  1. Doors

  2. Definitions

  3. Definitions

  4. Definitions

  5. Materials

  6. Profiles

  7. Mullions • To provide separation between multiple doors • To allow for a glazed side light Mullion

  8. Transom • To provide glazed light etc above door Transom

  9. Thresholds Rebate for weathering Must be made from durable timber Other mater materials may be used Such as Marble, granite etc Brass Strip for Weathering

  10. Typical Entry Door Frames

  11. Storm Moulds • Provides weathering strip • Closes cavity • Finishes frame against brickwork • Note it is important that brickwork finishes even around the frame so as the margin is even

  12. Metal Door Frames • Pre primed • When ordering make sure • Assembled or Unassembled • Hinges – welded or screwed • Fully welded or Tacked • This item is important • Position of Striker • What type of Striker • Other Hardware • Deadlock • Door Closer • Patio Bolts etc • Important to specify all • SITE FIXING IS VERY EXPENSIVE

  13. Aluminum Door Frames

  14. Frame Assembly

  15. Other Issues • If time allows check out of hinges • It is much easier on a set off saw horses • Usually don’t check out for Door Striker • Prime back of frame if it is an External Door • Prime base of frame if it is in a wet are

  16. Brace to Hinge Side Head at 90⁰ to Hinge Styles 90⁰ use steel square Same distance as head

  17. Installation of Frame

  18. Bonding Frame

  19. Brick Veneer Detail

  20. Single Brick

  21. Double Brick Construction

  22. Estimating for Doors

  23. Estimating Door Frames
