  1. Engineer Capabilities by Unit as of October 2011

  2. E SAPPER E E E E E HQ CBT ENG CBT ENG CBT ENG OBST HBCT ENGINEER COMPANY Mission:Increase the combat effectiveness of the maneuver commander by accomplishing mobility, countermobility, survivability, and general engineering tasks. Capabilities: Construct obstacles and defensive positions, obstacle breaching operations; survivability advice, assistance, and equipment to maneuver elements in the construction of fighting positions for individuals and weapons systems; prepares and executes target demolition such as bridge destruction, road and runway craters, abatis or other roadblocks, and tunnel and railroad destruction; prepares and executes obstacles or other combat engineer missions to degrade enemy mobility, including berms, ditches, log posts, log cribs and wire entanglements; emplaces mines and provides technical assistance in the emplacement of mines; supports combined arms obstacle breaching operations; when required, fights as Infantry Assignment (Echelon): One per Maneuver Battalion, TOE 07205G000. Section I TOE BOA: One per Maneuver Battalion, TOE 07205G000. Capability Trace: Div Mechanized Eng Company Doctrinal Link/Rule Rationale: JP 3-06, Modularity O&O, FM 3-0, FM 3-90.3, FM 3-20.96, FM 3-100.38. I Issue: None Discussion: Recommendation: Rule of Allocation: Embedded in Combined Arms Battalion (2 per HBCT). 4-0-72-76 •• ••• •• 2-0-8-10 0-0-8-8 1-0-28-29 1 - M113A3 2 - HEMTT 3 - JAVELIN 1 - Trk Cgo 2 - M548A1 3 - HMMWV 2 - Dispenser (Volcano) 1 - Tool Kit, Eng Plt Carp 2 - Sketch Set Surveying 6 - Tool Kit, Eng Sq W/chest 9 - M2A3 (Base Is M113A3) 1 - Tool Kit Pioneer, Eng Cbt Plt 6 - Demo Set Explosive 6 - Tool Kit Pioneer, Eng Sq 1 - 3kw Gen 3 - ACE (Base Is Dozer) 1 - 2kw DC Gen 6 - Trl Cgo 1½ T 2 - SOF Demo Kit 1 - Water Trl 2 - SEE 18 - HSTAMIDS

  3. E SAPPER E E E E E HQ CBT ENG CBT ENG CBT ENG OBST IBCT ENGINEER COMPANY Mission:Increase the combat effectiveness of the IBCT by accomplishing limited mobility, countermobility, survivability, and sustainment engineering missions, or to perform infantry combat missions when required. Capabilities: Prepares/maintains essential combat routes in the brigade area; assists in assault of fortified positions; assists maneuver units in assault breach of obstacles; obstacle breach operations; field engineering advice, assistance, and limited equipment capability to maneuver elements to construct fighting positions for individuals and weapon systems; emplaces and/or assists in the emplacement of mines; creates obstacles to delay enemy mobility including berms, ditches, log/timber obstacles, and wire entanglements; prepares targets for demolition; carries out demolitions if required; when required, fights as Infantry. Assignment (Echelon): Organic to the Brigade Troops Battalion, TOE 77405G000. Section I TOE BOA: One per IBCT, TOE 77302G000. Capability Trace: Div Light Infantry Division Eng Company Doctrinal Link/Rule Rationale: JP 3-06, Modularity O&O, FM 3-0, FM 3-90.3, FM 3-20.96, FM 3-100.38. I Issue: None Discussion: Recommendation: Rule of Allocation: Embedded in Brigade Troops Battalion (1 per IBCT). 4-0-68-72 •• ••• •• 2-0-6-8 0-0-6-6 1-0-28-29 4 - JAVELIN 2 - Sketch Set Surveying 6 - Demo Set Explosive 7 - Trk Dump MTV w/e 1 - Gen Set 2kw DC 3 - Trk Dump MTV w/e w/w 1 - 10kw Gen On M116A2 Trl 2 - DEUCE 1 - Ldr 2 ½ Cu Yd 8 - Flt Bed Trl M1082 LMTV 1 - Pneu Tool & Compressor 2 - Tool Kit Carp Eng Plt 2 - SOF Demo Kit 6 - Tool Kit Carp Eng Sq 4 - SEE 1 - Tool Kit Pioneer Eng Cbt Plt 1 - Trk Cgo LMTV 6 - Tool Kit Pioneer Eng Sq 4 - HMMWV Cgo 12 - HSTAMIDS

