  1. VBA for Excel

  2. What is a spreadsheet? • An Excel spreadsheet is a set of worksheets • Each worksheets is made up of rows and columns of cells • Rows are numeric: 1, 2, 3, … • Columns are alphabetic: A, B, C, … • A cell contains data, or a formula

  3. Cell Ranges B6:E13 column letters A1 Single cell G2 : G8 Single Column Range A3 : E3 Single Row Range Read as “B6 to E13” Row numbers

  4. Numerical Data • Numerical data is any number (formatted or not) • Numerical data can be used in a formula • You can use Format/Conditional formatting with to alter the appearance of numeric data • Examples: 5344 -34.5209 75%

  5. Formatting Numbers

  6. Formatting Dates

  7. Formulas • A formula represents a mathematical calculation • Always starts with = • A formula contains: • Numbers • 25.32, -56, 78 • Cell addresses and ranges • A3, G24, A2:A54 • Mathematical operators • Excel built-in functions • Today, Month, Sum =100*B5-D3+sum(R2:R15)

  8. Today and Month functions • =TODAY() • =MONTH( a date)

  9. Macros in Excel • A macro is a sequence of steps designed to accomplish a particular task • Just like a sub procedure in VB • In Excel, a user may create a macro in 2 ways • Record a sequence of steps in Excel using the macro recorder • Write a VB sub procedure using the macro editor

  10. Macro Statements • A Macro always begins a Sub statement • A Macro ends with an End Sub statement

  11. To perform multiple actions on the same object Macros use With End With A Macro

  12. The Selection object • Just as a user can select multiple cells simultaneously, a macro can select a region of a worksheet and apply changes to all the cells in that region

  13. Recording a Macro

  14. Putting a button onto a spreadsheet—in CS132 we use Control Objects • We can create a button and assign it to a Macro • This button is called a button control • View/Toolbars/Visual Basic • Then choose the button control

  15. Adding the button control

  16. The Visual Basic Toolbar View/Toolbars/Visual Basic Check Box Text box Command Button Option Button List boxes Label Image

  17. Using the Control Toolbox & Property Box • Click on the tools icon to display the controls toolbox • After you add a control, right click on it to display the properties box

  18. An object and its properties Sample Command Button name = cmdStart caption = text that appears on the button (Start) enabled = true or false You must follow good programming practice • Object names must be meaningful • cmdExit • cmdStart

  19. Accelerator Property s ( not S) • This is done by putting the desired letter in the Accelerator property in the properties box • (note lower case only matters if more than one letter is present)

  20. Referring to a Worksheet in VBA • An index number is a sequential number assigned to a sheet, based on the position of its sheet tab • The following procedure uses the Worksheets property to activate worksheet one in the active workbook. Sub FirstOne() Worksheets(1).Activate End Sub

  21. Cell Ranges in VBA Properties Range("A1").Value = 99 The Value property is what the cell holds, in this case 99 Range("B2:B7").Interior.Color = vbYellow This changes the color of the cells in "B2:B7" to yellow. Methods We can use Range(“A1”).Select This makes “A1” the active cell

  22. A1-style references using the Range property

  23. Cells Notation • Cells(2,2).Value refers to R2C2 below Remember, row first, then column B3 is the same as Cells(3,2)

  24. Cells vs. Range Range("B1").Value = 8 Range("B2").Value = 8 Can also be written: Cells(1,2).Value = 8 Cells(2,2).Value = 8

  25. Deleting data • You can clear the contents of a range using the ClearContents method: Private Sub cmdClear_Click() Range("D:D").ClearContents End Sub • Note: ClearContents does not clear the formatting, just the numbers or formulas contained within the cells.

  26. Event handling for VBA objects • The various objects present in an excel application (application, worksheet, etc.) generate events that can be handled • Working with such events is beyond the scope of this class

  27. Documentation http://msdn.microsoft.com/office/understanding/excel/documentation/default.aspx
