  1. Algorithms on grids Natasha Gelfand Geometry Seminar Fall 2006

  2. Grids in computer science Geometry Seminar: Algorithms on Grids

  3. Graphics and vision Collision detection, point location Simulation Grids in computer science Geometry Seminar: Algorithms on Grids

  4. Grids for geometric proximity • Isolate and localize interesting events • Proximity is local • “Uniform” grids • Closest pair, k-Minimum enclosing disk • Adaptive grids • quadtrees Geometry Seminar: Algorithms on Grids

  5. Closest pair • Given: n points in the plane • Return pair of pointsrealizing Geometry Seminar: Algorithms on Grids

  6. Grids for points • Computing the grid takes linear time Geometry Seminar: Algorithms on Grids

  7. r Sub-problem • Given a set P and a distance r, verify in linear time if CP(P)<r or CP(P) > r • Insert points sequentially • If CP(P) < r, p, qare in the same orneighboring cells • Can we search a cellin constant time? Geometry Seminar: Algorithms on Grids

  8. Algorithm • If some cell contains more than 9 points, then CP(P)<r • Algorithm: • Insert points into the grid • If cell(p) contains more than 9 points, return CP(P) < r Geometry Seminar: Algorithms on Grids

  9. Algorithm • If some cell contains more than 9 points, then CP(P)<r • Algorithm: • Insert points into the grid • If cell(p) contains more than 9 points, return CP(P) < r • Otherwise, compute • Constant time per point,running time O(n) r Geometry Seminar: Algorithms on Grids

  10. Closest pair • Permute points P=<p1, p1, … , pn> • Let ri = CP({p1, …, pi}) • Can check if ri<ri-1in linear time • Good case: ri = ri-1 • Grid is already built, check in O(1) time • Bad case: ri < ri-1 • Rebuild grid, O(i) time • Trivial bound: O(nk), when closest pair changes k times Geometry Seminar: Algorithms on Grids

  11. Analysis • Let Xi = 1 if ri· ri-1, and 0 otherwise • Running time: Geometry Seminar: Algorithms on Grids

  12. Analysis • Bound Pr[Xi = 1] = Pr[ri < ri-1] • Likelihood that pirealizes CP(Pi) • Expected running time Geometry Seminar: Algorithms on Grids

  13. k-Enclosing minimum disk • Disk of minimum radius that contains k points • Brute forceO(nk) • 2-Opt algorithm: r(P,k) · 2ropt(P,k) k=4 k=3 Geometry Seminar: Algorithms on Grids

  14. Non-uniform grid • Partition P into horizontal strips with at most k/4 points in each strip • Recursive median partitioning • O(n/k) strips Running time: T(n) = n + 2T(n/2) Stop at n < k/4 O(nlog(n/k)) G Geometry Seminar: Algorithms on Grids

  15. Finite centers • Claim: Dopt(P,k) contains at least one intersection point of G • Pf: By contradiction: k/4points k/4points Dopt(P,k) k points At most k/2 points Geometry Seminar: Algorithms on Grids

  16. Algorithm • For each grid intersection point g2G • Compute smallest circle centered at p with k points • k-th order statistic of{||p, g||} • Expected timeO(n) • Return the best of(n/k)2 candidates • Running time: O(n(n/k)2) Geometry Seminar: Algorithms on Grids

  17. Correctness • 2-Opt: r(P,k) · 2ropt(P,k) Geometry Seminar: Algorithms on Grids
