Case Presentation

Case Presentation. Mary Palomaki November 11, 2009. 9 y/o female with difficulty seeing far. HPI History obtained from grandmother and patient. 9 y/o female with difficulty seeing the blackboard x 3 days. She noticed the change in vision while playing with her dolls.

gwyn
Télécharger la présentation

Case Presentation

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript


  1. Case Presentation Mary Palomaki November 11, 2009

  2. 9 y/o female with difficulty seeing far

  3. HPIHistory obtained from grandmother and patient • 9 y/o female with difficulty seeing the blackboard x 3 days. • She noticed the change in vision while playing with her dolls. • + slight pain with eye movements • + increased lacrimation • No alleviating factors, no provoking factors • Denies trauma, proptosis, edema, erythema of eye or eyelids, fever, headache, weight loss, nausea/vomiting, weakness, vertigo, neck stiffness • ROS: + cough, runny nose, sore throat x 4 days, no diarrhea or dysuria, good PO

  4. Past Medical History • Birth History: FT, NSVD, no complications • Tonsillectomy at age 7 • History of headaches • MRI (2008): cystic lesion in left hippocampus/tail of caudate nucleus, cleared by neurosurgery • FH: Mother: deceased, cancer

  5. Other History • Medications: Tylenol for sore throat • Allergies: NKDA • Immunizations: up to date (verified by CIR) • Social: lives with grandmother, three brothers, 7,9,14 y/o.

  6. Physical Exam • VS: T: 98.6 F, HR: 82, RR 16, BP: 80/60, wt: 39.9 kg, Ht 135 cm, BMI 21 (>95%tile) • Gen: Obese, NAD, AAO x 3 • HENT: NC/AT, TM: b/l shinny, grey, no fluid, + rhinorrea, oropharynx: no lesion, neck supple

  7. Physical Exam • Orbit: no edema, no discoloration, no crepitus on bony deformities, no proptosis • Eyelids: no edema, no lesion • Acuity: R: 20/20, L: 20/70, + diplopia on L • Pupils: round, symmetrical, direct and consensual pupillary reflexes intact • EOMI • No lacrimation • No nystagmus • Conjunctivae pink, no lesion, no hemorrhage

  8. Physical Exam • CVS: S1/S2, no murmur, RRR • Resp: CTA • Abd: BS+, soft, NT/ND, no organomegaly • Ext: FROM, 5/5 strength, no edema, cap refill < 2 sec. • Skin: no rash • Neuro: CN II-XII intact, normal tone, normal gait, heel-shin intact, failed pass pointing with right eye closed • GU: normal female, Tanner 1

  9. Differential Diagnosis

  10. Ophthalmology Consult • Corneal abrasion on left eye, 4mm long • Erythromycin ointment x 3 days • Follow up with ophthalmology in 1 week

  11. Ocular Trauma Ocular Trauma

  12. Ocular trauma • 1/3 of blindness in children results from trauma • Boys age 11-15 are most at risk (M:F = 4:1) • Sports, toy darts, sticks, stones, fireworks, paintballs, air-powered BB guns are common causes of trauma

  13. Outline • Review of Anatomy • History • Eye exam • Corneal Abrasions • Orbital fractures • Lacerations • Globe rupture • Retinal Detachment • Chemical Burns • Prevention

  14. Review of anatomy

  15. History • Mechanism of injury, events after injury • Onset/duration of symptoms • Preexisting eye disorders • Systemic disorders • Drug allergies • Contraindications to anesthesia • When patient last ate • Prior tetanus immunization

  16. Physical Exam • Observation/inspection with pen light • External examination: • Orbital bones: palpate orbital rim • Position of globes (exophthalmos or enophthalmos) • Mobility of globes: note pain, diplopia, limitation of ocular rotation, and abnormal movements (nystagmus) • Inspection of lids (Do NOT palpate if globe ruptured!) • Skin, conjunctival surfaces of lids should be inspected for foreign body or laceration • Palpate lid for crepitus

  17. Physical Exam • Pupil exam: • Size • Shape • Reaction to light • Look for corneal opacities or defects • Look for blood in anterior chamber • Look for lens opacification or dislocation • Iridodonesis is a moving/shaking iris, a sign of dislocation

