write-Host "Done" -ForegroundColor Yellow Write-Host "Installing branding app..." -ForegroundColor Yellow -NoNewline $app = $apps | Where {$_.Title -eq “my-solution-name"} $appmgr.Install($app) $context.ExecuteQuery() Write-Host "Done" -ForegroundColor Yellow PowerShell to On-Prem using CSOM (requires adding to App Catalog first)

  21. Summary SPFx: lightweight, standardized Experienced developers should be able to quickly ramp up Compatible with 2019 on-prem or SPO Allows continued scripting customizations in a more controlled and future-oriented way. Just one method, many others for customizing SharePoint!

  22. Q&A Questions? Feedback?

  23. Thank you! SharePoint Framework enterprise guidance - https://docs.microsoft.com/en-us/sharepoint/dev/spfx/enterprise-guidance Setting up SPFx - https://docs.microsoft.com/en-us/sharepoint/dev/spfx/set-up-your-development-environment Building your first app - https://docs.microsoft.com/en-us/sharepoint/dev/spfx/web-parts/get-started/build-a-hello-world-web-part Connect an SPFx web part to SharePoint - https://docs.microsoft.com/en-us/sharepoint/dev/spfx/web-parts/get-started/connect-to-sharepoint Deploy to SharePoint - https://docs.microsoft.com/en-us/sharepoint/dev/spfx/web-parts/get-started/serve-your-web-part-in-a-sharepoint-page Custom Action to App Extension - https://docs.microsoft.com/en-us/sharepoint/dev/spfx/extensions/guidance/migrate-from-usercustomactions-to-spfx-extensions SPFx Roadmap - https://docs.microsoft.com/en-us/sharepoint/dev/spfx/roadmap
