WEB BASED DATA TRANSFORMATIONUSING XML, JAVA Group members: Darius Balarashti & Matt Smith
Idea • highly customizable • dynamic • platform independent Web application that acts as an intermediary among several databases in exchanging data
Background – technology used • XML • SOAP • HTTP • Java Server Pages (JSP)
XML - eXtensible Markup Language • called extensible since it is not a fixed format e.g. HTML • XML is a ‘meta-language’– a language for describing other languages - e.g. Wireless Markup Language (WML) • designed to describe any structured data • “universal format for structured data on the Web”– W3C web site When should I use XML? When you need a buzzword in your resume. W3SCHOOLS.COM
designed to describe data & focus on what data is No predefined tags No inherit structure of your tags used for data manipulation and transfer designed to display data & focus on how it looks Predefined tags Inherit structure built into tags e.g. <h1> used for displaying that same data XML vs. HTML XML is not a replacement for HTML
<?xml version="1.0"?> <CATALOG> <CD> <TITLE>EmpireBurlesque</TITLE> <ARTIST>Bob Dylan</ARTIST> <COUNTRY>USA</COUNTRY> <COMPANY>Columbia</COMPANY> <PRICE>10.90</PRICE> <YEAR>1985</YEAR> </CD> </CATALOG> <html> <h2>Catalog</h2> <body> <table width=“100%”> <tr> <td>EmpireBurl</td> <td>Bob Dylan</td> <td>USA</td> </tr><tr> <td>Columbia</td> <td>10.90</td> <td>1985</td> </tr></table></body></html> Simple Example HTML XML • <?xml version="1.0"?> <CATALOG> <CD> <TITLE>EmpireBurlesque</TITLE> <ARTIST>Bob Dylan</ARTIST> <COUNTRY>USA</COUNTRY> <COMPANY>Columbia</COMPANY> <PRICE>10.90</PRICE> <YEAR>1985</YEAR> </CD> </CATALOG>
Advantages of XML • data exchange between incomparable systems • Software independent • Hardware independent • plain text files • data is stored outside of HTML • can code documents more precisely • - reflects structure and semantics of that document
Transforming XML • DTD – document type definition - defines tags in XML - number, sequence, attributes, and values of those tags • XSL – eXtensible Style Sheet - browsers can’t display XML - transforms XML into HTML • CSS – Cascading Style Sheet - less control than XSL
SOAP – Simple Object Access Protocol XML and HTTP based Protocol -protocol for exchange of information decentralized environment - defines a framework for describing what is in a message & how to process it All SOAP messages encoded in XML
Java Server Pages (JSP) • servlet = server side applet - Java’s answer to CGI - no GUI • static HTML with dynamic content from servlets and/or JavaBeans • some Java advantages • Platform independent • Can utilize Java API for XML Processing (JAXP), Java API for XML Messaging (JAXM), and Simple Access API for XML (SAX).
XML & Java Application • XML document is parsed, data becomes available to application • DOM (Document Object Model) • represents elements as tree nodes • use if need random access to data • SAX (Simple API for XML) - fires events based on what it encounters - write code to make sense of these events
XML & Java • Java is portable code, XML portable data • Applications completely portable • Java provides most robust set of - API’s - processors - parsers
Why XML & JSP ? • can use SAX • 3 main steps • Create object model • Create parser • Create handler
Overall Approach • User can select source data and transfer it to different database(s) • 2 distinct process • - configuration • - transformation Web app. that is intermediary between 2 databases
Configuration Process • User driven - user selects source data - user selects destination database • User select transformation options, if any - direct mapping of data - string manipulations - simple calculations
System driven - takes user specified configurations and performs actual data transformation How? - System sends SOAP request to the module controlling the source database. - Module connects to database and receives the data tuple. - System sends data to the interpreter which transforms the data. - Data is sent to the module controlling the destination database. - Module loads the data into the database. Transformation Process
Costs • Time - done by April 2002 • Money – can vary greatly • Software - currently, none • Hardware - none other than available on campus
Performance Requirements • handle large databases 10,000+ records • less than 1 sec per record
Constraints • Environmental • Unknown bandwidth between system and source/destination • Unknown database optimizations • System • Bandwidth • Processor power • Code optimization
Constraints [cont’d] • User • Access Privileges • Security • Maintenance • Basic code/server maintenance • Updating database specific modules • Optimization
Alternative Designs • Application server using Enterprise Java Beans • Adv: any application environment, direct transformations • Dis: complex, expensive, unreliable • Microsoft .NET platform • Adv: based on XML, any language • Dis: documentation, Beta version
Testing Methods • User Interface Testing Testing Methodology: Rational Unified Process Testing the user interface against necessary functionality. • Unit Testing Testing the classes as individual components. Development and implementation of test cases. • System Testing Testing the classes as components in the system. Development and implementation of test scenarios.
