Understanding Electricity: The Basics of Voltage, Amps, and Resistance

DESCRIPTION

Electricity is the movement of electrons from one atom to another, creating a flow that powers our devices. Three key factors influence this flow: voltage (the pressure on electrons), amps (the volume of flow), and resistance (the hindrance to that flow). To create a functioning circuit, it must be a closed loop, allowing electrons to move. The relationship between these factors is governed by Ohm's Law, where voltage (V) equals amps (A) times resistance (R). Understanding these concepts is crucial for anyone working with or studying electricity.

1 / 9

Télécharger la présentation

Understanding Electricity: The Basics of Voltage, Amps, and Resistance

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Electricity

  2. What is it?? • Movement of electrons from one atom to another • Trying to create a balance

  3. Three factors • Voltage • Pressure on the electrons. • Amps • Measurement of volume of flow. • Resistance • Resistance to flow.

  4. Just Like This Poor Sucker

  5. What does it take? • To make amps, circuit must be a loop • The more electrons moving means more work done • The more pressure (voltage) applied means more work done

  6. Measuring • Voltage • Live or dead circuit - whatever you want • Amps • Must be in ‘series’ in a live circuit • Resistance (Ohms) • Circuit MUST be dead

  7. Relationships • The three measurments all work together • One cannot change without affecting another

  8. Ohm’s Law • V = AxR • A = V / R • R = V / A V AXR