  4. E E E E E HQ CBT MOB CBT MOB CBT MOB MOB SPT SBCT ENGINEER COMPANY Mission:Provides organic mobility, force protection, limited countermobility, survivability, and sustainment engineering to the Stryker Brigade Combat Team. Capabilities:Organic force protection and mobility support; limited countermobility, survivability and sustainment engineering support by taking risk in force protection and mobility support; reduction assets for existing natural and reinforcing obstacles in open, rolling terrain, complex terrain and urban environments; medium weight bridging assets for limited wet and dry gap crossing; Engineer Reconnaissance Teams to augment the RSTA Squadron by taking risk in force protection and mobility support; emplaces and provides technical assistance in the emplacement of mines; advice to maneuver commanders on employment of scatterable mines; and performs combat infantry missions in the role of Infantry. Assignment (Echelon):Organic to the Stryker Brigade Combat Team, TOE 47100F300. Section I TOE BOA:One per SBCT, TOE 47100F300. Capability Trace: None Doctrinal Link/Rule Rationale: JP 3-06, FM 3-0, FM 3-90.3, FM 3-20.96, FM 3-21.31, FM 3-34.221, FM 3-100.38. I Issue: None Discussion: Recommendation: Rule of Allocation: 1 per SBCT E 6-0-114-120 SAPPER ••• •• ••• 2-0-11-13 1-0-22-23 1-0-27-28 8 - Bed Cgo Demount 8x20 (PLS) 2 - Trk Cgo MTV 1 - Bridge Erection Set Fixed (MGB) 6 - DEUCE 1 - Bridge Fixed 100ft (MGB) 4 - Trk Trans 8x8 (CBT) 3 - Disp Mine (Volcano) 2 - HMMWV Armt Carr Armd 9 - Chassis Trl 2 1/2 T 6 - HMMWV Exp Cap Up Armd 6 - Launcher Mine Clearing (MICLIC) 4 - Trl PLS 8x20 1 - HMMWV Hvy Variant 1 - Trl Cgo MTV 6 - SEE 7 - Trl Cgo High Mob 3/4 T 1 - HMMWV Cgo 2 - Water Trl 9 - Eng Squad Veh (ESV)

  5. E E E E E SAPPER SAPPER SAPPER SAPPER HQ SAPPER COMPANY Mission: Executes mobility, countermobility, survivability tasks, and provides support of general engineering missions in support of Maneuver and Support units to enable force application, focused logistics, and protection. Reinforces engineers in Maneuver BCTs. Capabilities: Provides training readiness and oversight of assigned sapper platoons; Provides battle command for 3-5 sapper, assault, obstacle, clearance, or tactical bridge platoons operating as an EMT in the execution of mobility, countermobility, survivability missions; Improve lane markings in the BCT area; Can provide 660 manhours/day for general construction labor tasks to vertical, horizontal, or light construction companies during general engineering missions. (10 hours/day for E5 and below) Assignment (Echelon): To an engineer battalion attached to a Maneuver Enhancement Bde; may augment Maneuver BCTs conducting combat operations. Section I TOE BOA: 1 Sapper Company per Clearance Company conducting clearance operations in LR 2, 3, 4; 1 Sapper Company per Maneuver BCT executing combat operations in LR 1; 1.52 Sapper Companies per general construction workload in LR 1, 2, 3, and 4 Capability Trace: EN Corps Wheeled, Corps Mechanized, Corps Airborne, and Corps Light Battalions Doctrinal Link/Rule Rationale: JP 3-06, FM 3-0, FM 3-90.3, FM 3-20.96, FM 3-100.38. I Issue: None Discussion: Recommendation: Rule of Allocation: 1 per Clearance Company conducting clearance opns in LR2-4; 1 per BCT executing cbt opns in LR1; 1.52 gen const workload in LR1-4. 5-0-86-91 •• SRC ••• SRC 2-0-11-13 1-0-25-26 7 - ESV 6 - MATILDA Robot 6 - ESV w/LMS 3 - ENFIRE 6 - 1.5T Trl 5 - MCS-ENG 6 - Mine Roller 2 - HMMWV 24 - HSTAMIDS 1 - CPP 6 - RCU 2 - ¾ T Trl 6 - Demo Kit w/SOF Supplement 1 - LMTV 6 - Pioneer Tool Kit 1 - Water Trl 6 - Hand-held FLIR 2 - CDWS 6 - Carpenter Kit