  18. Examination of Visual Acuity in Children • Preverbal children • Allow child to reach for a small toy with one eye covered, then the other eye covered

  19. Examination of Visual Acuity in Children • Children 4-8 years old: • Eye chart with Pictures, tumbling E’s, numbers, or letters • 2 inch wide paper taped to brow to cover one eye • Test with corrective lenses in place if possible • Vision difference more important than absolute vision • Referral to ophthalmologist if both eyes in 5 year old are 20/50 or worse, or 20/60 or worse in 6 year old

  20. Examination Visual Acuity in Children • Children > 8 years old • Use standard Snellen Chart at 20 ft. • Most common ocular condition in this age group is myopia • blurred vision at distance • can develop over several months

  21. Fluorescein Staining • First use topical anesthetic drops (proparacaine) • Warn patients and parents of transient pain before anesthesia takes effect • Moisten a fluorescein strip, and touch to lower fornix • Or use fluorescein drops • Fluorescein stains tear film, washes away on intact epithelium and stains exposed corneal stroma • Yellow dye is visible in white light, but better under ultraviolet light (Wood Lamp) • Wood’s lamp is better tolerated if photophobia present

  22. Physical Exam--Slit Lamp Exam • Binocular microscope that allows the examiner to have a three-dimensional view of the eye • Beam of light (rather than diffuse light) can be adjusted by height and width • Provides 10-25 x magnification • Anterior segment of the eye: • lids, lashes, conjunctiva, cornea, • anterior chamber, iris, and lens • Ocular foreign body removal

  23. Physical Exam: Dilation • Perform after visual acuity tested and pupil exam • Perform only if patient is neurologically intact • Use Topical 2.5% phenylephrine plus 1-2 drops of 0.5% tropicamide • Wait 20 minutes • Complete the ophthalmoscopic exam • Dilation lasts 2-5 hours • (Atropine is contraindicated because dilation can last for days.)

  24. Corneal Abrasions: Corneal Anatomy • Avascular • Densely innervated • Sensory pain fibers from CN V • 5 layers: • Epithelium: outermost, 5-6 cell-thick • Cells quickly regenerate after injury • Boman’s layer: tough layer, protects • Stroma: thick layer composed of collagen fibrils aligned in parallel • Descemet’s membrane • Endothelium: if damaged will not regenerate

  25. Corneal Abrasions • Most common eye trauma • Symptoms: photophobia, tearing, intermittent sharp pain due to ciliary body spasm, foreign body sensation • PE: irritability, blurry vision, conjunctival injection, blepharospasm, irregular red reflex, dulled corneal light reflex, fluorescein staining of epithelial defect • Be sure to evert the lid to examine tarsus

  26. Lid Eversion

  27. Corneal Abrasions • Traumatic corneal abrasions: mechanical trauma to the eye, or foreign body under the lid • Foreign body related corneal abrasion: objects embedded in cornea • Contact lens related corneal abrasions: from over-worn, poorly fitting, dirty lens • Spontaneous defects: previous trauma

  28. Corneal Abrasions: Treatment • Remove foreign bodies with moist cotton swab or sterile needle (by ophthalmologist only) • Long-acting topical cycloplegic drop • Homatropine 5% • For pain relief caused by ciliary body spasm • Antibiotic ointment • Better than drops because it lubricates • Erythromycin • Aminoglycosides should be avoided since they can be toxic to the epithelium. • Drops with steroids are contraindicated; they slow epithelial healing and decrease immune response. • Semi-pressure patch • controlled studies have found that patching does not improve the rate of healing or comfort

  29. Corneal Abrasions: Follow Up • Small (<3 mm) abrasions with no change in vision do not need follow up • Except patients with contact lens related abrasions, where daily follow up recommended • Large abrasions (>3 mm), or any abrasion with diminished vision, need daily follow-up.

