  1. Light Modalities Chapter 19

  2. Description • Light modalities are found on the electromagnetic spectrum • Most abundant form of energy in the universe • Drying superficial tissues or via superficial photochemical effects • Some mild superficial thermal effects

  3. Types of Therapeutic Lamps • Infrared • Superficial dry heat • Ultraviolet • Heats the body’s tissues for either tissue destruction or therapeutic effects • Visible • Combination of ultraviolet and infrared known as Lasers

  4. Infrared Lamp • Used to dry seeping open wounds or sedate superficial sensory nerves • Radiant modality: An electrical current passes through a carbon or tungsten filament • Intensity controlled by adjusting current flow or distance between lamp and tissue • Constant temperature, increased risk of burns • Heating skin depends on the amount of radiation absorbed • Pigmented, darker skin will absorb more energy and will heat more rapidly than lighter skin

  5. Types of Infrared Lamps • Near-Infrared • Luminous Infrared Lamp • Wavelength: 780 to 1,500 nm (closest to visible light) • Thermal Effects: 5 to 10 mm deep • Energy formed by carbon and tungsten filament • Light bulb • Some energy is reflected by the surface of the skin

  6. Types of Infrared Lamps • Far-Infrared • Nonluminous Infrared Radiation • Wavelength: 1,500 to 12,500 nm • Thermal Effects: < 2mm • Less penetrating than Near-Infrared • Skin feels warmer • Energy formed by metal coil • i.e. electric stove or space heater • Invisible to human eye

  7. Effects of Infrared Lamps • Constant, dry heat to assist with superficial tissue • Dermatological conditions • Increase cell metabolism • Blood flow • Muscle Relaxation • Contraindications • Any conditions in which other forms of superficial heat are contraindicated

  8. Clinical Applications • Turn On and warm if necessary • Treatment Duration: 20 to 30 minutes • Intensity: adjust wattage or distance of lamp • Luminous = 24 inches • NonLuminous = 32 inches • Inverse Square Law • Cosine Law • Clean sweat and dirt, remove jewelry, and fit infrared goggles (if applicable) for patient

  9. Ultraviolet Therapy • Used to produce photochemical reactions in the skin • Wavelength: 180 to 400 nm • 3 UV bands (A, B, and C) produce unique effects

  10. Types of UV • UV-A • AKA: near UV • Effects: Erythema without pigmentation • UV-B • AKA: middle UV • Effects: Erythema without pigmentation, formation of vit D, skin tanning (blister/burn) • UV-C • AKA: far UV • Kills bacteria, formation of vit D, skin tanning

  11. Types of UV Lamps • ‘Hot’ UV Lamps • Low Volt (30-110V) High-Amp (5A) • Electrical current passes through tube, argon gas heats, vaporizing and polarizing mercury to produce UV light in ALL 3 bands and visible violet light • ‘Cold’ UV Lamps • High Volt (3000V) Low-Amp (15mA) • Energy is cooler than ‘Hot’ and produce UV-C

  12. Biophysical Effects • Energy absorbed at a depth between 0.20 to 0.22 mm • Damages cell proteins, DNA, & RNA to initiate local inflammatory responses • Effects: • Vitamin D synthesis • Enhances melanin production • Thickens epidermis • Superficial vasodilatation • Bactericide

  13. Effects of UV Lamps • Wound Healing • Activates inflammatory response • Use: Cold Lamps at intensity of E3 • Treat Skin Disorders • i.e. psoriasis • Exfoliates tissue and damage DNA that produces the excess skin growth associated with psoriasis • Use: UV-B

  14. UV Contraindications • Sunlight sensitivity • Fair skin (precaution) • Medications or food that increase sunlight sensitivity • Hyperthyroidism

  15. UV Dosage • Determined by Minimal Erythema Dose • Least amount of UV exposure time to produce redness within 1-6 hrs and disappear within 24 hours • ‘Hot’ Lamps • Determined by each patient and each lamp • Standard distance = 30 in., not closer than 15 in. • ‘Cold’ Lamps • Standard MED value • 12-15 seconds at a distance = 1 in.

  16. Determining MED for UV Lamp • Cardboard Test Strips 1. 6 different shapes cut out 2. Use to cover shapes • UV Lamp 30 in. away • Exposes 1 cut out, open the shutters for 30- sec., expose the 2nd cut out and leave the 1st uncover for the 30-sec. • Repeat the steps above for the remaining 4 cut outs, but expose them at 15-sec intervals • Instruct patient to check area every hour and record changes

  17. UV Treatment Dosage • SED • No erythema • MED • Smallest dose that produces erythema within 1-6 hr • E1 • Erythema lasts for 1-3 days, some scaling of skin present, approximately 2.5x MED • E2 • Erythema with edema, peeling, and pigmentation, approximately 5x MED • E3 • Severe erythema and burning, blistering, peeling, edema, approximately, 10x MED

  18. Clinical Application • Calculate treatment dose and duration • Clean area and remove jewelry • Cover skin not being treated (sunscreen if applicable) • Fit UV-resistant goggles to patient and clinician • Position lamp at right angle using the correct distance and duration for each type of lamp • Clean machine and check periodically for maintenance of bulbs

  19. Adjusting the Treatment Dose • Biophysical changes occur with light exposure causing changes in treatment • Duration • 30 to 50% increase for each subsequent treatment • If 3 to 5 minutes, then distance is reduced • 5 to 10 sec is decreased when missing a treatment • Be aware of patients skin color and the lamps distance, duration, and angle

  20. Therapeutic Lasers • L=Light • A=Amplification by • S=Stimulated • E=Emission of • R=Radiation • Classified by the FDA’s Center for Devices and Radiological Health

  21. Types of Lasers • High-Power Laser • “Hot Laser” • Effect: • Causes thermal changes in tissues (cause tissues to be destroyed, evaporated, or dehydrated) • Uses: • Surgery • Capsular shrinkage • Wrinkle and tattoo removal • Low-Power Laser • “Cold Laser” • Effect • Causes photochemical changes in tissue • Uses: • Wound healing • Arthritis • Burn care

  22. Production of Laser Energy • Lasers are referred to by the type of active medium (gas, liquid, solid) • HeNe: visible red light penetrating 0.8 to 15mm • GaAs: invisible penetrating up to 2 cm • Energy is introduced into the active medium • An orbiting electron briefly elevates into a higher or ‘excited’ state • The electron spontaneously returns and releases another photon

  23. Effects of Lasers • Photons are absorbed by tissues to alter molecular-level activity • Theorized to affect pain-producing tissue (muscle spasm), by increasing ATP synthesis that increases cell metabolism and encourages the release of free radicals

  24. Wound Healing • Superficial wounds • Ulcers, surgical insicison, burns • Lasers alter cell membrane permeability and increase in fibroblast, lymphocyte, and macrophage activity occurs • Blood and lymph improve to promote the growth of granulation tissue • Increase collagen and tensile strength of healing wounds

  25. Pain Reduction • Decrease acute and chronic pain • Reduce the rate and velocity of sensory nerve impulses • Similar to cryotherapy but without thermal changes

  26. Fracture Healing • May enhance fracture healing and bone remodeling by increasing capillary formation, calcium deposition, increase callus formation, and reducing hematomas • Photons striking the tissue create acoustic waves that affect bone healing similar to ultrasonic bone growth stimulators

  27. Clinical Application • Because of the investigational status of therapeutic lasers, the clinical application is not described.
