  1. PADFRAME Michael Karagounis

  2. Questions & Answers LVDS 1 Question: Do your LVDS circuits meet the specs of the LVDS standard Answer: No, but they are compatible to commercial LVDS circuits

  3. LVDS Driver Restrictions • Only Thin-Gates Transistors -> max. voltage 1.2-1.5V • Maximum output voltage before current source leaves saturation  VDD- 250mV • LVDS standard defines a common mode range of 0 – 2.4V for the LVDS receiver •  A commercial LVDS receiver (e.g. FPGA input) is able to process the data signal Slide 3

  4. LVDS Receiver Restrictions • Rail-to-Rail Input stage max. input voltage limited by VDD • Option1: • To process standard LVDS signal 1.2V +/- 175mV VDD >= 1.375 VOption2: • Override Driver Common Mode Voltage Option 3: • Use LVDS transceiver chip in test setup Tyhach et al., A 90-nm FPGA I/O Buffer Design With 1.6-Gb/s Data Rate for Source-Synchronous System and 300-MHz Clock Rate for External Memory Interface, IEEE JSSC, Sept. 2005 Slide 4

  5. Questions & Answers LVDS 2 Question: Does your receiver reach an intermediate state of high current consumption? ( Is your receiver Fail-Safe?) Answer: No, because we bias the receiver input (Yes it is Fail-Safe)

  6. Failsafe-Biasing • bias voltage close to VDD/2 is defined by resistive divider • bias is fed to RX inputs by high ohmic resistors • additional high ohmic resistor connected between inverted input & ground introduces voltage difference @ inputs Maxim Application Note 4007,Robust Fail-Safe Biasing for AC-Coupeled Multidrop LVDS Bus, 2007

  7. AC Coupled Communication Scheme TX RX CMOS OUT approach allows to study AC-coupled communications scheme  DC – Balancing can be achieved by sending commands with wrong chip id & complementary data during command data transmission breaks

  8. Self-Biasing of LVDS Receiver consequence of power-on sequence: LVDS receiver has to be fully functional before the precise reference circuit is available LVDS receiver has to be self biased LVDS receiver biasing has to be reliable • modified version of low voltage beta-multiplier (M1, R2 & R3 have been added) (Baker, CMOS, 2nd edition, IEEE press p. 629) • reference current is defined by R1 (R1=R2=R3) • circuit has only one dominant pole  easy to compensate • addition of transistor M1 gives first order temperature compensation (Friori, A New Compact Temperature compensated CMOS current reference, IEEE Trans. Circ. & Sys., 2005) • start-up circuit enforces current flow in the circuit and switches off during normal operation

  9. Reference Current vs. Supply Voltage reference current stays stable for VDD > 1.0

  10. Reference Current vs. Temperature variation of referene current < 300nA with temperature

  11. Monte Carlo Simulation Imean=23.7 uA, Isigma=1.3 uA, Imin=17.5uA,Imax=32.5uA

  12. Monte Carlo: RiseTime & Duty Cycle Rise Time Duty Cycle Mean:217psSigma:20ps Mean:50.4%Sigma:0.5% Slide 12

  13. STATUS: LVDS circuits • Layouts have been adapted to the longer bondpad pitch of production chip (with respect to the test chips) LVDS driver has now more width & less height • Metalization has been changed from LM to DM • Design has been ported fom Tripple-Well to T3 substrate isolation option • LVDS biasing & failsafe circuits designed & layouted OLD NEW Extraction & simulations of parasitics has not been done yet LVDS driver

  14. Pad Frame 50 Power 22 Digital I/O 13 Analog I/O 21 Probe 128 Overall133 Maximum External power routing  Possibility to study different powering schemesPads grouped together to independent supply domains

  15. Bond Pads • 150um bond pitch • Two different bond pad sizes  100um x 200um I/O pads  250um x 200um power pads (corresponds to two I/O pads) • ESD devices, vertical M2 & horizontal M3,MQ,MG supply rail routing below the pad • Only supply voltage & ground of according supply domain is routed below the pads • VDDT3 rail is either connected to dedicated pad (digital domain) or shorted to VDD

  16. Bond Pad Layout SpacerCell CutCell • ESD devices are located in upper part of the pad • lower part has been kept empty for TSV • Spacer cells are placed between the pads • cut cells seperare pads of different supply domains & provide bus to bus ESD protection ESD 120um empty for TSV tests Analog InputPad

  17. Question & Answer ESD Question: Do you follow a dedicated ESD strategy? Answer: Yes, we follow the recommendation of the IBM ESD manual!

  18. ESD strategy Ground-to-Supply Discharge RC-Clamp Input Pad Bus-to-Bus Protection Output Pad • I/O pads are connected via reverse-biased diodes to the supply rails • Inputs have seconde diode pair & series resistor limit max. voltage @ gate of transistor • Reverse biased diodes between VDD & GND rails discharge path from GND to VDD • RC-Clamp shorts VDD & GND in case of positive going ESD event  discharge path from VDD to GND • Ground busses are protected by antiparallel diodes

  19. Status Padframe • All needed pad types have been developed: Supply: Analog VDD Digital VDD VDD 3.3V Wide VDD GND Wide GND Substrate VDDT3 Digital: CMOS IN CMOS OUT LVDS IN LVDS OUT Analog: Analog IN Analog OUT Wide Analog OUT Construction of pad frame ongoing

  20. OLD & BACKUP SLIDES

  21. LVDS Chip Submissions • 21-Jul-2007: first test chip submitted to UMC 130nm via Europractice mini-asic run real hardware test of chosen architecture for use in FE-I4 • 24-Mar-2008: 4 channel LVDS transceiver chip submitted to IBM 130nm (LM) via CERN  for use in a SEU test setup characterization of new cables and flex types • 15-Sep-2008: LVDS driver with tristate option submitted to IBM130nm (DM) via MOSIS IBM 130nm (LM) UMC 130nm IBM 130nm (DM) 2mm 1.8mm 1.5mm 2mm 1.5mm 0.8mm

  22. LVDS Transceiver-Chip Test Setup Type 0 Cable Adapter Type 0 Cable Adapter Biasing developed by A. Eyring • 4 x LVDS receiver  CMOS output & CMOS input  LVDS driver • Configurable Chain: LVDS receiver  LVDS driver • 2x Type 0 cable adapter: LVDS signal  Type 0 cable  termination resistor  LVDS receiver

  23. Measurements LVDS Transceiver Chip Measurement with active differential probe and 100 Ohm termination resistor on PCB @ 1.2V supply LVDS Rx In  LVDS Tx Out @ 320 MHz Clock LVDS RX In  CMOS Out CMOS In  LVDS TX Out Clock-Rate Input Common Mode Voltage Clock-Rate 1.05V 320MHz 320MHz 600mV 160MHz 160MHz 150mV 40MHz 40MHz Increased biased currents needed for LVDS RX to operate@ high frequences & low common mode voltages measured by L. Gonella

  24. LVDS Transceiver-Chip Eye Diagram • Test-Setup includes: • One – 4 meter twisted pair 36 AWG wire(0.127 mm copper diameter) • 160 Mbps data rate • Eye pattern is 317mV, need > 200mV • No errors @ 150 Mbps or 350 MbpsError rate better than 2*10-13 @ 350 Mbps 350Mbps without cable 160Mbps with cable M. Kocian, D. Nelson, Su Dong SLAC

  25. CMOS Input & Output Buffers Input Buffer Output Buffer Schmitt-Trigger with 200mV hysteresis • Cascoded structures have higher snapback voltage • Have been used in LVDS-Transceiver chip developed by D. Gnani