  6. E E E E E E E E E ASLT Bridge Breach CMOB CMOB OBST ASLT ASLT MAC HQ • • 0-0-6-6 0-0-14-14 MOBILITY AUGMENTATION COMPANY Mission: Conducts assault gap crossings, mounted and dismounted breaches, and emplaces obstacles in support of Maneuver and Support units to enable force application, focused logistics, and protection. Capabilities: Provides training readiness and oversight of assigned assault and obstacle platoons; battle command for 3-5 assault, obstacle, or sapper platoons operating as an EMT in the execution of mobility/countermobility missions; Enables a Maneuver BCT to conduct 4 assault gap crossings; an IN/Stryker BCT to conduct 4 mounted breaches; an HBCT to conduct 2 mounted breaches; a Maneuver BCT to conduct 4 additional dismounted breaches; emplace 4432 linear meters of fix/disrupt tactical obstacle frontage without reload in support of Maneuver and Support units; employ 2 breach modules to execute hasty route clearance operations in support of Maneuver and Support units. Assignment (Echelon): To an engineer battalion attached to a Maneuver Enhancement Bde; may augment Maneuver BCTs conducting combat operations. Section I TOE BOA: 1 Mobility Augmentation Company per IN/Stryker BCT executing combat operations in LR 1; 2 Mobility Augmentation Companies per HBCT executing combat operations in LR 1. Capability Trace: EN Corps Wheeled, Corps Mechanized, Corps Airborne, and Corps Light Battalions Doctrinal Link/Rule Rationale: JP 3-06, JP 3-15, FM 3-06.11, FM 3-90.2, FM 3-90.3. I Issue: None Discussion: Recommendation: Rule of Allocation: 1 per IBCT/SBCT executing cbtopns in LR1; 2 per HBCT executing cbtopns in LR1. 5-0-92-97 •• ••• ••• SRC SRC SRC 2-0-11-13 1-0-25-26 1-0-31-32 • 0-0-16-16 2 - HMMWV 9 - ESV 6 - Demo Kit 1 - CPP 4 - ESV w/LMS 4 - Urban Br Kit 2 - ¾ T Trl 4 - ACE 4 - Hand-held FLIR 1 - LMTV 4 - Mongoose 2 - RF Jammer 1 - Water Trl 4 - Mine Roller 4 - VOLCANO 1 - CDWS 4 - Mine Rake 4 - SSL 5 - MCS-ENG 8 - HEMTT 4 - Hydr Pckt Pndr 4 - MTV Trailer 6 - HAB or REBS w/CBT 4 - RCU 8 - HSTAMIDS 4 - APOBS

  7. E E E E E E E E E E CLEARANCE AREA AREA AREA RTE RTE RTE RTE RTE HQ CLEARANCE COMPANY Assignment (Echelon): To an engineer battalion supporting a Support unit; can be assigned to an Engineer Battalion that is attached to an Expeditionary Engineer Brigade under the operational control of a Theater Protection Command. Section I TOE BOA: 1 Clearance Company per division (min) or per 255 km (156 miles) of two-way route requiring clearance per day in LR 2; 1 Clearance Company per 255 km (156 miles) of two-way route requiring clearance per day in LR 3 and 4 Capability Trace: New organization Doctrinal Link/Rule Rationale:JP 3-01, JP 3-06, JP 4-01.6, FM 3-0, FM 3-100.38. Mission: Conducts detection and neutralization of explosive hazards along routes and within areas in support of Support units to enable force application, focused logistics, and protection. Capabilities: Provides training readiness and oversight of assigned route and area clearance platoons; Provides mission command for 3-5 route, area, sapper, or light construction platoons operating as an EMT in the execution of route or area clearance missions; Can clear a total of 255 km (156 miles) of two-way route per day (3 routes of 52 miles each); Can clear a total of 2 acres (8093 m2) per day (2 areas at 1 acre each). I 6-0-159-165 Issue: ODS, OEF, OIF Lessons Learned reflected need for new organization with unique capabilities (equipment/skill sets). Discussion: Limited clearance equipment on hand as contingency stock, currently not type-classified. Anticipate requirement for 15 Clearance Companies. Recommendation: Type