  1. Overview Presentation

  2. Introduction • The new Dedicated Micros DV-IP Server is a high performance scalable hybrid DVR designed for professional surveillance applications. • New capabilities include: local control, new enhanced user interface, embedded NetVu Console, AnalyticsCapable external SATA storage expansion • Unique TransCoding architecture to optimise streamingdepending on network topography

  3. Introduction • Flexible Local Control via telemetry keyboard, USB mouse or IR Remote • Embedded NetVu Console enables control of up to 1980 cameras, regardless of whether analogue or IP • Enhanced User Interface (common whether local or remote)‏ • Colour coded menus • Camera selection maps • Video Timeline • Electronic Pan, Tilt, Zoom - ePTZ • Point & Go • Absolute Positioning* • AnalyticsCapable – enables analytics solutions to be seamlessly deployed on your CCTV system

  4. Local Control • Operators can access connected cameras locally using an attached control device and standard definition monitor output • Local and remote user interface are identical to reduce operator and installer training and maintenance time • Control can be achieved using a wide range of methods including the KBC1 & 2 keyboards, a USB Mouse, USB Keyboard and the included Infrared Remote Control • Of course as a NetVu Connected DVR, the DV-IP Server can also be viewed from devices such as Pick-A-Point, NetVu Console and NetVu Observer

  5. Embedded NetVu Console • The DV-IP Server is equipped with a built -in sophisticated Video Management System • Embedded NetVu Console control means that you can connect, view and control up to 1980 mixed analogue and IP cameras: • 20 systems • Up to 8 servers or DVRs on each system • 99 cameras available per system • Camera selection can be simplified by using camera selection maps

  6. Embedded Console Using the Embedded Console, an Operator can view and control the locally connected cameras AND the cameras connected to Remote Server 1 AND the cameras connected to Remote Server 2 AND up to 20 systems comprising up to 8 DVRs per system with up to 99 cameras per system – max 1980 cameras

  7. Enhanced User Interface • The DV-IP Server contains the complete range of new Enhanced User Interface common to all Gen3 servers and encoders deployed by Dedicated Micros • Implemented across the new range of DV-IP products (DV-IP RT, DV-IP HD, DV-IP Express and DV-IP Server) and HighVu Excel • Features include: • Camera Selection Maps • Colour Coded Menus • Point&Go* • Video Timeline control of playback video • Absolute Positioning* • Electronic PTZ (ePTZ)‏ * Absolute Positioning & Point&Go require a Dedicated Micros Oracle Dome connected to a Next Generation DV-IP product that has the enhanced user interface

  8. Camera Selection Maps • Use bespoke graphical maps presented on your local monitor screen to navigate around your CCTV installation. • Ideal for quickly identifying camera locations around a site or CCTV infrastructure • Select the relevant camerato instantly connect to that cameras image stream • Load bespoke map imagesand floor plans onto the DVR to reflect the installation.

  9. Point&Go • Point&Go* provides the user with easy to use, fast, accurate telemetry control via an attached monitor. • Perfect for remote and IP based applications • Use the Pan & Tilt control of a DM Oracle Dome simply by clicking an area of the monitor • The camera will instantly respond, to any selection positioning the selected area in the middle of the screen • Ideal for tracking movement through a scene. • Removes network latency problems * Absolute Positioning & Point&Go require a Dedicated Micros Oracle Dome connected to a Next Generation DV-IP product that has the enhanced user interface

  10. Absolute Positioning • Absolute Positioning* combines the functionality of Camera Selection Maps with the deep integration of the Oracle Dome • Select and move cameras to any area of the site simply and quickly • Click in the area around the cameras location • The screen will switch to the cameras new view • The further away from the center of the cameras location you click, the more elevated the cameras view will become • When combined with Point&Go* it provides powerful and rapid visual control of your cameras * Absolute Positioning & Point&Go require a Dedicated Micros Oracle Dome connected to a Next Generation DV-IP product that has the enhanced user interface

  11. Electronic PTZ (ePTZ)‏ • Dedicated Micros Electronic PTZ uses an advanced image ‘interpolation’ algorithm that reveals detailed information that simple pixel-stretching digital zoom commands cannot. • Move around the scene and zoom in/out using the associated keyboard or remote control – even on static analogue cameras. • Combined with Dedicated Micros CamVu2000 Megapixel camera gives the user access to incredible detail. • Electronic Zoom can be carried out on both live and playback video • Provides the ability to retrospectively control and view an image as if it were a live PTZ dome or camera

  12. Video Timeline • A new on-screen intuitive interface for the control and navigation of playback video • Revolutionary method of getting to the video you need fast • Simple mouse operation to click on the timeline to get to the time you want • Control the video forward or backwards in incremental steps of seconds, minutes, hours, days and weeks • Ideal for the rapid search of captured video

  13. Megapixel & IP Images IP Streaming & Recording • Seamless recording & display of IP video streams from IP cameras, IP domes, encoders and other NetVu Connected DVR’s • Seamless Transparent Telemetry control • View and record IP sources, irrespective of the devices’ location • IP Streaming and Recording provides viewing and control across all connected IP cameras, seamlessly displaying them with analogue sources through a connected monitor. Megapixel Recording • Recording high definition megapixel camera images • Displayed in standard definition on an attached monitor • With the addition of ePTZ users are able to zoom into the detail of an attached megapixel camera with incredible clarity

  14. AnalyticsCapable • AnalyticsCapable products can be upgraded by software, to run a range of DM video analytics solutions including; Object Left/Removed, Object Counting, ANPR and Intrusion Detection / Perimeter Protection • Developed within the our own in-house development team, our analytics technology seamlessly integrates with a range of our NetVu Connected DVR’s – including the new DV-IP Server • Seamless control and viewing from a single platform - NetVu ObserVer • As the DV-IP Server is already AnalyticsCapable, users can upgrade their CCTV solution with analytics capabilities whenever required without having to redesign their system or add on expensive disparate 3rd party systems • Available via a software license upgrade

  15. Typical Applications • Create a local recording solution that seamlessly integrates into a wider CCTV infrastructure including legacy systems, so no need for a complete refit • Ideal for multi-site installations that also require remote access from a central control room or viewing client • View up to 1980 cameras from other systems thanks to the Embedded NetVu Console capability • Use in environments where you may require analytics, either now or in the future • Compliant with the UK's Remote Monitoring Standard BS8418 for use in remote monitoring scenarios where a Level 1 Police response is required

  16. Summary • Available in 8, 12 & 16 channel options • Local Control via attached keyboard, USB mouse or IR Remote • AnalyticsCapable – enables analytics solutions to be deployed on your CCTV system • Use Embedded Console to view up to 1980 cameras from the local control position of the DV-IP Server • Ideal for multi-site installations that also require remote access from a central control room or viewing client • Unique TransCoding architecture optimises video streams depending on the network topography • Includes Dedicated Micros Enhanced User Interface capability; On-screen maps, Video Timeline, ePTZ, Point & Go and Absolute Positioning* • BS8418 compliant for RVRC and remote monitoring applications * Absolute Positioning & Point&Go require a Dedicated Micros Oracle Dome connected to a Next Generation DV-IP product that has the enhanced user interface
