  1. HEAD ELECTRONICS BV • Electronics development • Printed Circuit Boards • Assembling • Mechatronics

  2. One trusted address: HEAD • One-stop-shop • From idea to product • Product-redesign and -engineering • Purchasing of components • PCB work preparation and purchasing • Assembling of SMD and THT (trough hole) • Prototyping, nulseries, serieproduction • Assemble in housing or system, cabling • In-house testing of product and CE-EMC • Deliveries on call (JIT) and as series • Logistics, warehouse, outscoursing • Service, upgrades and repairs

  3. The references: the market • Industrial electronics • Machinery factories • Measure- & control equipment • Led-solutions • Power electronics • Signalling systems • Computer related products • Office products • Consumer electronics

  4. Development: in house and external From idea to functioning product Finding balance in development and product costs • Hardware • Embedded software • Availability of components • Costprice components • Production friendly • Test, selftest • Productiontest • CE, EMC pre-compliant

  5. Projectmanagement One partner for the customer • Projectmanagement • Work preparation • Purchase and logistics • Outscourcing • Planning, controlling • Documentation

  6. PCB work preparation Design, work preparation and purchasing: • Single- and double layer PCB • Multilayer PCB • Panelization with CAM350 • Design/edit with Ultiboard and Pulsonics • Own internet tool for PCB specification • Purchasing of PCB’s

  7. Electronics-assembling SMD Fast, flexible and accurate • Samsung CP 411-421 series SMD • Placing SMD-components to 02 01 • Finepitch 0,4 mm • Laser check SMD • Vision camera for QFP / (µ)BGA • Soltec My Reflow 10 zone furnace • DEK Horizon 2 screenprinter

  8. Electronics- SMD closer look

  9. SMD Samsung 411-421with intelligent feeder system

  10. C1608-560pF C1608560PF9907141301 C1608-560pF C1608560PF9907141301 PART-STATION How It Works? Database Server ETHERNET (TCP/IP) MACHINE FEEDER-STATION BARCODE PRINTER SM FEEDER DeviceNet REEL BARCODE READER REEL BARCODE READER Feeder ID Reading Feeder Event (insert, remove, …) DOCKING-CART

  11. Assembling conventional • Placing of all other components • Assemble to systems and mechatronics • Programming and loading of software • Routine testing

  12. Wave soldering • Wave soldering N2 with the Soltec “Deltawave” • In-line wave soldering N2 met EPM IBL

  13. Selective soldering Selectiv soldering with the Soltec My Selective 6745

  14. Elektronics-Mechatronics • Assemblies of PCB’s, cabling and housings • Cleaning of PCB’s • Coating and gluing • Potting of PCB’s in housings • Cabling in house or outscourced

  15. Coating machine forcoating and glueing

  16. Testengineering • PCB: Visual, probe tester, sleeves /microscope • SMD: AOI (Viscom), X-ray (Dage 2 M pixel) • CE- precompliant EMC • Product: Visual, Functional, In-circuit, self-test, climate-test

  17. Service and repair • After sales service, upgrades, repair • For hard- and software • During the lifecycle of your product • Redesign and use of other/newer parts

  18. Logistics Year order, rolling forecast Purchasing and incoming goods Identification / inspection / part storage Packing following instructions Storage, consignation

  19. Transportation Just in time, track and trace Destinations to customer and endcustomer Transportation boxes with UPS in NL, UK (Europe) Pallet Benelux with Wesseling Transport Sassenheim Worldwide via expedition centres, airport etc.

  20. Live on the Word Wide WEB

  21. The news from HEAD

  22. Request for proposal

  23. Memberships • FHI: Federatie Het InstrumentExhibition Electronics & Automation 2003 - 2009 • Nevat: Nederlandse Vereniging Algemene Toelevering Specific:- Member and secretary of the Technology taskforce- Managing the website for RoHS and Technology- Production 70% RoHS and 30% with Pb (sea shipping, automotive, petrochemical-ATEX etc)

  24. Your contact persons: Managing Director: Arie van Leeuwen Marketing & Sales: Eric Verkerke Operations & Finances: Arjan van der Ploeg Head Electronics BVAmbachtsweg 172222 AH Katwijk ZHtel.: 071-4029154fax.: 071-4030091e-mail: info@head.nl Internet: www.head.nl

  25. Development, production and assembling of electronics? We will be pleased to do it for you!