Classify Equipment and get into the POM cycle Rule of Allocation: 1 per division (min) or per 255Km (156 miles) or two way route requiring clearance per day in LR2-4. •• ••• ••• SRC SRC SRC 1-0-31-32 2-0-11-13 1-0-39-40 • • 0-0-14-14 0-0-18-18 16 - RG-31 12 - BUFFALO 2 - MV4 Flail 12 - GSTAMIDS Block 0 4 - Aardvark Flail 10 - LET 2 - MCAP Dozer 14 - PantherLite (Full Width) 14 - Demo Kit 4 - HMMWV 1 - CPP 10 - 40 T Lowbed Trl 16 - HSTAMIDS 14 - TRAP 6 - MATILDA Robot 32 - Basic Body Armor Set 6 - UHMMWV 12 - Handheld FLIR 1 - LMTV 32 - Mine Protective Boot Set 2 - ¾ T Trl 12 - RF Jammer 6 - MCS-ENG 1 - Water Trl 13 - Change Detect Workstation

  8. E E E E HQ HORIZ HORIZ HAUL HORIZONTAL CONSTRUCTION COMPANY Mission: Executes general engineering missions to repair, maintain, and/or construct air/ground LOCs; repair and restore infrastructure, and enhance force and infrastructure protection in support of BCTs, Bdes, or Expeditionary Engineer Brigades. Supports gap crossing operations. Capabilities: Provides mission command for three to five platoons as an EMT; Construct 250 m of berm per hr; Excavate 112 - 144 cy material per lift (scrapers); 1859 cy (banked)/2321 cy (loose) material per hr (dozers); Scoop 3.26 cy (GP Bucket) /3.54 cy (Ditching Bucket) per lift (HYEX); Grade and compact approximately 2600 cy of material per hr; Compact 3000 compacted cy per hr (HSC); Scoop 1.50cy (See Bucket)/.52 cy (See BH) per hr; Scoop 2.50 cy (420D Bucket) and .46 cy (420D BH) per hr; Haul 48 - 56 cy of material per trip (20 T dump); Haul 104 cy of material per trip (EMM-Dump); Fully self-mobile utilizing organic assets not to exceed 130km. Assignment (Echelon): To Engineer Battalions as part of an Engineer Brigade under the operational control of a Theater Protection Command or Engineer Command, a Maneuver Enhancement Brigade, or part of a mission team that may augment a Maneuver BCT in defensive operations. Section I TOE BOA: 1.23 per horizontal construction workload (1000 MH per day) in LR 2-4 (except for maintenance of low traffic areas in LR2; damage repair of Low Damage Roads in LR2; and damage repair of Baseline 0 Troop Housing in LR2) 1 per HBCT during defensive operations; .33 per strategic port (will be offset by the port maintenance task) Capability Trace:CbtHvy Co; CSE; Corps Wheel Co Doctrinal Link/Rule Rationale: JP 3-06, JP 3-06, JP 4-04, JP 3.34, FM 3-0, FM 3-19.40, FM 3-5, FM 3-04.11, 5-205, 7-59. I E 5-0-141-146 HORIZ CONST Issue: None Discussion: Recommendation: Rule of Allocation: 1.223 per horiz const workload in LR2-4 (except for maint of low traffic areas in LR2; damage repair of low damage roads in LR2; and damage repair of baseline 0 troop housing in LR2. 1 per HBCT during defensive opns. .42 per HBCT during offensive opns. .33 per strategic port. •• ••• SRC ••• 2-0-11-13 1-0-42-43 1-0-46-47 9 - HMMWV 4 - Med Vibe 8 - MTV Dump 2 - HSC 3 - MTV 11 - 1.5 T Trl 4 - EMM-WD 2 - 5 Yd Scoop Loader 11 - D7 25 - M916 Tractor 8 - 621 Scraper 25 - M870 Semi-Trl 4 - Grader 6 - PLS Truck 2 - Backhoe 6 - PLS Trl 2 - HYEX 8 - Flat Racks 2 - ¾ T Trl 6 - EMM Dump Bed 1 - LMTV 2 - Trl f/Crane & attachments 1 - Water Trl 2 - 22 T Crane 4 - 20 T Dump

