  1. Mobile Computing Cellular Concepts

  2. Cellular Networks • Wireless Transmission • Cellular Concept • Frequency Reuse • Channel Allocation • Call Setup • Cell Handoffs • Location Management

  3. Basic Idea • Single hop wireless connectivity to the wired world • Space divided into cells; A base station is responsible to communicate with hosts in its cell

  4. Wireless Transmission • Communication Frequencies • Frequencies in the VHF range are used • Regulation bodies • Antennas • Theoretically: equal radiation in all directions • Reality: directive effects, sectorized antennas

  5. Wireless Transmission • Signal Propagation • Classification: Analog/Digital, Periodic/Aperiodic • Parameters: Amplitude, Frequency and Phase shift • Modulation Techniques • Amplitude, Frequency, Phase • Multiplexing Mechanisms • Space (SDM), Frequency (FDM), Time (TDM), Code (CDM)

  6. Cellular Concept • Mobile hosts can change cells while communicating • Hand-off occurs when a mobile host changes base station • Factors for determining cell size • No. of users to be supported • Multiplexing and transmission technologies

  7. Cellular Concept • Limited number of frequencies => limited channels • Single high power antenna => limited number of users • Smaller cells => frequency reuse possible => more number of users • As demand increases (more channels needed) • Number of base stations is increased • Transmitter power is decreased correspondingly to avoid interference

  8. Cellular Concept • Base stations (BS): implement space division multiplex • Each BS covers a certain transmission area (cell) • Each BS is allocated a portion of the total number of channels available • Cluster: group of nearby BSs that together use all available channels • Mobile stations communicate only via the base station, using FDMA, TDMA, CDMA…

  9. Cellular Concept • Cell size: • 100 m in cities to 35 km on the country side (GSM) • even less for higher frequencies

  10. Cellular Concept • Cell shape: • Hexagonal is useful for theoretical analysis • Practical footprint (radio coverage area) is amorphous • BS placement: • Center-excited cell: BS near center of cell • omni-directional antenna • Edge-excited cell: BSs on cell vertices • sectored directional antennas

  11. Cellular Concept • Advantages: • higher capacity, higher number of users • less transmission power needed • more robust, decentralized • base station deals with interference, transmission area etc. locally

  12. Cellular Concept • Problems: • fixed network needed for the base stations • handover necessary • interference with co-channel, adjacent-channel • Important Issues: • Cell sizing; Frequency reuse planning • Channel allocation strategies Bottom line: Attempt to maximize availability of channels in an area

  13. Geometric Representation • Cells are commonly represented by hexagons. • Why hexagon? • How about circle? • How about square, or triangle?

  14. Hexagonal Cells

  15. Channel Reuse • The total number of channels are divided into K groups. • K is called reuse factor or cluster size. • Each cell is assigned one of the groups. • The same group can be reused by two different cells provided that they are sufficiently far apart.

  16. Example: K = 7

  17. Coordinate System Use (i,j) to denote a particular cell. Example: Cell A is represented by (2,1). A

  18. Distance Formula where R D Reuse factor Note: i and j are integers

  19. MSC MSC HLR VLR HLR VLR To other MSCs PSTN PSTN Cellular System Architecture

  20. Cellular System Architecture • Each cell is served by a base station (BS) • Each BS is connected to a mobile switching center (MSC) through fixed links • Each MSC is connected to other MSCs and PSTN

  21. Cellular System Architecture • Each MSC is a local switching exchange that handles switching of mobile user from one base station to another • Locating the current cell of a mobile user • Home Location Register (HLR): database recording the current location of each mobile that belongs to the MSC • Visitor Location Register (VLR): database recording the cell of “visiting” mobiles • Interfacing with other MSCs and PSTN

  22. Cellular System Architecture • One channel in each cell is set aside for signalling information between BS and mobiles • Mobile-to-BS: location, call setup for outgoing, response to incoming • BS-to-Mobile: cell identity, call setup for incoming, location updating

  23. Call Setup • Outgoing call setup: • User keys in the number and presses send (no dial tone) • Mobile transmits access request on uplink signaling channel • If network can process the call, BS sends a channel allocation message • Network proceeds to setup the connection

  24. Call Setup (contd) • Network activity: • MSC determines current location of target mobile using HLR, VLR and by communicating with other MSCs • Source MSC initiates a call setup message to MSC covering target area

  25. Call Setup (contd) • Incoming call setup: • Target MSC (covering current location of mobile) initiates a paging msg • BSs forward the paging message on downlink channel in coverage area • If mobile is on (monitoring the signaling channel), it responds to BS • BS sends a channel allocation message and informs MSC

  26. Hand-Offs Mobile moves from one BS into another • BS initiated: • BS monitors the signal level of the mobile • Handoff occurs if signal level falls below threshold • Increases load on BS • Monitor signal level of each mobile • Determine target BS for handoff

  27. Hand-Offs (contd) • Mobile assisted: • Each BS periodically transmits beacon • Mobile, on hearing stronger beacon from a new BS, sends it a greeting • changes routing tables to make new BS its default gateway • sends new BS identity of the old BS • New BS acknowledges the greeting and begins to route mobile’s call

  28. Hand-Offs • Intersystem: (Roaming) • Mobile moves across areas controlled by different MSC’s • Handled similar to mobile assisted case with additional HLR/VLR effort • Local call may become long-distance

  29. Cellular Implementations • First-generation: Analog cellular systems (450-900 MHz) • Frequency shift keying for signaling • FDMA for spectrum sharing • NMT (Europe), AMPS (US) • Second-generation: Digital cellular systems (900, 1800 MHz) • TDMA/CDMA for spectrum sharing • Circuit switching • GSM (Europe), IS-136 (US), PDC (Japan)

  30. Cellular Implementations • 2.5G: Packet switching extensions • Digital: GSM to GPRS • Analog: AMPS to CDPD • 3G: • High speed, data and Internet services • IMT-2000
