  1. Algorithms Searching and SortingAlgorithm Efficiency

  2. Efficiency • A computer program should be totally correct, but it should also • execute as quickly as possible (time-efficiency) • use memory wisely (storage-efficiency) • How do we compare programs (or algorithms in general) with respect to execution time? • various computers run at different speeds due to different processors • compilers optimize code before execution • the same algorithm can be written differently depending on the programming language used

  3. Example: Linear Search • Input: • List A of n unique data values, indexed from 0 to n-1. (The data values are not in any specific order.) • The desired data value (target) we’re searching for. • Output: • The index of the location of the target in the list or -1 if the target is not found.

  4. Example: Linear Search • Algorithm: 1. Set index = 0. 2. While index < n and A[index] ≠ target, do the following: a. Add 1 to index 3. If index ≤ n-1, output index; Otherwise, output -1.

  5. Example: Linear Search index  0 Algorithm: 1. Set index = 0. 2. While index < n and A[index] ≠ target, do the following: a. Add 1 to index 3. If index ≤ n-1, output index; Otherwise, output -1. index < n andA[index] ≠ target no yes index  index + 1 yes index ≤ n-1 no index -1

  6. Example: Linear Search index  0 Algorithm: 1. Set index = 0. 2. While index < n and A[index] ≠ target, do the following: a. Add 1 to index 3. If index ≤ n-1, output index; Otherwise, output -1. index >= n or A[index] = target DeMorgan’s Law: not (A and B) = (not A) or (not B) yes no index  index + 1 yes index ≤ n-1 no index -1

  7. Some questions • What is the maximum number of data values we need to examine as a function of n? (i.e. worst case) • What is the minimum number of data values we need to examine as a function of n? (i.e. best case) • How much storage do we need to hold all of the information for use in this algorithm as a function of n?

  8. Linear Search • We measure time efficiency by counting the number of operations performed by the algorithm. • But what is an operation? 1. Set index = 0. 2. While index ≤ n-1 and A[index] ≠ target, do the following: a. Add 1 to index 3. If index ≤ n-1, output index; Otherwise, output -1.

  9. Counting Operations • We typically count operations that are a function of the amount of data (n) that we have to process. • Abstraction: • We don't count individual operators (+, -, ...). • We count more general operations: • assignments (← or "Set ... equal to ..."), or • comparisons (<, >, <,>, =, ≠) • For linear search, we might count comparisons. • How many comparisons does linear search require in the worst case? n+2

  10. Example: Binary Search • Input: • List A of n unique data values. NOTE: The data values must be sorted in increasing order. • The desired data value (target) we’re searching for. • Output: • The index of the location of the target in the array or -1 if the target is not found.

  11. Example: Binary Search • Algorithm: 1. Set i = 0 and j = n-1. 2. Repeat: a. mid = (i + j) / 2 (ignore any remainder). b. If (target < A[mid]), set j = mid-1. Otherwise if (target > A[mid]), set i = mid+1. until i > j or A[mid] = target. 3. If i <= j, output mid. Otherwise, output -1.

  12. Example: Binary Search i  0, j  n-1 Algorithm: 1. Set i = 0 and j = n-1. 2. Repeat: a. mid = (i + j) / 2 (ignore any remainder). b. If (target < A[mid]), set j = mid-1. Otherwise if (target > A[mid]), set i = mid+1. until i > j or A[mid] = target. 3. If i ≤ j, output mid. Otherwise, output -1. mid (i + j) div 2 yes no target < A[mid] yes target > A[mid] j  mid-1 i  mid+1 no no i > j or A[mid] = target yes yes no i ≤ j mid -1

  13. Counting Operations Again • For binary search, consider the worst-case scenario (target is not in list) • How many times can we split the list before the list becomes empty? • n=15: 15  7  3  1  0 (4 splits) • In general, we can split the list in half approximately log2n + 1 times before it becomes empty. • Recall the log function:logab = c is equivalent to ac = bExamples: log2128 = 7 log2n = 5 implies n = 32

  14. Order of Complexity • For very large n, we express the number of operations as the order of complexity. • Order of complexity for worst-case behavior is often expressed using Big-O notation: Number of operationsOrder of Complexity n O(n) n/2 + 6 O(n) 2n + 9 O(n) Usually doesn't matter what theconstants are...we are only concerned aboutthe highest powerof n.

  15. O(n) ("Linear") 2n + 9 n Number of Operations n/2 + 6 n (amount of data)

  16. O(n) Number of Operations n 30 10 20 10 10 10 20 30 n (amount of data)

  17. Order of Complexity Number of operationsOrder of Complexity n2 O(n2) 2n2 + 7 O(n2) n2/2 + 5n + 2 O(n2) Usually doesn't matter what theconstants are...we are only concerned aboutthe highest powerof n.

