  1. Accessing Help Files, References, and Sticky Notes FRAMES-2.0 Workshop U.S. Nuclear Regulatory Commission Bethesda, Maryland November 15-16, 2007 Pacific Northwest National Laboratory Richland, Washington

  2. On-Line Help(for Certain Models) 2

  3. Example of On-line Help Choose User Input forthe Exposure Module 3

  4. • Place cursor in parameter box • Left click “Help” • Left click on “How to … ” • Documentation on parameter “EC-MAXTIM” appears Example of On-line Help Note that the Range for the parameter is automatically given at the bottom of the page 4

  5. Documentation on Parameter “EC-MAXTIM” Appears 5

  6. References“Reference” functionality from FRAMES-1 has not been fully converted over to FRAMES-2 6

  7. Example of References Choose User Input forthe Exposure Module 7

  8. Example of Adding Reference “1” 8

  9. Sticky Notes 9

  10. Create a Sticky Note Right click over icon Type note in here. 10

  11. 1 View a Sticky Note 2 MEPAS 5.0 Source in an Aquifer This is a user-defined personalized note associated with the Source module. These notes are constructed by the user and will be displayed when the curser is held over the icon, when "Show Notes" is checked under the Customize menu. To View Note: 1. Choose Customize, Show Notes 2. Move Cursor over the Icon to see the Sticky Note. 11