  9. E E E E HQ HORIZ HORIZ HAUL HORIZONTAL CONSTRUCTION COMPANY • Mission: Executes general engineering missions to repair, maintain, and/or construct air/ground LOCs; repair and restore infrastructure, and enhance force and infrastructure protection in support of BCTs, Bdes, or Expeditionary Engineer Brigades. Supports gap crossing operations. • Capabilities: Mission command for three to five platoons • Survivability Capabilities (per day) • 104 Tank Hull Defilade Positions, or • 41 Tank Turret Defilade Positions, or • 93 TOW HMMWV Positions, or • 171 Wheeled Vehicle Positions, or • 95 Dismounted Crew Serve Positions, or • 190 Individual Fighting Positions, or • 101 Bn TOC's, or • 441 105mm Positions, or • 433 155mm Positions • Construct 250 m of berm per hr • Countermobility Capabilities • 7,300 m ATD I E 5-0-141-146 HORIZ CONST •• ••• SRC ••• 2-0-11-13 1-0-42-43 1-0-46-47 9 - HMMWV 4 - Med Vibe 8 - MTV Dump 2 - HSC 3 - MTV 11 - 1.5 T Trl 4 - EMM-WD 2 - 5 Yd Loader 11 - D7 25 - M916 Tractor 8 - 621 Scraper 25 - M870 Trl 4 - Grader 6 - PLS Truck 2 - Backhoe 6 - PLS Trl 2 - HYEX 8 - Flat Racks 2 - ¾ T Trl 6 - EMM Dump 1 - LMTV 2 - Trl f/Crane 1 - Water Trl 2 - 22 T Crane 4 - 20 T Dump • General Engineering Capabilities • Excavate 112 - 144 cy material per lift (scrapers); 1859 cy (banked)/2321 cy (loose) material per hr (dozers); • Grade and compact 2600 cy of material per hr; Compact 3000 compacted cy per hr (HSC); • Scoop 1.50cy (See Bucket)/.52 cy (See BH) per hr; 2.50 cy (420D Bucket) and .46 cy (420D BH) • Haul 48 - 56 cy of material per trip (20 T dump); Haul 104 cy of material per trip (EMM-Dump); • Fully self-mobile utilizing organic assets not to exceed 130km.

  10. E E E E HQ VERT VERT VERT VERTICAL CONSTRUCTION COMPANY Assignment (Echelon): To Engineer Battalions as part of an Engineer Brigade under the operational control of a Theater Protection Command, or a Maneuver Enhancement Brigade. Section I TOE BOA: .95 per vertical construction workload (1000 MH per day) in LR 1-4; .33 per strategic port (will be offset by the port maintenance task) Capability Trace: Cbt Hvy Co; HHC Corps Airborne; HHC Corps Light; Utilities Team Doctrinal Link/Rule Rationale: JP 3-06, JP 3-06, FM 3-0, FM 3-19.40, FM 3-04.11, 5-205. Mission: Executes general engineering missions to construct basecamps, internment facilities; construct, repair, maintain vertical infrastructures in support of Bdesor Expeditionary Engineer Brigades. Capabilities: Provides mission command to three to five platoons as an EMT; Construct, repair, maintain woodframe, concrete, and preengineered structures; Construct, repair, maintain interior plumbing, water distribution, sewage distribution systems; Construct culverts/ abatements/ retaining walls; Scrape .62 cy of material per lift (SSL); Emplace interior electrical, sewer systems; airfield matting; Combine with horizontal and concrete modules to conduct port repair operations; Fully self mobile utilizing organic assets. I E 5-3-143-151 Issue: None Discussion: Recommendation: Rule of Allocation: .95 per vert const workload (1000MH per day) in LR1-4. .33 per strategic port (will be offset by the port maintenance task). VERT CONST •• ••• SRC 2-0-11-13 1-1-44-46 12 - HMMWV 9 - MTV Trl 12 - MTV Dump 3 - 250 CFM/HETO 3 - Welding Trl 9 - Electrical SKO 3 - MTV Dropside 9 - Plumbing SKO 3 - 1.5 T Trl 9 - Concrete/Masonry 3 - Backhoe w/forks 9 - Pioneer SKO 3 - FMTV Tractor 9 - Carpenter Sets 3 - 20 T Trl 3 - SSL (900 series) w/Combo Bucket 9 - MTV Dropside 3 - SSL auger, tiller, concrete mix, paver 2 - ¾ T Trl breaker, sweeper, track, tamper 1 - LMTV 1 - Water Trl

