  1. Class diagrams Terézia Mézešová

  2. Class diagram • static diagram, part of UML describing classes structure of system • shows classes, their attributes and methods and relationships between classes • classes represent main interactions in system and classes to be programmed

  3. Classes • name • attributes • methods • abstract classes have name in italics

  4. Attribute and method syntax • visibility name : data_type • visibility name ( parameter_name : parameter_type, ... ) • visibility: • +   public • -    private • #   protected • /   derived • _   static

  5. Relationships class level: • generalization • realization instance level: • association • aggregation • composition

  6. Generalization • "is a" relationship, inheritance • instance of subtype is also instance of superclass

  7. Realization • one element realizes the behavior of second element • e.g. relationship between classes and interfaces showing that the class realizes methods offered by the interface

  8. Association • represents static relationship between objects of two classes

  9. Aggregation • "has a" relationship • type of association relationship • can only involve two classes

  10. Composition • "owns a" relationship • stronger than aggregation • if the container class is destroyed, all contained classes must be destroyed as well

  11. Other types of relationships • dependency - one class uses another at some point • multiplicity: • 0..1 - no or one instance • 1 - exactly one instance • 0..* - zero or more instances • 1..* - at least one or more instances

  12. Thank you for your attention
