  1. Forces (Part 2)

  2. Free Body Diagrams • A free body diagram is a diagram used to describe the forces acting on an object • It only describes the forces acting on ONE single object, and not other objects connected to it • Forces are represented by arrows. • Direction of arrow represents direction of force • Length of arrow represents magnitude of force • Each arrow must be labelled

  3. Free Body Diagrams • Objects are typically represented either using a silhouette of the object itself, or a simplification thereof. • E.g. free-body diagram of a cow in free fall COW Gravitational Force (Weight) Gravitational Force (Weight)

  4. Types of Component Forces • Forces can be classified into 2 broad categories: contact forces & long range forces. • Contact forces require an object to physically touch something else in order for the force to take effect • Non-contact do not require physical contact for the force to take effect

  5. Types of Component Forces

  6. Half-Time • Breaking The Magician’s Code - Levitation Tricks • 1) Levitating Girl 1 (https://www.youtube.com/watch?v=OAHsY_w4lcM) • 2) Levitating Girl 2(https://www.youtube.com/watch?v=F64L4CtGshw) • 3) Flying(https://www.youtube.com/watch?v=O0MOVgzSU_E) • 4) Walking on Water(https://www.youtube.com/watch?v=z0ukAescNC0)

  7. Gravitational Force • Weight is simply the gravitational force exerted by the Earth on an object • Formula: Gravitational Force = mg, • m = mass of the object (which the force is exerting on) • g = gravitational field strength. This is also identical to the acceleration due to free fall, which is 10 ms-2. • It is advisable to use “mg” instead of “W” or any other symbol to represent weight or gravitational force.

  8. Gravitational Force • To draw gravitational force of a free body diagram, locate the center of gravity of the object (typically the center of the object) • Draw an arrow downwards (towards the center of the Earth) • Label the arrow “mg” mg

  9. Normal Contact Force • Sometimes called “normal reaction force” • The normal contact force is the force objects exert on each other when they press each other • Normal contact force is always a push force • Usually represented by symbol “N” or “n” • “Normal” here refers to “perpendicular” • The direction of normal contact force is always perpendicular to the surface of contact

  10. Normal Contact Force • To draw normal contact force on a free body diagram, locate the surface of contact • Draw a force originating from the middle of the contact surface, going perpendicular and away from the surface • Label the arrow “N” or “n” N N Object on an inclined surface Object on the ground

  11. Tension • Tension is the force exerted by a taut string, rope, spring, etc. pulling on an object • Usually represented by symbol “T” • Tension is always a pull force • To draw tension in a free body diagram, locate the point where the string (for e.g.) is pulling the object • Draw an arrow originating from that point, in the same direction as the string • Label the arrow “T”

  12. Tension • Consider this scenario: • Ball suspended from the ceiling with a string • Free Body Diagram of the ball: T mg

  13. Tension • Consider this scenario: • Object being pulled along the ground by a string • Free Body Diagram: N T mg

  14. Friction • Friction is the contact force that opposes of tends to oppose motion between surfaces in contact • There is no symbol for friction. Either spell the word out in full, or use “Ffriction“ • To draw friction in a free body diagram, identify the contact surfaces, and draw an arrow parallel to the surfaces, in the direction which would oppose motion

  15. Friction moving to the right • If an object is moving in one direction, friction acts in the opposite direction • If friction is holding up an object which would otherwise slide away, friction acts in the direction opposing the sliding Friction Friction

  16. Rules for Drawing FBDs • Step 1: draw the object first. Do NOT draw other objects connected to it • Step 2: identify the center of gravity, draw and label the mg of the object • Step 3: draw all other component forces. The length of the arrows should be proportional to the magnitude of the force. • Note: NEVER draw the resultant force on a Free Body Diagram!! If there is a need to indicate the resultant force, draw it outside the FBD.

  17. Example • Draw the FBD of an object which is being pulled by a rope up a rough slope T N Friction mg

  18. Exercise 2 • An elevator weighs 1000 kg and is pulled upwards by a cable. • (a) Draw the free body diagram of the elevator • (b) If the elevator is accelerated upwards at 0.1 ms-2, calculate the tension in the cable.
