  1. Network Simulator - 2 Project Made by Min-Soo Kim and Kang-Yong Lee Ajou University, Division of Information & Computer Engineering 2003/06/09

  2. Index Purpose & Necessity Sample Network Architecture Proposed Network Architecture How to Implement Advantages & Drawbacks Project Schedule Implementation Core Source  Packet  Link Layer  Channel  MAC Layer 9. Simulation Environment 10. Simulation Video 11. Simulation Result

  3. 1. Purpose & Necessity • We will modify the network architectures which are assumed by sample NS-2 code. • Existing Network Architecture in sample code  Physically flat network architecture.  All nodes and routers have channel with homogeneous capability (link). • Proposed scheme  In real world, there is non-homogeneous channel capacity (link).  We consider routers and nodes which have group concept.  and all routers can communicate with each other, directly

  4. n1 n2 n7 R n4 n3 R n5 R n6 2. Existing Network Architecture n# : Node R : Router : Network (Ethernet)

  5. 3. Proposed Network Architecture n1 Group 1 n2 n7 R n4 Group 2 n3 R n5 Group 3 R n6 Group 4 : New Added Channel

  6. 4. How to Implement – Data structure Node Information – Routing module Group Membership Table - Routing module maintains group membership table which contains nodes ID in the same physical group Packet header - packet • Additional define a new packet field • channel mode (for channel layer) • in common header field

  7. 4. How to Implement – Algorithm Channel Routing Module • If destination node is not • located in • same physical group with router ? • Set the group field value to New channel mode else • Set the group field value To Normal mode Receives packet to transmit from upper layer Inter group traffic or Intra group traffic (Using channel field) ? Existing scheme New Added Channel - Delay control

  8. 5. Advantages & Drawbacks • Advantages  Reducing the number of packets  Guarantees good QoS - High transmission speed (through New added-Channel) - More reliable transmission (high delivery ratio) • Drawbacks  Additional overheads - Packet size is increasing (header field - channel field) - All routers must maintain the information of group member - All routers must equip two link  Potential bottleneck problem at the router

  9. 6. Project Schedule 5 / 24 5 / 26 5 / 28 6 / 1 6 / 3 6 / 5 6 / 7 Specific Design L , K Packet structure analysis K L Link, Channel analysis Coding - packet K Coding – Link, channel L Coding - routing L, K Debugging & Simulation L, K Result Analysis L, K L : By Kang-Yong Lee K : By Min-Soo Kim

  10. recv(p) arpresolve(p); 7. Implementation – Original Concept • 기존 LAN 에서의 Packet forwarding  one lanrouter object per a LAN  For every node on the LAN, the LL has a pointer to the lanrouter Direction ->Up sendUp(p) sendUp(p) Direction ->Down sendDown(p) YES lanrouter_->next_hop (p) ? next_hop(packet *p) NO schedule (downtarget_, p, delay_) LL::sendDown()

  11. arpresolve(p) 7. Implementation – Proposed Concept(1) • Before forwarding a packet, if “I am a router”, send the packet through “Direct Channel” to another router Direction ->Down sendDown(p) Modified part YES YES lanrouter_->next_hop (p)? Am I router ? Inter or Intra NO Inter NO Send the packet to other router through Direct Channel Intra next_hop(packet *p) Send the packet to other router through Normal Channel schedule(downtarget_, p, delay_) LL::sendDown()

  12. 7. Implementation – Proposed Concept(2) • Channel part Channel::sendUp() Received packet NORMAL_CHANNEL cmn_hdr->channel_type() DIRECT_CHANNEL Set the variables characterizing Normal Channel Set the variables characterizing Direct Channel Modified part

  13. 7. Implementation – Proposed Concept(3) • MAC layer Received packet NO DIRECT_CHANNEL cmn_hdr->channel_type() Am I router ? YES NORMAL_CHANNEL packet::free(p) Modified part Mac-802_3::recv()

  14. 8. Core Source – Packet • Add the new packet field : which_Channel_ New packet header field

  15. 8. Core Source – Link Layer • Distinguish the packet transmission type : Inter ? or Intra ? Set the channel type to use

  16. 8. Core Source – Channel • Characterizing “Direct Channel” : delay Set the delay of channel Send packet

  17. 8. Core Source – mac layer • Packet Drop or Receive ? If I am not a router, I must drop the packets which are received by Direct Channel. Because I don’t have the Direct Channel Link

  18. 9. Simulation Environment • Simulation Environment  The number of Node : 12 nodes  The number of Group : 4 physical groups  Simulation Time : 5 sec  Packet Size data packet : 1000 bytes ack packet : 40 bytes  Simulation Scenario * source : node 0 TCP Reno Agent * destination : node 14 TCP Sink Agent

  19. 10. Simulation Video • Other Meterials

  20. 11. Simulation Result • Simulation Result  Transmission Reliability (Received pkt / Transmitted packet) Original scheme : (1166/1181) = 0.9872 Proposed scheme : (1172/1184) = 0.9898  Transmission Time (End-to-End delay) Original scheme : 0.008 (sec) Proposed scheme : 0.005 (sec)