  30. Corneal Abrasion--Refer to Ophthalmologist when: • corneal infiltrate, white spot, or opacity • Refer same day • epithelial defect is larger at 24 hours, • purulent discharge present • Patient has experienced a drop in vision

  31. Orbital Fractures • Lateral Orbit fractures: zygomatic bone fracture • Cosmetic deformity, pain, difficulty opening mouth • Lateral canthus tendon inserts in the zygomatic, with fracture, the lateral canthus is inferiorly displaced • Orbital Apex fracture: • Can cause optic nerve compression, central retinal artery occlusion, retrobulbar hemorrhage • Blow-Out fracture: • Orbital floor and medial wall • Usually caused by blunt trauma with a large object

  32. Blow-Out fracture • Four signs: • Enophthalmos • Loss of sensation over malar eminence and cheek • Inability to look up on affected side • Diplopia on up-gaze • Positive traction test • Inability to rotate eye upward with forceps

  33. Blow-Out fracture: Management • Oral antibiotic prophylaxis x 5-7 days • Surgical correction 2-3 weeks later by otolaryngologist

  34. Complicated Lid Lacerations • Lid Margin lacerations: must be aligned properly to avoid lash inversion, damaging the cornea • Medial canthus lacerations: • May go through canaliculi • Cause persistant tearing • Canaliculi must be reattached

  35. Traumatic Hyphema • Blood in anterior chamber secondary to trauma • (Spontaneous Hemorrhage can occur secondary to juvenile xanthogranuloma) • Vision impaired until blood settles and forms a red meniscus • 20% of patients re-bleed • “Blackball hyphema” • Usually occurs at 3-5 days after initial injury • Occurs from lysis of clot • Recurrence of bleeding is more severe; possibly causing glaucoma, hemophthalmitis

  36. Black ball Hyphema

  37. Primary Hyphema: Management • Bed rest, elevation of the head • Eye Shield • Cycloplegia • Topical Steroids • Systemic antifibrinolytics • Aminocaproic acid: in your healthy patients • Measurement and control of intraocular pressure • Screen all black patients with hemoglobin electrophoresis • Secondary glaucoma is more likely with SS or trait

  38. Open Globe Injuries • Blunt trauma: globe rupture, most common site is near the insertion of the rectus muscles in the sclera • Penetrating trauma: laceration to the globe, most common in the cornea

  39. Open globe Injuries • Avoid any examination procedure that might apply pressure to the eyeball • For young children, an examination facilitated by procedural sedation or anesthesia should be performed by an ophthalmologist • Avoid medication (anesthetic drops or fluorescein) into the eye. • Foreign bodies should be removed by ophthalmologist

  40. Open Globe Injuries: PE • Markedly decreased visual acuity • Volume loss • Afferent pupillary defect • Increased anterior chamber depth • Leakage of vitreous • Outward prolapse of the uvea (iris, ciliary body, or choroid) • Tenting of the cornea or sclera • Low intraocular pressure • (checked by an ophthalmologist only) • Seidel sign • fluorescein streaming away from the laceration site

  41. Imaging • Axial and coronal CT of the eye without contrast • 1 to 2 mm cuts through the orbits

  42. Open Globe injuries: Management • Place eye shield over the affected eye • Do not touch, move eye • Bed rest • Antiemetic therapy (eg, IV ondansetron 0.15 mg/kg, maximum dose: 16 mg) • Pain medication: morphine, fentanyl • Don’t use NSAIDs --> platelet inhibiting properties • Sedation: lorazepam • NPO

  43. Open Globe Injury: Prognosis • Depends on: • Primary closure by ophthalmologist within 24 hours • Blunt trauma has worst outcome • Initial visual acuity • Wound location: posterior lacerations have poorest outcome • Afferent pupillary defect

  44. Open Globe Injuries: Complications • Endophthalmitis: internal eye infection • Endophthalmitis is associated with poor prognosis • Prophylactic antibiotic treatment: • Vancomycin (15 mg/kg, maximum dose: 1 gram) • ceftazidime (50 mg/kg: maximum dose 1 gram) • Organisms: • Bacillus species • coagulase-negative Staphylococcus • Streptococcal species • S. aureus • gram negative organisms

  45. Retinal detachment • Rhegmatogenous detachment: a break in the retina allows fluid to enter the subretinal space • (child abuse/shaking) • Traction retinal detachments: adhesions between the vitreous and the retina pull on the retina
