  1. TECHNICAL TRAINING 2008

  2. Mini Chiller Panel Controller V2.0

  3. Content 1. Mini Chiller Panel Controller V2.0 2. Inverter Parameter 3. Inverter Display 4. Other Information

  4. Mini Chiller Panel Controller V2.0 Chiller Panel vs Main Board Main Board Chiller Panel V2.0 Single Comp. Control Module, MC01 1 CP Double Comp. Control Module, MC01 2 CP Handset, CH_XX2.0 WCCH Tandem Comp. Control Module, MC01 HP TC2CP Inverter Control Module, Inverter

  5. Mini Chiller Panel Controller V2.0 OPERATING MENU TIMERS MENU ALARM MENU DISPLAY MENU SETTINGMENU SET PANEL ID CHANGE PASSWORD PANEL OPTION GENERAL SENSOR (OMITTED) REGULATOR COMPRESSOR CONDENSER DEFROST COOL MODE ANTIFREEZE ALARM & CONTACT (P4~P19 OMITTED) SET PARAMETER V2 EXV OPENING V3 COMPRESSOR MANUAL SETTING V4 EXV MANUAL SETTING V5 DEFROST MODE V1 COMPRESSOR FREQUENCY INVERTER Outline MAIN MENU

  6. Mini Chiller Panel Controller V2.0 OPERATING MENU SETTIGN MENU TIMERS MENU ALARM MENU DISPLAYMENU DEFROST SENSOR DISCHARGE SENSOR COMP. RUN TIME EXV OPENING CURRENT DC VOLTAGE SUCTION SENSOR BPHE IN SENSOR BPHE OUT SENSOR CONDENSER IN SENSOR COMPRESSOR FREQUENCY INVERTER CHILLER Outline MAIN MENU

  7. Schematic diagram Inverter chiller schematic diagram

  8. Inverter Parameter

  9. Inverter Parameter These parameter are only available when the Chiller Panel Controller V2.0 is connected to an Inverter Mini Chiller Model V1 Cp Freq : 0Hz V2 EXV : 0 V3 Cp Manual : Disable V4 EXV Manual : Disable V5 Def Mode : Disable V1 : Compressor Frequency It allows to set the inverter compressor frequency (max frequency varies according to models) V2 : EXV It allows to set the EXV opening (0~480 pulsation)

  10. Inverter Parameter V1 Cp Freq : 0Hz V2 EXV : 0 V3 Cp Manual : Disable V4 EXV Manual : Disable V5 Def Mode : Disable V3 : Cp Manual This parameter enables automatic or manual setting for compressor frequency Enable : Manual setting is possible Disable: Compressor frequency auto-run V4 : EXV Manual This parameter enables automatic or manual setting for EXV opening Enable : Manual setting is possible Disable: EXV opening auto-run

  11. Inverter Parameter V1 Cp Freq : 0Hz V2 EXV : 0 V3 Cp Manual : Disable V4 EXV Manual : Disable V5 Def Mode : Disable V5 : Def Mode This parameter enables automatic intelligent or standard defrosting setting Enable : Manual setting for defrosting is possible in Parameter D1~D6 Disable: Intelligent defrosting (auto-run)

  12. Inverter Display

  13. Inverter Display These parameter are only available when the Chiller Panel Controller V2.0 is connected to an Inverter Mini Chiller Model Inverter Chiller Comp : 45Hz EXV : 500 Comp Amp : 9.7A DC Bus : 385V Screen 1 Compressor Frequency It shows the operating inverter compressor frequency (Hz) EXV It shows the operating EXV opening (pulse) Comp Amp It shows the operating inverter compressor running current (A)

  14. Inverter Display Inverter Chiller Comp : 45Hz EXV : 500 Comp Amp : 9.7A DC Bus : 385V Screen 1 DC Bus It shows the operating DC voltage in the inverter system (V)

  15. Inverter Display Inverter Chiller Suction : 15.5°C BPHE In : 45.9°C BPHE Out : 18.3°C Condenser : 28.4°C Screen 2 Suction It shows the inverter compressor suction temperature (°C) BPHE In It shows the refrigerant inlet temperature at the BPHE during Cooling Mode. During Heating Mode, the value shows refrigerant outlet temperature at BPHE (°C)

  16. Inverter Display Inverter Chiller Suction : 15.5°C BPHE In : 45.9°C BPHE Out : 18.3°C Condenser : 28.4°C Screen 2 BPHE Out It shows the refrigerant outlet temperature at the BPHE during Cooling Mode. During Heating Mode, the value shows refrigerant inlet temperature at the BPHE (°C) Condenser It shows the inverter condenser coil inlet temperature (°C)

  17. Other Information

  18. Other Information If the Chiller Panel V2.0 is connected to a Non Inverter Mini Chiller, the following information will display “--” Inverter Parameter V1~V5 V1 Cp Freq : -- V2 EXV : -- V3 Cp Manual : -- V4 EXV Manual : -- V5 Def Mode : -- Display Menu for Inverter Chiller Inverter Chiller Comp : -- EXV : -- Comp Amp : -- DC Bus : -- Inverter Chiller Suction : -- BPHE In : -- BPHE Out : -- Condenser : -- Screen 1 Screen 2

  19. Other Information Alarm & Contact Parameter P1~P3 will display P1 FS Confirm : 5s P2 FS Delay : 180s P3 LP Delay : 30s Parameter P4~P19 and Sensor Parameter had been omitted P4 CO Reset : Manual P5 HP Reset : Auto P6 LP Reset : Auto P7 FO Reset : Manual P8 PO Reset : Manual P9 FS Reset : Manual P10 Aux Reset : Manual P11 A/F Reset : Manual P12 CO Contact : Normal P13 HP Contact : Normal P14 LP Contact : Normal P15 FO Contact : Normal P16 PO Contact : Normal P17 FS Contact : Normal P18 EA Contact : Normal P19 DE Contact : Normal S1 Water Enter : 0.0°C S2 Water Leave : 0.0°C S3 Air Sensor : 0.0°C S4 Defrost 1 : 0.0°C S5 Defrost 2 : 0.0°C S6 Defrost 3 : 0.0°C S7 Defrost 4 : 0.0°C S8 Cp Dish 1 : 0.0°C S9 Cp Dish 2 : 0.0°C S10 Cp Dish 3 : 0.0°C S11 Cp Dish 4 : 0.0°C

  20. Other Information If the Chiller Panel V1.0 is connected to an inverter mini chiller, there shall be no Inverter features. Alarm & Contact P4~P19 and Sensor Parameter will display “00”

  21. Thank You