  11. E E E E HQ RDE-M RDE-L RDE-L BCT ENGINEER SUPPORT COMPANY Assignment (Echelon):To Engineer Battalions as part of an Engineer Brigade under the operational control of a Theater Protection Command, or a Maneuver Enhancement Brigade, or part of a mission team that may augment a Maneuver BCT. Section I TOE BOA: 1.16 per horiz construction workload (1000 MH per day) in LR 1; 1.16 per horiz construction workload (1000 MH per day) in LR 2 for maintenance of low traffic areas in LR 2; damage repair of Low Damage Roads in LR 2; and damage repair of Baseline 0 Troop Housing in LR 2; .9 per Armor UA; .76 per Light/SBCT UA Capability Trace: Corps Abn; Corps Light; LE Company Doctrinal Link/Rule Rationale: JP 3-06, JP 3-06, FM 3-0, FM 3-19.40, FM 3-04.11, 5-205. Mission: Employs light construction assets to conduct RRR, initial basecamp construction, repair and maintain ground LOCs, non-explosive area clearing, construct tactical UAS airfields, HLZs, and ALZs, and enhance force protection in support of BCTs, Maneuver Enhancement Brigades, or Expeditionary Engineer Brigades. Capabilities: Provides mission command for three to five platoons as an EMT; provide two RDE-L and 1 RDE-M platoon to Maneuver UA or SUAs; Construct 18 two-man fighting positions or 12 crew-served fighting positions per hr; Construct 200 m of protective berm per hr; Repair/maintain 8-12 km of MSR per day; Establish FARPS, Construct HLZ and UAV LZs; Combine with Horizontal Module to construct ALZ; Scrape 1.25 cy of material per lift (SSL); Prepare ingress/egress for float bridge operations; Fully self mobile utilizing organic assets not to exceed 190 km. I Issue: None Discussion: Recommendation: Rule of Allocation: 1.15 per horiz const workload (1000 MH per day) LR1. .76 per IBCT/SBCT. E 5-0-112-117 UA EN SPT •• ••• SRC ••• SRC 2-0-11-13 1-0-33-34 1-0-35-36 9 - HMMWV 2 - Cargo HMMWV 2 - ¾ T Trl 2 - DEUCE 6 - HMEE (self deployable) 2 - 613B WD 2 - Med Grader 14 - MTV Dump (Lapes) 8 - MTV Trl to haul SSL 2 - Small Roller 6 - 1.5 T Trl (behind MTV Dump) 8 - MTV Tractor (pull 25T) 4 - JD450 8 - 25 T Low Bed Trl 4 - 2.5 KVA Tact Gen Set 2 - 613B Scraper 8 - SSL (900 series) w/Combo Bucket 1 - LMTV 4 - SSL Dozer Blade, Foot Tamper, Track, 1 - Water Trl Sweeper, Tiller/Pavement Breaker attach 4 - RRR Kit 4 - Special Tools Kit (concrete saw, tamper, etc)

  12. E E E E E E E E E E MATERIEL PLANS INTEL PERS CMD DCP DCP HQ INTEGRATION SUSTAIN BATTALION HEADQUARTERS Mission: Plans, integrates, and directs execution of engineer missions by any mix of 3-7 assigned engineer companies to provide mobility in support of force application or focused logistics. Provides necessary level of engineer mission command to mission-tailored Bdesor Engineer Brigades at Division or Corps. Augments BCTs with focused engineer mission command if engineer task organization or scope of mission requires. Mission readiness of assigned companies and modules in the engineer force pool. Capabilities: Ensures mission readiness of 5-7 assigned companies/other modules in the force pool in garrison. As Engineer Mission Force, provides tailorable and scalable engineer mission command for 3-7 company sized engineer mission teams assigned to Support Bdesor Engineer Brigades. Has two deployable CPs to exercise mission command over dispersed locations or to augment the BTB of BCTs. Receives Design/ Survey and Explosive Hazard Teams from an Engineer Brigade to execute construction or explosive hazard clearance missions. Assignment (Echelon): Assigned to Engineer Brigades at Corps to accomplish Army Service Component Command missions or to Support Bdes at Division to accomplish operational and tactical mobility missions. Section I TOE BOA: 1 per 3 - 5 engineer companies in LR 1 - 2 in support of division; 1 per 3 - 7 engineer companies in LR 3 - 4 in support of Corps Capability Trace:Bn HQs of EN Corps Wheeled, Corps Mechanized, Corps Airborne, Corps Light Battalions, and HHD EN Bn Doctrinal Link/Rule Rationale: Theater Protection Command Concept; FM 5-34. • Issue: Reduced number of Engineer Battalions in the Regiment • Discussion: Future Engineer Force Battalion HQ was designed with greater capability than current HQs… specifically, increase the span of control • Applied to TAA, increasing the span of control to 5-7 companies will reduce the number of Engineer HQs • In the aggregate, this may be OK given direction of BTBs and ME • But, it may reduce flexibility and increase OPTEMPO of Engineer HQs • Recommendation: Stay the course…have aggressive strategic communications plan to the Regiment • Rule of Allocation: 1 per 3-5 eng companies in LR1-2 in support of Division. 