Pipe Cutting System

3. The evolution of pipe cutting Patented products Designed in Finland Pipe Cutting System

5. Pipe Cutting System The Exact way to cut pipe Unique Exact method for cutting pipes The Exact pipe cutting system is designed and made for professional use. All pipe cutters are lightweight and easy to carry and operate on-site. You can use the Exact pipe saws to cut steel, plastic, copper, cast-iron, stainless steel and multi-layer pipes. In our product range we have also special pipe saws for cutting ventilation pipes and for cut and bevel plastic pipes in one process. Our pipe cutting systems have been used for over 10 years and our patented technology has been used globally by many world-leading brands. You have everything you need in one handy shoulder bag.

6. Pipe Cutting System Perfect cut ends are ready to weld or join When welding pipes it is most important to have straight and clean cut ends. With Exact pipe cutting system the pipe ends fulfil these needs. Pipes are immediately ready to be welded or joined together by other means. Exact saws are incredibly fast. It takes less than 20 seconds to cut Ø170 mm with 5 mm wall. Exact method is also fire safe, energy saving and safe for the user and the working environment. Each model has a huge cutting range and one person can easily handle also large pipes by themself.

7. Pipe Cutting System Great improvements in ease of work and working safety as well as fire safety After cutting, the cut ends of the pipe are straight and ready to be connected The Exact method provides an extremely fast cutting speed which saves working time significantly Ease of work and better working conditions, as the Exact method is designed to be used in worksite conditions (on-site) and it is very easy and light to use The cutting process is also very safe to the user. The machine is tightly fixed to the pipe and cannot rush from the user’s hands The method is environmentally safe because the cutting does not produce much sparks or dust Multitude of different pipe sizes and material can be cut with one machine Pipes can be cut anywhere that electric power is available All pipe materials such as steel, stainless, cast-iron, copper, plastic, multi-layer can be cut Workbenches or big tripod stands are not needed Return on investment (ROI) over a short period of time. Benefits of Exact Pipe Cutting System O O O O O O O O O O O

8. Pipe Cutting System Exact pipe cutting machines are designed and intended to the following industries: O O O O O O O O O O O O O House building Shipyards Industrial pipe installations, pulp, paper, chemical, boiler, pump stations etc. Worksites for fresh water and waste water systems Municipal heating and cooling systems Municipal gas lines Municipal site works as hospitals, office buildings, large public buildings Maintenance and repair of medium and large size industry Power stations Installation companies that carry out pre-assembly work prior to site installation, sprinkler systems etc. Pipe repairs for old buildings Duct pipe installations Etc.

9. Pipe Cutting System Everything you need in one shoulder bag The Exact pipe cutting system is designed and made for professional use. All pipe cutters are lightweight and easy to carry and operate one-site. The carton contains a shoulder bag, pipe saw, pipe supports (not with V1000), a saw blade in the machine, allen keys for changing the blade and for adjusting the saw, operating instructions, and the DVD disc with demonstrations and instructions. For example: Exact PipeCut 280E carton contains: 1. PipeCut shoulder bag 2. Exact PipeCut 280E pipe saw 3. Pipe supports 4 pcs 4. Operating instructions manual 5. Allen keys 5 mm and 2 mm fitted to the machine 6. TCT blade Ø 165 mm fitted on the machine 7. DVD-video disc containing instructions and demonstrations

10. PipeCut Saws

11. PipeCut 170 Lightweight and handy PipeCut 170 has a wide cutting range it weights only 5,7 kg. PipeCut 170 can be used for cutting both metal and plastic pipes. It is very comfortable and light to use and it cuts the pipes extremely fast. Model Voltage Power No-Load speed Blade diameter Weight Range of use Ø Max. pipe wall PipeCut 170 110 V and 230 V / 50-60 Hz 1010 W 4000 / min 140 mm 5,7 kg 15 mm – 170 mm 6 mm steel, 14 mm plastics

12. PipeCut 170E Powerful, lightweight and handy PipeCut 170E can be used for cutting both metal and plastic pipes. Because of its adjustable speed and steady torque feature it is ideal for cutting stainless steel and cast iron pipes. It offers hi-end performance for pipe fitting professionals. Model Voltage Power No-Load speed Blade diameter Weight Range of use Ø Max. pipe wall PipeCut 170E 110 V and 230 V / 50-60 Hz 1200 W 1600-3500 / min 140 mm 5,7 kg 15 mm – 170 mm 8 mm steel, 14 mm plastics

13. PipeCut 220E Efficiency and wide cutting capacity with PipeCut 220E. It can be used for cutting both metal and plastic pipes. It has adjustable speed and steady torque control. Because of its robust construction it is ideal for universal use at building sites and for industrial installations. Model Voltage Power No-Load speed Blade diameter Weight Range of use Ø Max. pipe wall PipeCut 220E 110 V and 230 V / 50-60 Hz 1200 W 1600-3500 / min 140 mm 6,9 kg 15 mm – 220 mm 8 mm steel, 12 mm plastics

