Understanding Amplitude, Midline, and Period in Sinusoidal Functions

DESCRIPTION

This guide explores the key concepts of sinusoidal functions, focusing on amplitude, midline, and period as described in the fourth edition of "Functions Modeling Change: A Preparation for Calculus." It explains how to determine the amplitude and midline from equations like y = A sin(t) + k and provides examples including y = 3 sin(t) + 5 and y = -0.15 cos(t) + 0.2. It also covers transformations such as horizontal shifts and helps understand how period influences the waveform. Ideal for calculus preparation.

1 / 8

Télécharger la présentation

Understanding Amplitude, Midline, and Period in Sinusoidal Functions

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. 8.2 SINUSOIDAL FUNCTIONS AND THEIR GRAPHS Functions Modeling Change: A Preparation for Calculus, 4th Edition, 2011, Connally

  2. Amplitude and Midline The functions y = A sin t + k and y = A cost + k have amplitude |A| and the midline is the horizontal line y = k. Functions Modeling Change: A Preparation for Calculus, 4th Edition, 2011, Connally

  3. Amplitude and Midline Example 1 State the midline and amplitude of the following sinusoidal functions: (a) y = 3 sin t + 5 (b) y = (4 − 3 cost)/20. Solution Rewrite (b) as y= 4/20 − 3/20cost y = -0.15 cost + 0.2 (a) (b) Amplitude = 3 Midline y = 5 Amplitude = 0.15 Midline y = 0.2 Graph of y = 3 sin t + 5 Graph of y = 0.2 − 0.15 cost Functions Modeling Change: A Preparation for Calculus, 4th Edition, 2011, Connally

  4. Period The functions y = sin(Bt) and y =cos(Bt) have period P = 2π/|B|. Functions Modeling Change: A Preparation for Calculus, 4th Edition, 2011, Connally

  5. Finding Formulas for Functions Example 3 Find possible formulas for the functions f and g in the graphs Solution y = g(t) y = f(t) This function has period 4π This function has period 20 The graph of f resembles the graph of y = sin t except that its period is P = 4π. Using P = 2π/B Gives 4π = 2π/B so B = ½ and f(t) = sin(½ t) The graph of g resembles the graph of y = sin t except that its period is P = 20. Using P = 2π/B gives 20 = 2π/B so B = π/10 and g(t) = sin(π/10 t) Functions Modeling Change: A Preparation for Calculus, 4th Edition, 2011, Connally

  6. Horizontal Shift The graphs of y = sin(B(t − h)) and y = cos(B(t − h)) are the graphs of y = sin(Bt) and y = cos(Bt) shifted horizontally by h units. Functions Modeling Change: A Preparation for Calculus, 4th Edition, 2011, Connally

  7. Horizontal Shift Example 7 Describe in words the graph of the function g(t) = cos (3t −π/4). Solution We want the form cos(B(t − h)). Factor out a 3 to get g(t) = cos (3(t − π/12)). The period of g is 2π/3 and its graph is the graph of f = cos 3t shifted π/12 units to the right, as shown Period = 2π/3 Horizontal shift = π/12 g(t) = cos (3(t − π/12)) f(t) = cos (3t ) Functions Modeling Change: A Preparation for Calculus, 4th Edition, 2011, Connally

  8. Summary of Transformations For the sinusoidal functions y = A sin(B(t − h)) + k and y = A cos(B(t − h)) + k, • |A| is the amplitude • 2π/|B| is the period • h is the horizontal shift • y = k is the midline Functions Modeling Change: A Preparation for Calculus, 4th Edition, 2011, Connally