  18. O(n2) ("Quadratic") n2 n2/2 + 5n + 2 2n2 + 7 Number of Operations n (amount of data)

  19. O(n2) Number of Operations n2 900 500 400 300 100 10 20 30 n (amount of data)

  20. Order of Complexity Number of operationsOrder of Complexity log2n O(log n) log10n O(log n) 2(log2n) + 5 O(log n) The logarithm base is not written in big O notation since all that matters is that the function is logarithmic.

  21. O(log n) ("Logarithmic") 2(log2 n) + 5 Number of Operations log2 n log10 n n (amount of data)

  22. O(log n) Number of Operations log2 n 6 1 5 1 4 16 32 64 n (amount of data)

  23. O(n log n) Number of Operations n log2n = O(n log n) 384 (not drawn to scale) 224 160 96 64 16 32 64 n (amount of data)

  24. O(1) ("Constant") Number of Operations 15 = O(1) 15 n (amount of data) 10 20 40

  25. O(2n) 2n = O(2n) Number of Operations (definitely not drawn to scale) 32768 31744 1024 992 n (amount of data) 32 5 10 15

  26. Comparing Big O Functions O(2n) O(n2) O(n log n) Number of Operations O(n) O(log n) O(1) n (amount of data)

  27. Searches • Linear Search • Count comparisons as operations. • Worst Case: O(N) • Binary Search • Count comparisons as operations. • Worst Case: O(log N) • Which algorithm is better? • In general, for large values of N: log N < Nso binary search is better for large N. • BUT, binary search requires a sorted list.

  28. Selection Sort • Find the smallest data value in the list from index 0 to index n-1 and swap it into position 0 of the list. • Find the smallest data value in the list from index 1 to index n-1 and swap it into position 1 of the list. • Find the smallest data value in the list from index 2 to index n-1 and swap it into position 2 of the list. • …etc…

  29. Selection Sort • What is the worst-case order of complexity of selection sort on n data values? • Count the comparisons as operations. • First pass through: n-1 comparisons • Second pass through: n-2 comparisons • ... • Last (n-1st) pass through: 1 comparison • Order of complexity:(n-1)+(n-2)+...+1 = n(n-1)/2 = (n2-n)/2 = O(n2) • We call selection sort a "quadratic sort".

  30. MergeSort • Split the list into 2 halves.* • If the size of the half-list is not 1, • Sort each half using merge sort. (recursively) • Set up a new list. • Merge step: Move the smallest of each half-list into the new list. Repeat this step until one of the half-lists is empty. Then copy the remaining data in the non-empty half-list into the new list. *If the list has an odd number of elements, one list will have one extra element.

  31. MergeSort

  32. MergeSort

  33. Merge Sort • What is the order of complexity of merge sort? • Let C(n) = total number of operations performed for merge sort on n data values. • Operations include comparisons in the merge process. • C(1) = 0 • Maximum number of comparisons to merge 2 lists on size n/2 into one list of size n: n-1 comparisons. • C(n) = C(n/2) + C(n/2) + n-1 = 2C(n/2) + n – 1 • This is a recurrence relation (it’s recursive!). • Solution: C(n) = nlog2n - n + 1 = O(n log n).

  34. Order of Complexity • Examples: • O(logN) + O(N) = O(N) • O(N log N) + O(N) = O(N log N) • O(N logN) + O(N2) = O(N2) • O(2N) + O(N2) = O(2N) Algorithm O(A) Overall order of complexity of algorithm is max (O(A), O(B)). O(B)

  35. Order of Complexity • Examples: • O(logN) * O(N) = O(N log N) • O(N log N) * O(N) = O(N2 log N) • O(N) * O(1) = O(N) Algorithm O(A) Overall order of complexity of algorithm is O(A * B). Example:- Nested loops O(B) O(A) does not include complexity of part B of algorithm

  36. Searches Revisited • What if you wanted to use binary search on data that is not sorted? • Sort first: O(n log n) using Merge Sort • Then use binary search: O(log n) • Total runtime complexity:O(n log n) + O(log n) = O(n log n) • Now, how does this compare to linear search?

  37. Comparing Algorithms • Assume an algorithm processes n data values. If each operation takes 1 s to execute, how many s will it take to run the algorithm on 100 data values if the algorithm has the following number of computations? Number of ComputationsExecution Time n 100 s n • log2 n 665 s n2 10,000 s n3 1,000,000 s = 1 sec 2n > 1030s n! > 10160s