14. PipeCut 280E Most effective pipe cutting with the powerful PipeCut 280E. It is ideal for cutting metal pipes because of it’s two speed selection, automatic fuse and torque control. It works well even with the hardest cast-iron pipes. It is also suitable for cutting plastic pipes because it can be attached to a vacuum cleaner and it can cut very thick pipe walls. Model Voltage Power No-Load speed Blade diameter Weight Range of use Ø Max. pipe wall PipeCut 280E 110 V and 230 V / 50-60 Hz 1750 W I = 2900 / min, II = 3900 /min 165 mm 9,0 kg 40 mm – 280 mm 10 mm steel, 38 mm plastics

15. PipeCut 360E The largest universal pipe saw in the Exact range. It has two speed selection, soft start, automatic fuse and torque control. It is suitable even for the hardest cast-iron pipes. It is also suitable for cutting plastic pipes because it can be attached to a vacuum cleaner and it can cut very thick pipe walls. Because of its robust design and construction plus large capacity it is ideal for universal use on-site. Model Voltage Power No-Load speed Blade diameter Weight Range of use Ø Max. pipe wall PipeCut 360E 110 V and 230 V / 50-60 Hz 1750 W I = 2900 / min, II = 3900 /min 165 mm 14,5 kg 75 mm – 360 mm 10 mm steel, 38 mm plastics

16. PipeCut P400 Cut and bevel plastic pipes in one process. Unique method for plastic pipe installations. You just need to cut around a pipe and you get a nice 15 degrees bevel at the same time. You can use the PipeCut P400 saw also only for cutting or only for just bevelling plastic pipes. Model Voltage Power No-Load speed Blade diameter Weight Range of use Ø Max. pipe wall PipeCut P400 110 V and 230 V / 50-60 Hz 1010 W 4000 / min 150 mm 6,0 kg 100 mm – 400 mm 25 mm cut, 22 mm bevel cut

17. PipeCut V1000 New era for spiral duct cutting. Exact Pipe Cut V1000 offers ease of use and a huge size range for cutting spiral ducts. The cut ends are straight and ready to be connected. As an optional extra we have special pipe supports for V1000 that can hold spiral ducts from 75 mm to 1000 mm . Model Voltage Power No-Load speed Blade diameter Weight Range of use Ø Max. pipe wall Pipecut V1000 110 V and 230 V / 50-60 Hz 1010 W 4000 / min 155 mm 6,0 kg 75 mm – 1000 mm 1,5 / 6 mm

18. PipeCut Blades

19. PipeCut blades Exact has a wide range of specially designed blades for Exact PipeCut saws. High quality cutting blades are designed for different purposes and for different PipeCut machines. With the correct blade you can achieve optimal cutting results. Blade Type Blade Dimensions For Materials For Machine Types ØBore Kerf Body Teeth TCT 140 140 x 62 x 1,8 x 1,4 x 46 Steel, Copper, Plastics PC 170, 170E, 200, 220E, 360 Cermet140 140 x 62 x 1,8 x 1,4 x 46 Steel, Stainless, Copper, Plastics PC 170, 170E, 200, 220E, 360 Diamond 140 140 x 62 x 2,0 x 1,8 Cast iron PC 170, 170E, 200, 220E, 360 Diamond X140 140 x 62 x 2,7 x 1,5 Castiron, Ductile (nodularcastiron) PC 170, 170E, 200, 220E, 360 TCT 165 165 x 62 x 1,8 x 1,4 x 52 Steel, Copper, Plastics PC 280E, 360E Cermet 165 165 x 62 x 1,8 x 1,4 x 52 Steel, Stainless, Copper, Plastics PC 280E, 360E Diamond X165 165 x 62 x 2,7 x 1,5 Cast iron, Ductile (nodular cast iron) PC 280E, 360E TCT P165 165 x 62 x 1,8 x 1,4 x 40 Plastics (PE, PP, PVC, etc.) PC 280E, 360E Cermet V155 155 x 65 x 1,6 x 1,4 x 58 Thin wall ventilation pipes PC V1000 TCT P150 150 x 62 x 1,8 x 1,4 x 40 Plastics (PE, PP, PVC, etc.) PC P400, 360 Cut Bevel 148 x 62 x 2/30 x 40/8 Plastics (PE, PP, PVC, etc.) PC P400

20. Other Products

21. Bevel Disc Adjustable bevel tool for plastic pipes can make 15 degree bevel to all plastic pipes from Ø 60 mm to Ø 120 mm. The Bevel Disc is operated with any cordless drill that has 13 mm drill chuck. It takes only a few seconds to make a nice bevel to plastic pipe.

22. Pipe Support V1000 We recommend that you use the Exact Pipe Support V1000 to support the pipes when using the Exact PipeCut V1000 pipe saw. These pipe holders are specially designed to be used with the Exact PipeCut V1000 pipe saw. They can be used with pipes from 75 mm (3”) up to 1000 mm (40”). The pipe supports are sold separately. Each set of Pipe Support V1000 contain 3 pcs of two position supports in a shoulder bag.

23. Thank You
