  1. Dynamic Modeling FX. Henry Nugroho

  2. Dynamic Modeling • Keadaan yang bersifat temporal tidakbisadigambarkandengan DFD • Segalaaspeksistem yang berhubungandenganwaktudanperubahan, dimodelkandengan dynamic modeling • Event : menggambarkansesuatu yang terjadipadasuatusaattertentu (point in time). Contoh: saatklikkanan mouse

  3. Scenario for phone call • Caller lifts receiver • Dial tone begins • Caller dials digit(5) • Dial tone ends • Caller dials digit (4) • Caller dials digit (8) • Caller dials digit (6) • Caller dials digit (6) • Caller dials digit (6) • Caller dials digit (4)

  4. Scenario for phone call • Called phone beings ringing • Ringing tone appears in calling phone • Called party answer • Called phone stops ringing • Ringging phone disapears in calling phone • Phones are connected • Called party hangs up • Phones are disconnected • Caller hangs up

  5. State Diagram