1 per 3-7 eng companies in LR3-4 in support of Corps. I I E 18-2-49-69 •• •• •• •• 2-0-53-7 10-0-20-30 4-2-13-19 2-0-11-13 15 - HMMWV3 - TQG 2 - M113A3/ESV 3 - Tele Engineer Kit 4 - ENFIRE 5 - M577/CPP1 5 - ¾ T Trl2 3 - M105 Trl2 1 - Water Trl1 - LMTV Trl 4 - LMTV 1 - MTV NOTES 1. M577/Command Post Platform determined by unit requirement. 2. If equipped with CPP HQs receives 2 x HMMWV trailers; if equipped with M577 receives 1 x HMMWV trl, 1 x M105 trl.

  13. E E E E E E E E E E E E E E E E E E MATERIEL PLANS INTEL PERS CMD DCP DCP HQ DESIGN HQS DES/SURV DES/SURV DES/SURV DES/SURV PROCURE EDD INTEGRATION TECHNICAL SUSTAIN EXPEDITIONARY ENGINEER BRIGADE HQ Assignment (Echelon):OPCON to a TPC and/or Division Section I TOE BOA: 1 per Theater (min); 1 per additional 5-7 Engineer Battalion HQs in LR 2-4 Capability Trace:Cbt Group Hqs; Const Group Hqs; Corps BdeHqs; EAC BdeHqs Doctrinal Link/Rule Rationale: Theater Protection Command Concept, FM 3-34. Mission: Plans, integrates, and directs execution of engineer missions by 5-7 mission tailored engineer battalions to provide mobility in support of force application, focused logistics, or protection at the JTF/ASCC. Provides necessary level of engineer mission command to mission tailor Support Bdesor Engineer Brigades at Division or Corps. Augments BCTs or other Bdeswith focused engineer mission command if engineer task organization or scope of mission requires. May serve as a Joint Engineer HQs with augmentation. Ensures mission readiness of assigned battalion, companies, and modules in the engineer force pool. Capabilities: TRO for 5-7 assigned engineer battalions. Mission command 5-7 task organized battalion-sized engineer mission forces employed as a brigade sized EMF; augments Division, TPC, or JIIM HQs with engineer mission command, integration, and/or sustaining effects. Mission command for brigade sized EMF in support of TPC, Division, or JIIM HQs. Can simultaneously employ two deployable CPs. Engineer specific technical planning, design, and QA/QC. 24-hour ops capable. x • Issue: Reduced number of Engineer Brigades and Groups in the Regiment • Discussion: Future Engineer Force Brigade HQs was designed with greater capability than current HQs… specifically, increase the span of control • Applied to TAA, increasing the span of control to 5-7 battalions will reduce the number of Engineer HQs • In the aggregate, this may be OK given direction of BTBs and ME • But, it may reduce flexibility and increase OPTEMPO of Engineer HQs • Recommendation: Stay the course…have aggressive strategic communications plan to the Regiment • Rule of Allocation: 1 per Theater (min). 1 per LR2 when control exceeds 6 Eng Battalions. E 31-6-121-158 •• •• •• •• •• 3-0-6-9 13-0-28-41 8-4-61-73 2-0-11-13 5-2-15-22 SRC SRC 40 - HMMWV 12 - Tele Engr Kit 3 - M105 Trl 1 - EXP CAP HMMWV 18 - ENFIRE 2 - M113A3/ESV 8 - AISI Long Range 4 - Drafting Set 16 - GPS Receiver 6 - M577/CPP 24 - ¾ T Trl 4 - Soils Test Kit 4 - Nuclear Densometer Test Set 10 - LMTV 1 - MTV 4 - Concrete Test Set 6 - LMTV Trlr 4 - TQG 4 - Asphalt Test Set 1 - Water Trl
