  1. Petroleum Storage Tank Bureau May 2002 presentation Introduction to Regulation of Underground and Above Ground Storage Tank Systems

  2. Petroleum Storage Tank Bureau Our Mission is to reduce, mitigate and eliminate the threats to the environment posed by petroleum products or hazardous material or wastes released from petroleum storage tanks. Petroleum Storage Tank Bureau

  3. Currently regulated by: Federal (US EPA 40 CFR) Underground Storage Tank Program State (NMED 20NMAC5) Petroleum Storage Tank Bureau Currently regulated by: Federal (US EPA) currently no one Federal Regulatory Program Governing ASTs is active. HOWEVER, there are existing statutes & regulations that apply directly or indirectly to ASTs. So Federal Reg’s are in the works from US EPA just like the… State (NMED) Petroleum Storage Tank Bureau, currently in progress of being created........ Petroleum Storage Tank Bureau Underground Storage Tank (UST) Aboveground Storage Tank (AST)

  4. Petroleum Storage Tank Bureau • Hazardous Waste Act, NMSA 1978 • Ground Water Protection Act, amended, NMSA 1979 • Environmental Improvement Act, NMSA 1979 • Senate Bill 333, Legislative Session, 2001 NMED REGULATORY BACKGROUND

  5. Petroleum Storage Tank Bureau • Are being generated with the assistance from the following: • Several states with existing regulations governing ASTs • State NMED PST Bureau Inspector’s experience • Industry Standards and Codes • Petroleum Equipment Institute (PEI) • National Fire Protection Association (NFPA) • Steel Tank Institute (STI) • others Aboveground Storage Tank Regulations

  6. Petroleum Storage Tank Bureau Types of Petroleum Storage Tank Systems: Underground Storage Tank Aboveground Storage Tank

  7. tanks are constructed of: Steel single wall double wall Petroleum Storage Tank Bureau Underground Storage Tank

  8. tanks are constructed of: Fiberglass Reinforced Plastic (FRP) single wall double wall Petroleum Storage Tank Bureau Underground Storage Tank

  9. tanks are constructed of a Composite- steel tank with clad layer single wall double wall Petroleum Storage Tank Bureau Underground Storage Tank

  10. Petroleum Storage Tank Bureau Field Erected Aboveground Storage Tank

  11. Petroleum Storage Tank Bureau Shop Fabricated Aboveground Storage Tank

  12. Petroleum Storage Tank Bureau • various designs and configuration; • parts are in contact with surface of the ground either: soil bedding, ringwalls, concrete pads or special foundation. • usually the underside of the ground contact area not readily available for visual inspection; • corrosion damage major concern and other forms of bottom-plate failures. • general volumes comprise of large, high-volume/capacity AST, found at industrial or refining settings (over 50,000 gallons). AST Field-Erected

  13. Petroleum Storage Tank Bureau • various designs and configuration; • are supported ABOVE the surface of the ground and; • all parts of tank are readily accessible for visual inspection; • corrosion damage are of minimal concern; • general volumes of tanks are under 50,000 gallons. AST Shop-Fabricated

  14. Petroleum Storage Tank Bureau Comparison of UST and AST Systems

  15. contains regulated substances 10% or more below the surface of the ground contains regulated substances permanently installed 1,100 gallons or more vaults and special enclosures Petroleum Storage Tank Bureau UST AST

  16. Petroleum Storage Tank Bureau UST AST

  17. Petroleum Storage Tank Bureau UST AST

  18. Petroleum Storage Tank Bureau 20 NMAC 5 PART 4 New and Upgraded Storage Tank Systems: Design, Construction and Installation • Performance standards for storage tank systems • UST systems • AST systems • Spill and overfill equipment • Special requirements for storage tank systems at marinas • Deadline for Closing or Upgrading AST systems July 1, 2006

  19. Storage Tank Systems Secondary Containment AST- Vaults Venting Systems Spill and Overfill Control Corrosion Protection Repairs and Modifications Reporting & Recordkeeping Inspections, Monitoring and Testing Petroleum Storage Tank Bureau 20 NMAC 5 PART 5 General Operating Requirements Operation and Maintenance of:
